  • Page 1 CV-100/P2102 Series User Manual Industrial Panel PC High Performance Modular Panel PC Version: V1.08...

  • Page 2: Table Of Contents

    Contents Preface ..............................5 Revision ............................5 Copyright Notice ..........................5 Acknowledgement ......................... 5 Disclaimer ............................5 Declaration of Conformity ......................5 Product Warranty Statement ......................6 Technical Support and Assistance ....................7 Conventions Used in this Manual ....................8 Safety Precautions ..........................
  • Page 3 Chapter 3 System Setup ........................67 3.1 Removing Top Cover....................... 68 3.2 Installing Half Size Mini PCIe Card ..................69 3.3 Installing Full Size Mini PCIe Card ..................70 3.4 Installing M.2 E Key Card ......................71 3.5 Installing Antenna(s) ......................72 3.6 Installing SO-DIMM Memory ....................
  • Page 4 5.1.1 Digital I/O Programming Guide ................. 114 5.2 P2102 Digital I/O (DIO) Hardware Specification ..............121 5.2.1 P2102 DIO Connector Definition ................122 Chapter 6 Optional Modules & Accessories ..................124 6.1 Pin Definition and Settings of IGN Module ................125 6.2 Installing CFM-IGN Module ....................

  • Page 5: Preface

    2023/04/14 Copyright Notice © 2020 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 6: Product Warranty Statement

    (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain a RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service.

  • Page 7: Technical Support And Assistance

    Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.

  • Page 8: Conventions Used In This Manual

    Conventions Used in this Manual Safety Precautions Before installing and using this device, please note the following precautions. Read these safety instructions carefully. Keep this User’s Manual for future reference. Disconnected this equipment from any AC outlet before cleaning. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
  • Page 9 12. Never pour any liquid into an opening. This may cause fire or electrical shock. 13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel. If one of the following situations arises, get the equipment checked by service personnel: ⚫...

  • Page 10: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Panel PC Thermal Pad (for CPU Thermal Block) Power Terminal Block Connector Remote Power On/Off Terminal Block Connector DIO Terminal Block Connector Screws Pack PCI / PCIe Card Installation Kit (For CV-100/P2102E Only)
  • Page 11 12.1” XGA TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel CV-112HC/P2102E-i3 Core i3-8145UE Dual Core Processor and P-Cap. Touch 15" XGA TFT-LCD Modular Panel PC with 8th Gen. Intel Core i5-8365UE CV-115R/P2102-i5 Quad Core Processor and Resistive Touch 15”...
  • Page 12 15.6" WXGA TFT-LCD Modular Panel PC with 8th Gen. Intel Core i3-8145UE CV-W115C/P2102-i3 Dual Core Processor and P-Cap. Touch 15.6” WXGA TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel CV-W115C/P2102E-i3 Core i3-8145UE Dual Core Processor and P-Cap. Touch 17"...
  • Page 13 19” SXGA TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel CV-119R /P2102E-i5 Core i5-8365UE Quad Core Processor and Resistive Touch 19" SXGA TFT-LCD Modular Panel PC with 8th Gen. Intel Core i5-8365UE CV-119C/P2102-i5 Quad Core Processor and P-Cap. Touch 19”...
  • Page 14 21.5" Full HD TFT-LCD Modular Panel PC with 8th Gen. Intel Core i5-8365UE CV-W121G/P2102-i5 Quad Core Processor and Glass Only 21.5" Full HD TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel CV-W121G/P2102E-i5 Core i5-8365UE Quad Core Processor and Glass Only 21.5"...
  • Page 15 24" Full HD TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel CV-W124R/P2102E-i3 Core i3-8145UE Dual Core Processor and Resistive Touch 24" Full HD TFT-LCD Modular Panel PC with 8th Gen. Intel Core i3-8145UE CV-W124C/P2102-i3 Dual Core Processor and P-Cap. Touch 24"...

  • Page 16: Chapter 1 Product Introductions

    Chapter 1 Product Introductions CV-100- P2102 Series | User Manual...

  • Page 17: Overview

    Slim Design with Multiple Functions (CV-100/P2102 Series) The CV-100/P2102 series is designed at a slim height and provides a wall-mount kit for easy installation in any space limited environment. Furthermore, a variety of I/O, 2x 2.5” SATA 3.0 drive bays, and M.2/mPCIe expansions are also available to fulfill multiple applications.

  • Page 18: Key Features

    1.3 Key Features ⚫ 12.1” ~ 24” TFT LCD with Resistive 5-wire Touch, Projected Capacitive Touch or Glass Only (Available on Selected Models) ⚫ Onboard 8th Generation Intel® Core™ U Series Processor ⚫ 2x DDR4 SO-DIMM Socket, Supports Up to 2400MHz, 64GB ⚫...

  • Page 19: Hardware Specification

    1.4 Hardware Specification 1.4.1 CV-112H/P2102 Series The table on this page refers to the specifications of CV-112H alone Model Name CV-112HR CV-112HC Display • 12.1" (4:3) LCD Size • Max. Resolution 1024 x 768 • 500 Brightness( cd/m2) • Contract Ratio 700 : 1 •...
  • Page 20 Model Name P2102 P2102E System • Onboard 8th Intel® Core™ U Processors (Whiskey Lake) Processor - Intel® Core™ i5-8365UE Quad Core Processor (6M Cache, up to 4.10 GHz) - Intel® Core™ i3-8145UE Dual Core Processor (4M Cache, up to 3.90 GHz) - TDP: 15 W •...
  • Page 21 Model Name P2102 P2102E Expansion • 2x Full-size Mini-PCIe Sockets Mini PCI Express • 1x PCI or 1x PCIe x4 Expansion slot (with PCI Express Optional Riser Card) • 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module M.2 E Key Socket •...
  • Page 22 Model Name P2102 P2102E Reliability & Protection • Yes Reverse Power Input • Protection Range: 51-58V Over Voltage Protection • Protection Type: shut down operating voltage, • re-power on at the present level to recover • 15A Over Current Protection •...
  • Page 23 Dimensions CV-112H/P2102 CV-112H/P2102E CV-100- P2102 Series | User Manual...

  • Page 24: Cv-115/P2102 Series

    1.4.2 CV-115/P2102 Series The table on this page refers to the specifications of CV-115 alone Model Name CV-115R CV-115C Display • 15" (4:3) LCD Size • Max. Resolution 1024 x 768 • 350 Brightness( cd/m2) • Contract Ratio 800 : 1 •...
  • Page 25 Model Name P2102 P2102E System • Onboard 8th Intel® Core™ U Processors (Whiskey Lake) Processor - Intel® Core™ i5-8365UE Quad Core Processor (6M Cache, up to 4.10 GHz) - Intel® Core™ i3-8145UE Dual Core Processor (4M Cache, up to 3.90 GHz) - TDP: 15 W •...
  • Page 26 Model Name P2102 P2102E Expansion • 2x Full-size Mini-PCIe Sockets Mini PCI Express • 1x PCI or 1x PCIe x4 Expansion slot (with PCI Express Optional Riser Card) • 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module M.2 E Key Socket •...
  • Page 27 Model Name P2102 P2102E Reliability & Protection • Yes Reverse Power Input • Protection Range: 51-58V Over Voltage Protection • Protection Type: shut down operating voltage, • re-power on at the present level to recover • 15A Over Current Protection •...
  • Page 28 Dimensions CV-115/P2102 CV-115/P2102E CV-100- P2102 Series | User Manual...

  • Page 29: Cv-W115/P2102 Series

    1.4.3 CV-W115/P2102 Series The table on this page refers to the specifications of CV-W115 alone Model Name CV-W115R CV-W115C Display • 15.6" (16:9) LCD Size • Max. Resolution 1366 x 768(WXGA) • 400 Brightness( cd/m2) • Contract Ratio 500 : 1 •...
  • Page 30 Model Name P2102 P2102E System • Onboard 8th Intel® Core™ U Processors (Whiskey Lake) Processor - Intel® Core™ i5-8365UE Quad Core Processor (6M Cache, up to 4.10 GHz) - Intel® Core™ i3-8145UE Dual Core Processor (4M Cache, up to 3.90 GHz) - TDP: 15 W •...
  • Page 31 Model Name P2102 P2102E Expansion • 2x Full-size Mini-PCIe Sockets Mini PCI Express • 1x PCI or 1x PCIe x4 Expansion slot (with PCI Express Optional Riser Card) • 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module M.2 E Key Socket •...
  • Page 32 Model Name P2102 P2102E Reliability & Protection • Yes Reverse Power Input • Protection Range: 51-58V Over Voltage Protection • Protection Type: shut down operating voltage, • re-power on at the present level to recover • 15A Over Current Protection •...
  • Page 33 Dimensions CV-W115/P2102 CV-W115/P2102E CV-100- P2102 Series | User Manual...

  • Page 34: Cv-117/P2102 Series

    1.4.4 CV-117/P2102 Series The table on this page refers to the specifications of CV-117 alone Model Name CV-117R CV-117C CV-117G Display • 17" (5:4) LCD Size • Max. Resolution 1280 x 1024 • 350 Brightness( cd/m2) • Contract Ratio 800 : 1 •...
  • Page 35 Model Name P2102 P2102E System • Onboard 8th Intel® Core™ U Processors (Whiskey Lake) Processor - Intel® Core™ i5-8365UE Quad Core Processor (6M Cache, up to 4.10 GHz) - Intel® Core™ i3-8145UE Dual Core Processor (4M Cache, up to 3.90 GHz) - TDP: 15 W •...
  • Page 36 Model Name P2102 P2102E Expansion • 2x Full-size Mini-PCIe Sockets Mini PCI Express • 1x PCI or 1x PCIe x4 Expansion slot (with PCI Express Optional Riser Card) • 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module M.2 E Key Socket •...
  • Page 37 Model Name P2102 P2102E Reliability & Protection • Yes Reverse Power Input • Protection Range: 51-58V Over Voltage Protection • Protection Type: shut down operating voltage, • re-power on at the present level to recover • 15A Over Current Protection •...
  • Page 38 Dimensions CV-117/P2102 CV-117/P2102E CV-100- P2102 Series | User Manual...

  • Page 39: Cv-119/P2102 Series

    1.4.5 CV-119/P2102 Series The table on this page refers to the specifications of CV-119 alone Model Name CV-119R CV-119C CV-119G Display • 19" (5:4) LCD Size • Max. Resolution 1280 x 1024 • 350 Brightness( cd/m2) • Contract Ratio 1000 : 1 •...
  • Page 40 Model Name P2102 P2102E System • Onboard 8th Intel® Core™ U Processors (Whiskey Lake) Processor - Intel® Core™ i5-8365UE Quad Core Processor (6M Cache, up to 4.10 GHz) - Intel® Core™ i3-8145UE Dual Core Processor (4M Cache, up to 3.90 GHz) - TDP: 15 W •...
  • Page 41 Model Name P2102 P2102E Expansion • 2x Full-size Mini-PCIe Sockets Mini PCI Express • 1x PCI or 1x PCIe x4 Expansion slot (with PCI Express Optional Riser Card) • 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module M.2 E Key Socket •...
  • Page 42 Model Name P2102 P2102E Reliability & Protection • Yes Reverse Power Input • Protection Range: 51-58V Over Voltage Protection • Protection Type: shut down operating voltage, • re-power on at the present level to recover • 15A Over Current Protection •...
  • Page 43 Dimensions CV-119/P2102 CV-119/P2102E CV-100- P2102 Series | User Manual...

  • Page 44: Cv-W121/P2102 Series

    1.4.6 CV-W121/P2102 Series The table on this page refers to the specifications of CV-W121 alone Model Name CV-W121R CV-W121C CV-W121G Display • 21.5" (16:9) LCD Size • Max. Resolution 1920 x 1080 • 350 Brightness( cd/m2) • Contract Ratio 5000 : 1 •...
  • Page 45 Model Name P2102 P2102E System • Onboard 8th Intel® Core™ U Processors (Whiskey Lake) Processor - Intel® Core™ i5-8365UE Quad Core Processor (6M Cache, up to 4.10 GHz) - Intel® Core™ i3-8145UE Dual Core Processor (4M Cache, up to 3.90 GHz) - TDP: 15 W •...
  • Page 46 Model Name P2102 P2102E Expansion • 2x Full-size Mini-PCIe Sockets Mini PCI Express • 1x PCI or 1x PCIe x4 Expansion slot (with PCI Express Optional Riser Card) • 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module M.2 E Key Socket •...
  • Page 47 Model Name P2102 P2102E Reliability & Protection • Yes Reverse Power Input • Protection Range: 51-58V Over Voltage Protection • Protection Type: shut down operating voltage, • re-power on at the present level to recover • 15A Over Current Protection •...
  • Page 48 Dimensions CV-W121/P2102 CV-W121/P2102E CV-100- P2102 Series | User Manual...

  • Page 49: Cv-W124/P2102 Series

    1.4.7 CV-W124/P2102 Series The table on this page refers to the specifications of CV-W124 alone. Model Name CV-W124R CV-W124C CV-W124G Display • 24" (16:9) LCD Size • Max. Resolution 1920 x 1080 • 350 Brightness (cd/m2) • Contract Ratio 5000 : 1 •...
  • Page 50 Model Name P2102 P2102E System • Onboard 8th Intel® Core™ U Processors (Whiskey Lake) Processor - Intel® Core™ i5-8365UE Quad Core Processor (6M Cache, up to 4.10 GHz) - Intel® Core™ i3-8145UE Dual Core Processor (4M Cache, up to 3.90 GHz) - TDP: 15 W •...
  • Page 51 Model Name P2102 P2102E Expansion • 2x Full-size Mini-PCIe Sockets Mini PCI Express • 1x PCI or 1x PCIe x4 Expansion slot (with PCI Express Optional Riser Card) • 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module M.2 E Key Socket •...
  • Page 52 Model Name P2102 P2102E Reliability & Protection • Yes Reverse Power Input • Protection Range: 51-58V Over Voltage Protection • Protection Type: shut down operating voltage, • re-power on at the present level to recover • 15A Over Current Protection •...
  • Page 53 Dimensions CV-W124/P2102 CV-W124/P2102E CV-100- P2102 Series | User Manual...

  • Page 54: System I/O

    1.5 System I/O 1.5.1 Front Antenna Hole Clear CMOS Used to connect an antenna for optional wireless Used to clear CMOS to reset BIOS module Removable HDD SIM Card Used to insert a 2.5” SATA HDD/SSD Used to insert a SIM card Power LED IGN Switch Indicates the power status of the system...

  • Page 55: Left

    CV-100/P2102 CV-100/P2102E 1.5.3 Left Antenna Hole COM Port Used to connect an antenna for optional wireless Used to connect to RS-232/422/485 serial devices module USB 2.0 Used to connect to USB 2.0/1.1 compatible devices CV-100/P2102 CV-100/P2102E 1.5.4 Right COM Port OSD Function (For CDS Display Module) Used to connect to RS-232/422/485 serial devices...

  • Page 56: Top

    1.5.5 Top VESA Mounting Hole These are mounting holes for VESA mount (75x75mm and 100x100mm) CV-100/P2102 CV-100/P2102E CV-100- P2102 Series | User Manual...

  • Page 57: Chapter 2 Switches & Connectors

    Chapter 2 Switches & Connectors CV-100- P2102 Series | User Manual...

  • Page 58: Location Of Switches And Connectors

    2.1 Location of Switches and Connectors 2.1.1 Top View 2.1.2 Bottom View CV-100- P2102 Series | User Manual...

  • Page 59: Switches And Connectors Definition

    2.2 Switches and Connectors Definition List of Switch Location Definition AT_ATX1 AT / ATX Power Mode Switch BL_PWR1 Backlight Power on / off switching BL_UP1 Backlight Increase BL_DN1 Backlight Decrease LED1 HDD / Power Access LED Status PWR_SW2 Power button RTC2 Clear COMS Switch Reset1...

  • Page 60: Definition Of Switches

    2.3 Definition of Switches AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Left) AT Power Mode 2-3 (Right) ATX Power Mode (Default) BL_PWR1: Backlight Power on / off Switch Definition Push Backlight Power on / off switching BL_UP1: Backlight Increase Switch Definition Push...
  • Page 61 RTC2：Clear CMOS Switch Switch Definition 1-2 (Left) No Operation (Default) 2-3 (Right) Clear CMOS RESET1: Reset Switch Switch Definition Push Reset System SW1: COM1~4 with Power Select Switch Location Function DIP1 DIP2 0V(RI) ON (Default) ON (Default) COM1 Location Function DIP3 DIP4 0V(RI)

  • Page 62: Definition Of Connectors

    SW2: Super CAP Switch Location Function DIP1 DIP2 Super CAP Enabled ON (Default) OFF (Default) Super CAP Disabled 2.4 Definition of Connectors COM1 / COM2 / COM3/ COM4: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition...
  • Page 63 CN1： Mini PCI-Express Socket (Support mPCIE & SIM Module & USB) Definition Definition WAKE# 3.3V +1.5V SMB_CLK PETN0(USB3TN0)/SATATN0 1.5V SMB_DATA CLKREQ# PETP0(USB3TP0)/SATATP0 SIM_VCC SIM_DATA USB_D- REFCLK- RESERVED SIM_CLK USB_D+ REFCLK+ RESERVED SIM_Reset 3.3V SIM_VPP 3.3V PERST# +1.5V PERN0(USB3RN0)/SATARP0 3.3V PERP0(USB3RP0)/SATARN0 +3.3V CV-100- P2102 Series | User Manual...
  • Page 64 CN2： Mini PCI-Express Socket (Support mPCIE & USB) Definition Definition WAKE# 3.3V +1.5V SMB_CLK PETN0/SATATN0 1.5V SMB_DATA CLKREQ# PETP0/SATATP0 USB_D- REFCLK- USB_D+ REFCLK+ 3.3V 3.3V 3.3V PERST# +1.5V PERN0/SATARP0 +3.3VAUX PERP0/SATARN0 +3.3V CV-100- P2102 Series | User Manual...
  • Page 65 CN3： M.2 Key E Socket (Support M.2 PCIE / Intel CNVi ) Definition Definition Definition +3.3V PULL-UP USB_D+ PEWAKE0# +3.3V USB_D- RGI_DT I2C_DATA WTD1N/PETP1 PCM_CLK RGI_RSP I2C_CLK WGR_D1N PETP0 WTD1P/PETN1 RBI_DT PCM_SYNC/LPCRSTN WGR_D1N PETN0 PCM_IN CLINK_REST REF_CLK WTD0N/PETP1 PCM_OUT CLINK_DATA WGR_D0N PERP0 WTD0P/PERN1...
  • Page 66 DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~48VIN Ignition (IGN) Please disconnect the power source before mounting the DC power cables or connecting the DC power connector to system. LAN1 / LAN2 LED： LAN1 / 2 LED Status Definition LAN LED Status Definition...

  • Page 67: Chapter 3 System Setup

    Chapter 3 System Setup CV-100- P2102 Series | User Manual...

  • Page 68: Removing Top Cover

    This chapter takes P2102 as an example to demonstrate the installation of hardware components, except for chapter 3.7. 3.1 Removing Top Cover 1. Loosen the eight screws at front and rear panel. 2. Raise the edge of top cover (1), and raise the other side (2) subsequently to remove it from the chassis.

  • Page 69: Installing Half Size Mini Pcie Card

    3.2 Installing Half Size Mini PCIe Card Locate the Mini PCIe socket on the system board. Use two screws provided on adapter bracket to fasten the card and bracket together. Tilt the Mini PCIe card at a 45-degree angle and insert it into the socket until the golden finger connector of the card seated firmly.

  • Page 70: Installing Full Size Mini Pcie Card

    Press down the card and secure it with two screws. 3.3 Installing Full Size Mini PCIe Card 1. Locate the Mini PCIe slot on the system board. 2. Tilt the Mini PCIe card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly.

  • Page 71: Installing M.2 E Key Card

    3. Press the card down and secure it with 2 screws. 3.4 Installing M.2 E Key Card 1. Locate the M.2 E Key slot on the system board. 2. Tilt the M.2 E Key card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly.

  • Page 72: Installing Antenna(S)

    3. Press the card down and secure it with 1 screw. 3.5 Installing Antenna(s) 1. Remove the antenna rubber cover on front, left or right panel. 2. Penetrate the antenna jack through the hole. CV-100- P2102 Series | User Manual...
  • Page 73 3. Put on the washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together. Attach the RF connector at another end of the cable onto the card. CV-100- P2102 Series | User Manual...

  • Page 74: Installing So-Dimm Memory

    3.6 Installing SO-DIMM Memory 1. Locate the SO-DIMM socket on the system board. 2. Tilt the memory module at a 45-degree angle, and insert it into SO-DIMM socket until the golden finger connector of the module is seated firmly. 3. Press down the memory module until retaining clips snap back in place. CV-100- P2102 Series | User Manual...

  • Page 75: Installing Pci(E) Card

    4. For the upper SO-DIMM socket, please follow the same steps described earlier to install. 3.7 Installing PCI(e) Card This chapter takes P2102E for example to demonstrate the installation steps. 1. Loosen the two screws as indicated at rear panel. 2.
  • Page 76 3. Loosen the screw as indicated to remove the PCI bracket. 4. Align the notch of golden fingers of Riser card(Optional) with the slot. Insert the card vertically, and press the card straight down into the slot until it’s seated firmly. 5.
  • Page 77 6. Fasten the screw back to secure the PCI(e) expansion card. 7. Locate the retention module of PCI(e) expansion card. 8. Loosen the two screw as indicated to have the clamp arm slidable. CV-100- P2102 Series | User Manual...
  • Page 78 9. Slide the clamp arm of retention module until it contacts the edge of PCI(e) expansion card. 10. Finally, fasten the two screws that were previously loosen halfway to fix the retention module. CV-100- P2102 Series | User Manual...

  • Page 79: Installing Thermal Pad Of Thermal Block

    3.8 Installing Thermal Pad of Thermal Block 1. Place thermal pad on the top of CPU thermal block in order to provide a seamless contact with the body of chassis to create an efficient heat dissipation. Before assembling the system’s chassis cover, please make sure the protective film on the Thermal Pad has been removed! 3.9 Installing Top Cover 1.

  • Page 80: Installing Sata Hard Drive At Front Panel

    2. Fasten the eight screws at front and rear panel to secure the top cover. 3.10 Installing SATA Hard Drive at Front Panel 1. Turn over the system to bottom side, and remove the screw. 2. Loosen the screw to remove the HDD bay cover bracket. CV-100- P2102 Series | User Manual...
  • Page 81 3. Pull the rotating arm of HDD bracket outward as indicated. 4. Hold the rotating arm to pull out the HDD bracket. CV-100- P2102 Series | User Manual...
  • Page 82 5. Place the HDD bracket on screw-hole side of HDD. Use four screws provided to assemble HDD on the bracket. 6. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket and push it until the edge connector of HDD fully inserted into SATA slot. 7.

  • Page 83: Installing Sata Hard Drive On Bottom Side

    8. Fasten the screw to secure the HDD bracket on the system chassis. 3.11 Installing SATA hard drive on Bottom Side 1. Turn over the system to bottom side. Locate the cover of HDD compartment. CV-100- P2102 Series | User Manual...
  • Page 84 2. Loosen the two screws, lift the cover, and then remove it. 3. Loosen three screws and take the HDD bracket out of HDD compartment. 4. Place the HDD bracket on screw-hole side of HDD. Use four screws provided to assemble HDD on the bracket.
  • Page 85 5. Seat the HDD bracket into HDD compartment, and line up the connector of HDD with SATA slot, then push it until HDD is fully connected into slot. 6. Secure the HDD bracket with three screws. 7. Put back the cover and fasten the two screws. CV-100- P2102 Series | User Manual...

  • Page 86: Installing Sim Card

    3.12 Installing SIM Card 1. Loosen the screw to remove the Maintenance cover bracket. 2. Locate the SIM card slot. 3. Insert the SIM card. CV-100- P2102 Series | User Manual...

  • Page 87: Connecting With Cv Display Module

    3.13 Connecting with CV Display Module 1. Prepare the mounting kit that accompanied with P2102 as shown below. (including two mounting brackets and one screw pack) 2. Remove the six screws at left and right panel. 3. Assemble two mounting brackets by fastening six screws from the screws pack. CV-100- P2102 Series | User Manual...
  • Page 88 4. Turn over the system to bottom side. Locate the connector cover of display module. 5. Loosen two screws to remove the cover. The following photos indicates the male connector (on display module) and female connector (on P2102). CV-100- P2102 Series | User Manual...
  • Page 89 6. Place the P2102 on the display module through its display connector hole as indicated. 7. Align the mounting holes of P2102 with the screw holes of display module underneath. Then slide the PC2100 carefully as indicated to have P2102 and display module connected together. 8.

  • Page 90: Installing Panel Mount

    3.14 Installing Panel Mount 1. Accessories provided by Cincoze are as below. (Please note that the quantity of mounting kits varies with the size of the display module, please refer to the datasheet for the actual quantity) CV-100- P2102 Series | User Manual...
  • Page 91 2. All mounting kits displayed are to be inserted into holes. 3. Installation preparation and steps. CV-100- P2102 Series | User Manual...
  • Page 92 CV-100- P2102 Series | User Manual...
  • Page 93 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below. CV-100- P2102 Series | User Manual...

  • Page 94: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup CV-100- P2102 Series | User Manual...

  • Page 95: Bios Introduction

    4.1 BIOS Introduction The BIOS (Basic Input/ Output System) is a program located on a Flash Memory on the motherboard. When you start the computer, the BIOS program will gain control. The BIOS first operates an auto-diagnostic test called POST (power on self-test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 96: Advanced Setup

    Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 4.2.1 System Date Set the date. Please use <Tab> to switch between date elements. 4.2.2 System Time Set the time.

  • Page 97: Cpu Configuration

    4.3.1 CPU Configuration ■ Intel® Virtualization Technology [Enabled] Enables or disables Intel® Virtualization Technology. Virtualization enhanced by Intel® Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple virtual systems. ■...

  • Page 98: Trusted Computing

    ■ Intel AMT [Enabled] Allows you to enable or disable Intel® Active Management Technology BIOS execution. ■ Firmware Update Configuration ❑ ME FW Image Re-Flash [Disabled] Allows you to enable or disable ME firmware image re-flash function. 4.3.3 Trusted Computing CV-100- P2102 Series | User Manual...

  • Page 99: Acpi Settings

    ■ Security Device Support [Disable] Allow you to enables or disables Security Device Support function. 4.3.4 ACPI Settings This item allows users to configure ACPI settings. ■ Enable ACPI Auto Configuration [Enabled] Enables or disables BIOS Advanced Configuration Power Interface® (ACPI) auto configuration. ■...

  • Page 100: F81866 Super Io Configuration

    [Suspend Disabled]: Disables entering suspend state. [S3 (suspend to RAM)]: Enables suspend to RAM state. 4.3.5 F81866 Super IO Configuration The screen allows users to select options for the Super IO configuration, and change the value of the selected option. ■...

  • Page 101: Hardware Monitor

    This item allows users to change the address & IRQ settings of the specified serial port. ❑ Onboard Serial Port 1 Mode [RS232] This item allows users to select Serial Port Mode. Configuration options: [RS232] [RS422/RS485 Full Duplex] [RS485 Half Duplex] ■...

  • Page 102: Serial Port Console Redirection

    ■ Wake System from S5 [Disabled] This item allows users to change the way to wake system from S5 state. [Fixed Time]: Set the specified time (HH:MM:SS) to wake system. [Dynamic Time]: Set the increase time from current time to wake system. 4.3.8 Serial Port Console Redirection ■...

  • Page 103: Csm Configuration

    ■ Legacy USB Support [Enabled] This item allows users to enable or disable legacy USB support. When set to [Auto], legacy USB support will be disabled automatically if no USB devices are connected. ■ XHCI Hand-off [Enabled] This item allows users to enable or disable XHCI (USB3.2) hand-off function. ■...

  • Page 104: Nvme Configuration

    This item allows users to enable or disable UEFI Compatibility Support Module (CSM) to support a legacy PC boot process. 4.3.11 NVMe Configuration The screen allows users to select options for the NVMe configuration, and change the value of the selected option.

  • Page 105: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 System Agent (SA) Configuration ■ Memory Configuration This item displays detailed memory information in the system. CV-100- P2102 Series | User Manual...

  • Page 106: Pch-Io Configuration

    ■ Graphics Configuration ❑ Primary Display [Auto] Allows users to select which graphics device should be primary display or select SG for switchable graphics. Configuration options: [Auto] [IGFX] [PEG] [PCIe] [SG] ❑ Internal Graphics [Auto] This item allows users to enable or disable Internal Graphics. When set to [Auto], it will detect by BIOS.
  • Page 107 ■ PCI Express Configuration ❑ PCI Express Root Port (CN1 mPCIe) ◼ PCI Express Root Port [Enabled] Allows you to enable or disable the PCI Express Port. ◼ PCIe Speed [Auto] Allows you to select PCI Express interface speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. ❑...
  • Page 108 ■ SATA Configuration ❑ SATA Controller(s) [Enabled] Enables or disables Serial ATA controller. ❑ SATA Mode [AHCI] This item allows users to choose [AHCI] or [RAID] mode. ❑ Serial ATA Port 0 Port 0 [Enabled] Enables or disables SATA Port 0. ❑...
  • Page 109 ❑ HD Audio [Enabled] Allows you to select HD Audio options. [Enabled]: HD Audio device is unconditionally enabled. [Disabled]: HD Audio device is unconditionally disabled. ■ LAN i219LM Controller [Enabled] Enables or disables i219LM LAN Controller. ■ Wake On LAN (i219) [Enabled] Enables or disables integrated LAN i219LM Wake On LAN function.

  • Page 110: Security Setup

    4.5 Security Setup This section allows users to configure BIOS security settings. ◼ Administrator Password Administrator Password controls access to the BIOS Setup utility. ◼ User Password User Password controls access to the system at boot and to the BIOS Setup utility. ◼...

  • Page 111: Boot Setup

    4.6 Boot Setup This section allows you to configure Boot settings. ◼ Setup Prompt Timeout [1] Use this item to set number of seconds (1..65535) to wait for setup activation key. ◼ Bootup NumLock State [Off] Allows you to select the power-on state for keyboard NumLock. ◼...

  • Page 112: Save & Exit

    4.7 Save & Exit ◼ Save Changes and Exit This item allows you to exit system setup after saving changes. ◼ Discard Changes and Exit This item allows you to exit system setup without saving changes. ◼ Save Changes and Reset This item allows you to reset the system after saving changes.

  • Page 113: Chapter 5 Product Application

    Chapter 5 Product Application CV-100- P2102 Series | User Manual...

  • Page 114: Digital I/O (Dio) Application

    5.1 Digital I/O (DIO) application This section describes DIO application of the product. The content and application development are better understood and implemented by well experienced professionals or developers. 5.1.1 Digital I/O Programming Guide 5.1.1.1 Pins for Digital I/O Item Standard GPIO70 (Pin103) GPIO71 (Pin104)
  • Page 115 To program the Super I/O chip F81866A configuration registers, the following configuration procedures must be followed in sequence: (1) Enter the Extended Function Mode (2) Configure the configuration registers (3) Exit the Extended Function Mode The configuration register is used to control the behavior of the corresponding devices. To configure the register, use the index port to select the index and then write data port to alter the parameters.
  • Page 116 CV-100- P2102 Series | User Manual...
  • Page 117 5.1.1.4 Sample Code in C Language 5.1.1.4.1 Control of GP70 to GP77 #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h <Output/Input Mode Selection>...
  • Page 118 5.1.1.4.2 Control of GP80 to GP87 #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(DataPort, 0x06) // Select logic device 06h <Output/Input Mode Selection>...
  • Page 119 // Select configuration register 60h WriteByte(DataPort, (ReadByte(DataPort) ǀ 0x03)) WriteByte(AddrPort, 0x61) // Select configuration register 61h WriteByte(DataPort, (ReadByte(DataPort) ǀ 0x20)) <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Cincoze default GPIO Port base address is 0xA00h CV-100- P2102 Series | User Manual...
  • Page 120 5.1.1.6 DATA Bit Table (DIO) = DI1 = DO1 = DI2 = DO2 = DI3 = DO3 = DI4 = DO4 = DI5 = DO5 = DI6 = DO6 = DI7 = DO7 = DI8 = DO8 5.1.1.7 DIO I/O Port Address CV-100- P2102 Series | User Manual...

  • Page 121: P2102 Digital I/O (Dio) Hardware Specification

    5.2 P2102 Digital I/O (DIO) Hardware Specification • XCOM+ / 2XCOM+ : Isolated power in V+ • XCOM- / 2XCOM- : Isolated power in V- • Isolated power in DC voltage : 9~30V • 8x / 16x Digital Input (Source Type) •...

  • Page 122: P2102 Dio Connector Definition

    5.2.1 P2102 DIO Connector Definition DIO-1/DIO-2: Digital Input / Output Connector Connector Type: Terminal Block 2X10 10-pin, 3.5mm pitch Location Definition Location Definition DC INPUT DC INPUT DIO-1 DIO-2 CV-100- P2102 Series | User Manual...
  • Page 123 Reference Input Circuit Reference Output Circuit CV-100- P2102 Series | User Manual...

  • Page 124: Chapter 6 Optional Modules & Accessories

    Chapter 6 Optional Modules & Accessories Pin Definitions and Settings CV-100- P2102 Series | User Manual...

  • Page 125: Pin Definition And Settings Of Ign Module

    6.1 Pin Definition and Settings of IGN Module SW2 on CFM-IGN101: IGN Module Timing Setting Switch Set shutdown delay timer when ACC is turned off Pin 1 Pin 2 Pin 3 Pin 4 Definition 0 second 1 minute 5 minutes ON (IGN enabled) 10 minutes 30 minutes...

  • Page 126: Installing Cfm-Ign Module

    6.2 Installing CFM-IGN Module This chapter takes CFM-IGN101 module for example. Locate the power Ignition connector on system motherboard as indicated. Insert the female connector of power ignition board to the male connector on system motherboard. CV-100- P2102 Series | User Manual...

  • Page 127: Installing Cfm-Poe Module

    Fasten two screws to secure the power ignition board. 6.3 Installing CFM-PoE Module This chapter takes CFM-PoE04 module for example. 1. Place a thermal pad on the top of the heatsink, and locate the two regions as marked. 2. Turn over the heatsink and paste the thermal pad at the marked region. Before putting on the thermal block, please make sure the protective film on the Thermal Pad has been removed! CV-100-...
  • Page 128 3. Paste the thermal pad onto the coil of the CFM-PoE module. Locate the PoE connector on system motherboard as indicated. Insert the female connector of PoE daughter board to the male connector on system motherboard. CV-100- P2102 Series | User Manual...
  • Page 129 Put on the PoE thermal block and fasten two screws to secure the PoE board. Before assembling the system’s chassis cover, please make sure the protective films on the Thermal Pads have been removed! CV-100- P2102 Series | User Manual...

  • Page 130: Installing Vesa Mount

    6.4 Installing VESA Mount The following picture indicates VESA mounting hole pattern on P2102, which is compliant with VESA mounting standard. 1. The following picture uses a panel PC (P2102+CV/CS display module) as a demonstration. To attach the panel PC to a VESA stand, please fasten eight screws as indicated to fix it on the stand.
  • Page 131 © 2019 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.

This manual is also suitable for:

Cv-112h/p2102 seriesCv-w115/p2102 seriesCv-115/p2102 seriesCv-117/p2102 seriesCv-119/p2102 seriesCv-w124/p2102 series ... Show all

Table of Contents
