CV-100/P1000 Series
User Manual
Version: V2.05
Industrial Panel PC
Power Efficient Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV-100/P1000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Cincoze CV-100/P1000 Series

Summary of Contents for Cincoze CV-100/P1000 Series

  • Page 1 CV-100/P1000 Series User Manual Industrial Panel PC Power Efficient Series Version: V2.05...

  • Page 2: Table Of Contents

    Contents Preface Revision……………………………………………..……………….……………...……………...05 Copyright Notice.…………………………………………………………………………………...05 Acknowledgement.………………………………………………………………......05 Disclaimer.………………………………………………………………….………………...05 Declaration of Conformity.………………………………………………….……………………06 Product Warranty Statement …………………………………………………………….....06 Technical Support and Assistance.…………………………………………….…………………07 Conventions Used in this Manual …………………………………………….…………....08 Safety Precaution …...……………………………………………….………….………....08 Package Contents ………………………………………………………….…….………...……10 Optional Modules & Accessories……………………………………........10 Ordering Information …………………………………...…………………….…….……...……...11 Chapter 1 Product Introductions 1.1 Overview …………………………………………………….……..……………....17 1.2 Product Pictures……...……………………………………….……………………....17 1.3 Hardware Specification ……………..……………………….……...………………..……18...
  • Page 3 Chapter 3 System Setup 3.1 Removing the Top Cover ……...……………………………….….…………………..64 3.2 Installing a Half Size Mini PCIe Card………………………………………….……………65 3.3 Installing a Full Size Mini PCIe Card…………………………..…………….……………66 3.4 Installing Antennas…………………………….…………….……...……………….....67 3.5 Installing a SO-DIMM………………………………………..….…………………..69 3.6 Installing the Top Cover...……………………………………..…………...…….……..70 3.7 Installing a SATA Hard Drive…...……….….….……..………...….…………………...…71 3.8 Installing a SIM Card……………………….…...…………………….….……………..72 3.9 Installing a CFast Card………………………...……………..….…………….………..73 3.10 Connecting with CV Display Module…………………………...….……………………..74...
  • Page 4 4.6.3 Full Screen Logo Show……………………………………….………………..……98 4.6.4 Fast Boot ……………..………………………………………………………………...98 4.6.5 UEFI Boot……………..………………………………………………………………...98 4.7 Save & Exit …...……….….……………………..….…..………………………....99 4.7.1 Save Changes and Reset …………………………………………………………….99 4.7.2 Discard Changes and Reset ….………………………………………………………99 4.7.3 Restore Defaults …………………………………….…………………………………99 4.7.4 Save as User Defaults ………………….……………………………………………. 99 4.7.5 Restore User Defaults ..…………………………….…………………………………99 Chapter 5 Product Application 5.1 Digital I/O (DIO) application ………..…………………………………………….…………101...

  • Page 5: Revision

    Corrections made 2021/06/28 © 2018 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 6: Declaration Of Conformity

    Product Warranty Statement Warranty Cincoze products are warranted by Cincoze Co., Ltd. to be free from defect in materials and workmanship for 2 years (2 Years for PC Module, 1 Year for Display Module) from the date of purchase by the original purchaser. During the warranty period, we shall, at our option, either repair or replace any product that proves to be defective under normal operation.

  • Page 7: Technical Support And Assistance

    Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.

  • Page 8: Conventions Used In This Manual

    ⚫ Description of your peripheral attachments ⚫ Description of your software (operating system, version, application software, etc.) ⚫ A complete description of the problem ⚫ The exact wording of any error messages Conventions Used in this Manual Safety Precautions Before installing and using this device, please note the following precautions. Read these safety instructions carefully.
  • Page 9 Position the power cord so that people cannot step on it. Do not place anything over the power cord. 10. All cautions and warnings on the equipment should be noted. 11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage.

  • Page 10: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Panel PC Panel Mounting Kit Utility DVD Driver DIO Terminal Block Connector Power Terminal Block Connector Screw Pack Mini PCIe Screw Pack Note: Notify your sales representative if any of the above items are missing or damaged.

  • Page 11: Ordering Information

    Mini-PCIe Module with 2x USB 3.0 Ports, 1x30 cm cable / 1x MEC-USB-M102-3 Universal Bracket with 2x USB Cutout for DS-1000/ DS-1100 / 0/UB0314 P1000 Series (For P1001E only) Ordering Information Panel PC with Resistive 5-wire Touch Model No. Product Description 8.4"...
  • Page 12 12.1" TFT XGA 4:3 Panel PC with Resistive 5-wire Touch, CV-112HR-R10/P1001 w/ Intel Atom E3845 Quad Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort 12.1" TFT XGA 4:3 Panel PC with Resistive 5-wire Touch, CV-112HR-R10/P1001E w/ Intel Atom E3845 Quad Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort and 2x Universal bracket 15"...
  • Page 13 24" TFT Full HD 16:9 Panel PC with Resistive 5-wire CV-W124R-R10/P1001 Touch and Intel® Atom™ E3845 Quad Core PC Module, 4x USB, 2x COM, 1x VGA, 1x DisplayPort 24" TFT Full HD 16:9 Panel PC with Resistive 5-wire Touch and Intel® Atom™ E3845 Quad Core PC Module, CV-W124R-R10/P1001E 4x USB, 2x COM, 1x VGA, 1x DisplayPort, 2x Universal Brackets...
  • Page 14 12.1" TFT XGA 4:3 Panel PC with Projected Capacitive CV-112HC-R10/P1001 Touch, w/ Intel Atom E3845 Quad Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort 12.1" TFT XGA 4:3 Panel PC with Projected Capacitive Touch, w/ Intel Atom E3845 Quad Core, 4x USB, 2x CV-112HC-R10/P1001E COM, 1x VGA and 1x DisplayPort and 2x Universal bracket...
  • Page 15 21.5" TFT Full HD 16:9 Panel PC with Projected Capacitive Touch and Intel Atom E3845 Quad Core, 4x CV-W121C-R10/P1001E USB, 2x COM, 1x VGA, 1x DisplayPort, 2x Universal bracket 24" TFT Full HD 16:9 Panel PC with Projected Capacitive CV-W124C-R10/P1001 Touch and Intel®...

  • Page 16: Chapter 1 Product Introductions

    Chapter 1 Product Introductions P1000 Series | User Manual CV-100/...

  • Page 17: Overview

    Furthermore, they are 3 types of storage devices including 2.5" SATA HDD, CFast and SIM card. The accessible design of these storage devices allows quick data access and easy maintenance. Supporting wide range power DC input from 9 ~ 48VDC, The CV-100/P1000 Series can be deployed and powered for various industrial applications.

  • Page 18: Hardware Specification

    1.3 Hardware Specification 1.3.1 CV-108/P1000 CV-108R/P1000 | CV-108C/P1000 Display Other Features • LCD Size: 8.4" (4:3) • Watchdog Timer: Software Programmable Supports 256 • Max. Resolution: 800 x 600 Levels System Reset • Brightness (cd/m2): 400 • Audio: AMP 2W + 2W (Internal Speaker) •...
  • Page 19 Dimension CV-108/P1001 Unit: mm P1000 Series | User Manual CV-100/...
  • Page 20 CV-108/P1001E Unit: mm P1000 Series | User Manual CV-100/...
  • Page 21 1.3.2 CV-110/P1000 CV-110R/P1000 | CV-110C/P1000 Display Other Features • LCD Size: 10.4" (4:3) • Watchdog Timer: Software Programmable Supports 256 • Max. Resolution: 800 x 600 Levels System Reset • Brightness (cd/m2): 400 • Audio: AMP 2W + 2W (Internal Speaker) •...
  • Page 22 CV-110HR/P1000 | CV-110HC/P1000 Display Other Features • LCD Size: 10.4" (4:3) • Watchdog Timer: Software Programmable Supports 256 • Max. Resolution: 1024 x 768 Levels System Reset • Brightness (cd/m2): 400 • Audio: AMP 2W + 2W (Internal Speaker) • Contrast Ratio: 1400 : 1 •...
  • Page 23 Dimension CV-110/P1001 & CV-110H/P1001 Unit: mm P1000 Series | User Manual CV-100/...
  • Page 24 CV-110/P1001E & CV-110H/P1001E Unit: mm P1000 Series | User Manual CV-100/...
  • Page 25 1.3.3 CV-112/P1000 CV-112R/P1000 | CV-112C/P1000 Display Other Features • LCD Size: 12.1" (4:3) • Watchdog Timer: Software Programmable Supports 256 • Max. Resolution: 800 x 600 Levels System Reset • Brightness (cd/m2): 450 • Audio: AMP 2W + 2W (Internal Speaker) •...
  • Page 26 CV-112HR/P1000 | CV-112HC/P1000 Display Other Features • LCD Size: 12.1" (4:3) • Watchdog Timer: Software Programmable Supports 256 • Max. Resolution: 1024 x 768 Levels System Reset • Brightness (cd/m2): 500 • Audio: AMP 2W + 2W (Internal Speaker) • Contrast Ratio: 700 : 1 •...
  • Page 27 Dimension CV-112/P1001 & CV-112H/P1001 Unit: mm P1000 Series | User Manual CV-100/...
  • Page 28 CV-112/P1001E & CV-112H/P1001E Unit: mm P1000 Series | User Manual CV-100/...
  • Page 29 1.3.4 CV-115/P1000 CV-115R/P1000 | CV-115C/P1000 Display Other Features • LCD Size: 15" (4:3) • Watchdog Timer: Software Programmable Supports 256 • Max. Resolution: 1024 x 768 Levels System Reset • Brightness (cd/m2): 350 • Audio: AMP 2W + 2W (Internal Speaker) •...
  • Page 30 Dimension CV-115/P1001 Unit: mm P1000 Series | User Manual CV-100/...
  • Page 31 CV-115/P1001E Unit: mm P1000 Series | User Manual CV-100/...
  • Page 32 1.3.5 CV-W115/P1000 CV-W115R/P1000 | CV-W115C/P1000 Display Other Features • LCD Size: 15.6" (16:9) • Watchdog Timer: Software Programmable Supports 256 • Max. Resolution: 1366 x 768 Levels System Reset • Brightness (cd/m2): 400 • Audio: AMP 2W + 2W (Internal Speaker) •...
  • Page 33 Dimension CV-W115/P1001 Unit: mm P1000 Series | User Manual CV-100/...
  • Page 34 CV-W115/P1001E Unit: mm P1000 Series | User Manual CV-100/...
  • Page 35 1.3.6 CV-117/P1000 CV-117R/P1000 | CV-117C/P1000 | CV-117G/P1000 Display Other Features • LCD Size: 17" (5:4) • Watchdog Timer: Software Programmable Supports 256 • Max. Resolution: 1280 x 1024 Levels System Reset • Brightness (cd/m2): 350 • Audio: AMP 2W + 2W (Internal Speaker) •...
  • Page 36 Dimension CV-117/P1001 Unit: mm P1000 Series | User Manual CV-100/...
  • Page 37 CV-117/P1001E Unit: mm P1000 Series | User Manual CV-100/...
  • Page 38 1.3.7 CV-119/P1000 CV-119R/P1000 | CV-119C/P1000 | CV-119G/P1000 Display Other Features • LCD Size: 19" (5:4) • Watchdog Timer: Software Programmable Supports 256 • Max. Resolution: 1280 x 1024 Levels System Reset • Brightness (cd/m2): 350 • Audio: AMP 2W + 2W (Internal Speaker) •...
  • Page 39 Dimension CV-119/P1001 Unit: mm P1000 Series | User Manual CV-100/...
  • Page 40 CV-119/P1001E Unit: mm P1000 Series | User Manual CV-100/...
  • Page 41 1.3.8 CV-W121/P1000 CV-W121R/P1000 | CV-W121C/P1000 | CV-W121G/P1000 Display Other Features • LCD Size: 21.5" (16:9) • Watchdog Timer: Software Programmable Supports 256 • Max. Resolution: 1920 x 1080 Levels System Reset • Brightness (cd/m2): 300 • Audio: AMP 2W + 2W (Internal Speaker) •...
  • Page 42 Dimension CV-W121/P1001 Unit: mm P1000 Series | User Manual CV-100/...
  • Page 43 CV-W121/P1001E Unit: mm P1000 Series | User Manual CV-100/...
  • Page 44 1.3.9 CV-W124/P1000 CV-W124R/P1000 | CV-W124C/P1000 | CV-W124G/P1000 Display • Audio: AMP 2W + 2W (Internal Speaker) • LCD Size: 24" (16:9) • OSD Function: LCD On/Off, Brightness Up/Down • Max. Resolution: 1920 x 1080 Power • Brightness (cd/m2): 300 • Support AT, ATX Mode •...
  • Page 45 Dimension CV-W124/P1001 Unit: mm P1000 Series | User Manual CV-100/...
  • Page 46 CV-W124/P1001E Unit: mm P1000 Series | User Manual CV-100/...

  • Page 47: System I/O

    1.4 System I/O 1.4.1 Front ATX Power On/Off CFast and SIM card Slot Used to power-on or power-off the system Used to insert a CFast card and SIM card Antenna Hole Removable HDD Bay Used to connect an antenna for optional wireless Used to insert a 2.5”...

  • Page 48: Rear

    1.4.2 Rear DC IN USB 2.0 port Used to plug a DC power input with terminal Used to connect USB 2.0/1.1 device LAN port block Reset Button Used to connect the system to a local area Used to reset the system network Mic-in Used to connect a microphone...

  • Page 49: Side (Left)

    1.4.3 Side (Left) USB 3.0 port Digital I/O Terminal Block Used to connect USB 3.0/2.0/1.1 device The Digital I/O terminal block supports 4 digital USB 2.0 port input and 4 digital output AT/ATX mode select switch Used to connect USB 2.0/1.1 device Used to select AT or ATX power mode P1000 Series | User Manual CV-100/...

  • Page 50: Side (Right)

    1.4.4 Side (Right) COM port OSD Function: COM 2 supports RS232/422/485 serial device LCD On/Off DisplayPort Press to turn-on or turn-off the display Used to connect a DisplayPort devices Increase Brightness Power LED Press to increase brightness of the screen Indicates the power status of the system Decrease Brightness HDD LED...

  • Page 51: Top

    1.4.5 Top VESA Mounting Hole These are mounting holes for VESA mount (75x75mm and 100x100mm) P1000 Series | User Manual CV-100/...
  • Page 52 Chapter 2 Jumpers, Switches & Connectors P1000 Series | User Manual CV-100/...

  • Page 53: Jumpers Settings

    2.1 Jumpers Settings When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open. Refer to below for examples of the 2-pin and 3-pin jumpers when they are short (on) and open (off).

  • Page 54: Bottom View

    2.2.2 Bottom View P1000 Series | User Manual CV-100/...

  • Page 55: Definition Of Jumpers/Switches/Connectors

    2.3 Definition of Jumpers/Switches/Connectors List of Jumpers/Switches/Connectors Location Definition AT_ATX1 AT / ATX Power Mode Switch BL_PWR1 Backlight Power on / off switching BL_UP1 Backlight Increase BL_DN1 Backlight Decrease CFAST1 CFast Connector CLR_CMOS1 Clear BIOS Switch COM1_1, COM2_1 RS232 / RS422 / RS485 Connector COM12_SEL1 COM1 / COM2 with Power Select DC_IN1...

  • Page 56: Definition Of Jumpers

    2.4 Definition of Jumpers COM12_SEL1: COM1 / COM2 with Power Select Connector Type: 2X5 10-pin Header, 2.0mm pitch COM1 COM2 Definition Definition 1-3 On 2-4 On 3-5 On +12V 4-6 On +12V 7-9 On 8-10 On Reserved Reserved (Default) (Default) 2.5 Definition of Switches AT_ATX1: AT / ATX Power Mode Switch Definition...

  • Page 57: Definition Of Connectors

    RESET1: Reset Switch Switch Definition Push Reset System 2.6 Definition of Connectors CFAST1: CFast Connector Definition Definition Definition PC10 SATA_TX2+ PC11 SATA_TX2- PC12 PC13 +3.3V SATA_RX2- PC14 +3.3V SATA_RX2+ PC15 PC16 PC17 COM1~COM2: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 RS485 RS232...
  • Page 58 DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~48VIN Chassis GND Please disconnect the power source before mounting the DC power cables or connecting the DC power connector to system. DP1: DisplayPort Connector Definition Definition DP_LANE0_P...
  • Page 59 LED1: Power / HDD Access LED Status Definition HDD LED+ HDD LED- POWER LED+ POWER LED- LED Status LED Color Yellow POWER Green LINE_OUT1: Line-out Jack (Green) Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L MIC1: Microphone Jack (Pink) Connector Type: 5-pin Phone Jack Definition MIC_R MIC_L...
  • Page 60 POWER1: Power Connector Connector Type: 1X4-pin Wafer, 2.0mm pitch Definition +12V SATA1: SATA with Power Connector Definition Definition SATA_TX1+ SATA_TX1- SATA_RX1- SATA_RX1+ +3.3V +3.3V +12V +3.3V +12V +12V SIM1：SIM Card Socket Definition UIM_PWR UIM_RESET UIM_CLK UIM_VPP UIM_DATA P1000 Series | User Manual CV-100/...
  • Page 61 SPK_L1: Left Internal Speaker Connector Definition OUT_L SPK_R1: Right Internal Speaker Connector Definition OUT_R USB1_2_1：USB2.0 Connector, Type A Definition Definition USB_DATA0- USB_DATA_1- USB_DATA0+ USB_DATA_1+ USB2_1: USB2.0 Connector, Type A Definition USB2_DATA1- USB2_DATA1+ USB3_1: USB 3.0 Connector, Type A Definition Definition USB3_RX0+ USB2_D0- USB2_D0+...
  • Page 62 MINIPCIE1: Mini PCI-Express Socket Pin Definition Pin Definition Pin Definition WAKE# +3.3V +3.3V USB2_3P +3.3V MINIPCIE RST# MINIPCIE_RXN +3.3V +1.5V +3.3V CLKREQ# MINIPCIE_RXP UIM_PWR UIM_DATA +1.5V MINIPCIE_CLKN 29 UIM_CLK SMB_CLK +1.5V MINIPCIE_CLKP 31 MINIPCIE_TXN UIM_RESET SMB_DATA MINIPCIE_TXP UIM_VPP +3.3V USB2_3N P1000 Series | User Manual CV-100/...

  • Page 63: Chapter 3 System Setup

    Chapter 3 System Setup P1000 Series | User Manual CV-100/...

  • Page 64: Removing The Top Cover

    3.1 Removing the Top Cover Loosen the 8 screws of front and rear panel, then place them aside. Remove the cover from the chassis. Place the top cover gently. P1000 Series | User Manual CV-100/...

  • Page 65: Installing A Half Size Mini Pcie Card

    3.2 Installing a Half Size Mini PCIe Card Locate the Mini PCIe slot. Use provided two screws on bracket to fasten the module and bracket together. Tilt the Mini PCIe module at 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot.

  • Page 66: Installing A Full Size Mini Pcie Card

    Press down the module and use the two screws to fix the module. 3.3 Installing a Full Size Mini PCIe Card 1. Locate the Mini PCIe slot. 2. Tilt the Mini PCIe module at 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot.

  • Page 67: Installing Antennas

    3. Press down the module and use the two screws to fix the module. 3.4 Installing Antennas Remove the antenna hole covers at front panel. Have antenna jack penetrate through the hole. P1000 Series | User Manual CV-100/...
  • Page 68 Put on washer and fasten the nut with antenna jack. Assemble the antenna and antenna jack together. Attach the RF connector at another end of cable onto the module. P1000 Series | User Manual CV-100/...

  • Page 69: Installing A So-Dimm

    3.5 Installing a SO-DIMM 1. Locate SO-DIMM socket. 2. Tilt the SODIMM module at a 45-degree angle and insert it to SODIMM socket until the gold-pated connector of module contacted firmly with the socket. 3. Press the module down until its fixed firmly by the two locking latches on each side. P1000 Series | User Manual CV-100/...

  • Page 70: Installing The Top Cover

    3.6 Installing the Top Cover 1. Put on the cover. 2. Fasten the 8 screws to fix the cover. P1000 Series | User Manual CV-100/...

  • Page 71: Installing A Sata Hard Drive

    3.7 Installing a SATA Hard Drive 1. Locate the removable HDD bay and loosen the 3 screws. 2. Pull out the HDD bracket. 3. Make the PCB side of the HDD face up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together.

  • Page 72: Installing A Sim Card

    4. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket until the connector of HDD contact the SATA connector firmly. 3.8 Installing a SIM Card 1. SIM card slot is at the front panel of the system. 2.

  • Page 73: Installing A Cfast Card

    3.9 Installing a CFast Card 1. Locate the CFast card slot. 2. Remove the mounting cover by unscrewing the two screws. 3. Insert the CFast card until it clicks. P1000 Series | User Manual CV-100/...

  • Page 74: Connecting With Cv Display Module

    3.10 Connecting with CS Display Module 1. Locate the module connector slot and loosen the 1 screw. 2. Turn over the unit to have the bottom side face up, loosen the 2 screws of the module connector bracket. The photos show the male connector (on display module) and female connector (on PC module) P1000 Series | User Manual CV-100/...
  • Page 75 3. Connect the modules. 4. Fasten the 6 screws to fix the PC module on the display module. P1000 Series | User Manual CV-100/...

  • Page 76: Vesa Mount Bracket

    3.11 VESA Mount Bracket The following picture indicates VESA mounting hole pattern on P1000, which is compliant with VESA mounting standard. 1. The following picture uses a panel PC (P1000+CV display module) as a demonstration. To attach the panel PC to a VESA stand, please fasten eight screws as indicated to fix it on the stand.

  • Page 77: Panel Mount

    3.12 Panel Mount 1. Accessories provided by Cincoze are as follows. P1000 Series | User Manual CV-100/...
  • Page 78 2. All mounting kits displayed are to be inserted into holes. 3. Installation preparation and steps. P1000 Series | User Manual CV-100/...
  • Page 79 P1000 Series | User Manual CV-100/...
  • Page 80 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below. P1000 Series | User Manual CV-100/...

  • Page 81: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup P1000 Series | User Manual CV-100/...

  • Page 82: Bios Introduction

    4.1 BIOS Introduction The BIOS (Basic Input/ Output System) is a program located on a Flash Memory on the motherboard. When you start the computer, the BIOS program will gain control. The BIOS first operates an auto-diagnostic test called POST (power on self-test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 83: Main Setup

    4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 4.2.1 System Date Set the date.

  • Page 84: Advanced Setup

    4.3 Advanced Setup 4.3.1 ACPI Settings Enable or disable ACPI Auto Configuration. P1000 Series | User Manual CV-100/...

  • Page 85: Super Io Configuration

    4.3.2 Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. ■ Serial Port 1 Configuration ❑ Serial Port This item will allow users to enable or disable serial port. ❑...

  • Page 86: Hardware Monitor

    ■ Watch Dog Function You can setup the system watch-dog timer, a hardware timer that generates a reset when the software that it monitors does not respond as expected each time the watch dog polls it. ❑ Watch Dog Mode Change the Watch dog mode.

  • Page 87: Serial Port Console Redirection

    4.3.4 Serial Port Console Redirection ■ Console Redirection This item allows users to enable or disable console redirection. 4.3.5 CPU Configuration ■ Socket 0 CPU Information This section provides information on your CPU, frequency, and cache memory. ■ Active Processor Cores Change the active processor cores.

  • Page 88: Thermal Configuration

    ■ Limit CPUID Maximum This option is only useful if you are using an operating system that does not recognize all of the features of your processor. Allows user to determine whether to limit CPUID maximum value. Set this item to Disabled: For Windows XP operating system.

  • Page 89: Sata Configuration

    ■ Passive Trip Point Allows user to set the CPU temperature threshold. If the CPU temperature reaches this value, the CPU frequency will be automatically reduced. This item is configurable only when DTS is enabled. ■ DTS Enables or disables the CPU overheating protection function. (Default: Disabled) 4.3.7 SATA Configuration ■...

  • Page 90: Os Selection

    4.3.8 OS Selection This allows you to configure Windows OS version to install. The purpose of this is to enable USB 3.0 controller interface. If you set Windows 7 and install the OS, you will need to install USB 3.0 driver at the OS level to fully support USB 3.0 interfaces. If you set Windows 8.x and install it or later OS, the Windows OS will easily support USB 3.0 interfaces.

  • Page 91: Usb Configuration

    ■ CSM Support Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■ Boot option filter Allows user to select which type of operating system to boot. UEFI and Legacy: Allows booting from operating systems that support legacy option ROM or UEFI option ROM.
  • Page 92 ■ Legacy USB Support Allows USB keyboard/ mouse to be used in MS-DOS. ■ XHCI Hand-off Determines whether to enable XHCI (USB3.0) Hand-off feature for an operating system without XHCI (USB3.0) Hand-off support. ■ EHCI Hand-off Determines whether to enable EHCI Hand-off feature for an operating system without EHCI Hand-off support.

  • Page 93: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics-related configuration options. ■ Intel IGD Configuration This section provides onboard graphics-related configuration options. P1000 Series | User Manual CV-100/...
  • Page 94 ❑ GOP Driver This item will allow users to enable or disable GOP Driver. ❑ Integrated Graphics Device This item will allow users to enable or disable Integrated Graphics Device. ❑ IGD Turbo Enable This item will allow users to enable or disable IGD Turbo. ❑...

  • Page 95: South Bridge

    4.4.2 South Bridge ■ Azalia HD Audio Control detection of the Azalia device. ❑ Audio Controller Enabled: Azalia will be unconditionally enabled. Disabled: Azalia will be unconditionally disabled. ■ USB Configuration ❑ XHCI Mode This setting disables/enables the USB XHCI controller. The eXtensible Host Controller Interface (XHCI) is a computer interface specification that defines a register-level description of a Host Controller for Universal Serial Bus (USB), which is capable of interfacing to USB 1.0, 2.0, and 3.0 compatible devices.
  • Page 96 ❑ USB Port 3 This item will allow users to enable or disable USB Port 3. ■ Wake On LAN Enable This item enables or disables Wake On LAN (WOL) function. ■ PCI Express Configuration ❑ PCI Express Port 0 This item will allow users to enable or disable PCI Express Port 0.

  • Page 97: Security Setup

    This setting specifies whether your system will reboot after a power failure or interrupt occurs. Available settings are: Power Off: Leave the computer in the power off state. Power On: Leave the computer in the power on state. Last State: Restore the system to the previous status before power failure or interrupt occurred.

  • Page 98: Boot Setup

    4.6 Boot Setup This section allows you to configure Boot settings. 4.6.1 Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. 4.6.2 Bootup NumLock State Allows users to select the power-on state for keyboard NumLock. 4.6.3 Full Screen Logo Show This item allows user to enable or disable full screen logo show.

  • Page 99: Save & Exit

    4.7 Save & Exit 4.7.1 Save Changes and Reset This item allows user to reset system setup after saving changes. 4.7.2 Discard Changes and Reset This item allows users to reset system setup without saving any changes. 4.7.3 Restore Defaults This item allows user to restore/ load default values for all the options.

  • Page 100: Chapter 5 Product Application

    Chapter 5 Product Application P1000 Series | User Manual CV-100/...

  • Page 101: Digital I/O (Dio) Application

    This section describes DIO application of the product. The content and application development are better understood and implemented by well experienced professionals or developers. 5.1.1 Digital I/O Programming Guide 5.1.1.1 Pins for Digital I/O of Cincoze P1001 series product Item Standard GPIO74 (Pin107)
  • Page 102 -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. P1000 Series | User Manual CV-100/...
  • Page 103 5.1.1.4 Sample Code in C Language 5.1.1.4.1 Control of GP74 to GP77 (DI1 ~ DI4) #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h...
  • Page 104 <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) 5.1.1.4.2 Control of GP80 to GP83 (DO1 ~ DO4) #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(DataPort, 0x06) // Select logic device 06h...
  • Page 105 5.1.1.5 Change base address - DIO base address (Cincoze default 0xA00) <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h...
  • Page 106 5.1.1.6 DATA Bit Table (DIO) 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0 = DI1 = DO1 0 0 0 1 - - - - value - - - - 0 0 0 1 value 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0...

  • Page 107: Digital I/O (Dio) Hardware Specification

    5.2 Digital I/O (DIO) Hardware Specification XCOM+: Isolated power in V+ ⚫ XCOM-: Isolated power in V- ⚫ Isolated power in DC voltage: 9~30V ⚫ 4x Digital Input (Source Type) ⚫ Input Signal Voltage Level ⚫ Signal Logic 0: XCOM+ = 9V, Signal Low <...
  • Page 108 P1000 Series | User Manual CV-100/...
  • Page 109 © 2020 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.

This manual is also suitable for:
