  • Page 1 CV-100/P1001 Series User Manual Industrial Panel PC High Performance Modular Panel PC Version: V2.13...

  • Page 2: Table Of Contents

    1.3.3 CV-110H/P1001 Series ....................24 1.3.4 CV-112H/P1001 Series ....................28 1.3.5 CV-115/P1001 Series ....................32 1.3.6 CV-W115/P1001 Series ..................... 36 1.3.7 CV-W115FH/P1001 Series ..................40 1.3.8 CV-117/P1001 Series ....................44 1.3.9 CV-119/P1001 Series ....................48 1.3.10 CV-W121/P1001 Series ................... 52 1.3.11 CV-W124/P1001 Series ...................
  • Page 3 2.5 Definition of Switches ......................68 2.6 Definition of Connectors ...................... 69 Chapter 3 System Setup ........................75 3.1 Removing the Top Cover ...................... 76 3.2 Installing a Half Size Mini PCIe Card ..................77 3.3 Installing a Full Size Mini PCIe Card ..................78 3.4 Installing Antennas .......................

  • Page 4: Preface

    Add CV-W115FH & CV-115C-AG Display Module 2025/03/26 © 2018 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd.

  • Page 5: Disclaimer

    This manual is intended to be used as a practical and informative guide only and is subject to change without notice. It does not represent a commitment on the part of Cincoze. This product might include unintentional technical or typographical errors. Changes are periodically made to the information herein to correct such errors, and these changes are incorporated into new editions of the publication.

  • Page 6: Technical Support And Assistance

    Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain an RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service. ◼...

  • Page 7: Conventions Used In This Manual

    ⚫ Product name and serial number ⚫ Description of your peripheral attachments ⚫ Description of your software (operating system, version, application software, etc.) ⚫ A complete description of the problem ⚫ The exact wording of any error messages Conventions Used in this Manual This indication alerts operators to an operation that, if not strictly observed, may result in severe injury.
  • Page 8 power cord. 10. All cautions and warnings on the equipment should be noted. 11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage. 12. Never pour any liquid into an opening. This may cause fire or electrical shock. 13.

  • Page 9: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Panel PC Panel Mounting Kit (The quantity varies with the size of the display module, please refer to the datasheet for the actual quantity) DIO Terminal Block Connector Power Terminal Block Connector Screw Pack...
  • Page 10 12.1" TFT XGA 4:3 Panel PC with Resistive 5-wire Touch, w/ CV-112HR/P1001E Intel Atom E3845 Quad Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort and 2x Universal bracket 15" TFT XGA 4:3 Panel PC with Resistive 5-wire Touch, w/ Intel CV-115R/P1001 Atom E3845 Quad Core, 4x USB, 2x COM, 1x VGA and 1x DisplayPort...
  • Page 11 24" TFT Full HD 16:9 Panel PC with Resistive 5-wire Touch and CV-W124R/P1001 Intel® Atom™ E3845 Quad Core PC Module, 4x USB, 2x COM, 1x VGA, 1x DisplayPort 24" TFT Full HD 16:9 Panel PC with Resistive 5-wire Touch and CV-W124R/P1001E Intel®...
  • Page 12 DisplayPort and 2x Universal bracket 15" TFT XGA 4:3 Panel PC with Projected Capacitive Touch, CV-115C-AG/P1001 Anti-Glare Coating, and Intel® Atom E3845 Quad-Core Processor. 15" TFT XGA 4:3 Panel PC with Projected Capacitive Touch, CV-115C-AG/P1001E Anti-Glare Coating, and Intel® Atom E3845 Quad-Core Processor.
  • Page 13 24" TFT Full HD 16:9 Panel PC with Projected Capacitive Touch CV-W124C/P1001 and Intel® Atom™ E3845 Quad Core PC Module, 4x USB, 2x COM, 1x VGA, 1x DisplayPort 24" TFT Full HD 16:9 Panel PC with Projected Capacitive Touch CV-W124C/P1001E and Intel®...

  • Page 14: Chapter 1 Product Introductions

    Chapter 1 Product Introductions CV-100/P1001 Series | User Manual...

  • Page 15: Overview

    1.1 Overview The CV-100/P1000 Series all-in-one panel PC offers LED backlight LCD. It features flat surface and IP65 dust/waterproof front panel. In addition, designed with aluminum die-cast front frame with rugged body structure that can be able to apply in industrial applications. The CV-100/P1000 Series supports Convertible Display System (CDS) technology which makes it more flexible in system maintaining and upgrading.

  • Page 16: Hardware Specification

    1.3 Hardware Specification 1.3.1 CV-108/P1001 Series Model Name CV-108R CV-108C Display • 8.4" (4:3) LCD Size • 800 x 600 Max. Resolution • 400 Brightness (cd/m2) • 600 : 1 Contrast Ratio • 262K LCD Color • 0.213 (H) x 0.213 (V) Pixel Pitch(mm) •...
  • Page 17 • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P1001 P1001E System • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Processor • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) Memory •...
  • Page 18 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 19 Dimension CV-108/P1001 Unit: mm CV-108/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 20: Cv-110/P1001 Series

    1.3.2 CV-110/P1001 Series Model Name CV-110R CV-110C Display • 10.4" (4:3) LCD Size • 800 x 600 Max. Resolution • 400 Brightness (cd/m2) • 700 : 1 Contrast Ratio • 16.2M LCD Color • Pixel Pitch(mm) 0.264 (H) x 0.264 (V) •...
  • Page 21 • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P1001 P1001E System • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Processor • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) Memory • Support up to 8 GB •...
  • Page 22 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 23 Dimension CV-110/P1001 Unit: mm CV-110/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 24: Cv-110H/P1001 Series

    1.3.3 CV-110H/P1001 Series Model Name CV-110HR CV-110HC Display • 10.4" (4:3) LCD Size • Max. Resolution 1024 x 768 • 470 Brightness (cd/m2) • Contrast Ratio 1000 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.2055 (H) x 0.2055 (V) •...
  • Page 25 • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P1001 P1001E System • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Processor • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) Memory • Support up to 8 GB •...
  • Page 26 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 27 Dimension CV-110H/P1001 Unit: mm CV-110H/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 28: Cv-112H/P1001 Series

    1.3.4 CV-112H/P1001 Series Model Name CV-112HR CV-112HC Display • 12.1" (4:3) LCD Size • Max. Resolution 1024 x 768 • 500 Brightness (cd/m2) • Contrast Ratio 700 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.24 (H) x 0.24 (V) •...
  • Page 29 • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P1001 P1001E System • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Processor • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) Memory • Support up to 8 GB •...
  • Page 30 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 31 Dimension CV-112H/P1001 Unit: mm CV-112H/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 32: Cv-115/P1001 Series

    1.3.5 CV-115/P1001 Series Model Name CV-115R CV-115C CV-115C-AG Display • 15" (4:3) LCD Size • Max. Resolution 1024 x 768 • 350 Brightness (cd/m2) • Contrast Ratio 800 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.297 (H) x 0.297 (V) •...
  • Page 33 • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P1001 P1001E System • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Processor • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) Memory • Support up to 8 GB •...
  • Page 34 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 35 Dimension CV-115/P1001 Unit: mm CV-115/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 36: Cv-W115/P1001 Series

    1.3.6 CV-W115/P1001 Series Model Name CV-W115R CV-W115C Display • 15.6" (16:9) LCD Size • Max. Resolution 1366 x 768(WXGA) • 400 Brightness (cd/m2) • Contrast Ratio 500 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.252 (H) x 0.252 (V) •...
  • Page 37 Model Name P1001 P1001E System • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Processor • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) Memory • Support up to 8 GB • AMI 64Mbit SPI BIOS BIOS Graphics •...
  • Page 38 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 39 Dimension CV-W115/P1001 Unit: mm CV-W115/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 40: Cv-W115Fh/P1001 Series

    1.3.7 CV-W115FH/P1001 Series Model Name CV-W115FHR CV-W115FHC Display • 15.6" (16:9) LCD Size • Max. Resolution 1920 x 1080 (Full HD) • 350 Brightness (cd/m2) • Contrast Ratio 800 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.17925 (H) x 0.17925 (V) •...
  • Page 41 Model Name P1001 P1001E System • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Processor • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) Memory • Support up to 8 GB • AMI 64Mbit SPI BIOS BIOS Graphics •...
  • Page 42 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 43 Dimension CV-W115FH/P1001 Unit: mm CV-W115FH/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 44: Cv-117/P1001 Series

    1.3.8 CV-117/P1001 Series Model Name CV-117R CV-117C CV-117G Display • 17" (5:4) LCD Size • Max. Resolution 1280 x 1024 • 350 Brightness (cd/m2) • Contrast Ratio 800 : 1 • 16.2M LCD Color • Pixel Pitch(mm) 0.264 (H) x 0.264 (V) •...
  • Page 45 • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz • UL, cUL, CB, IEC, EN 62368-1 Safety Model Name P1001 P1001E System • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Processor •...
  • Page 46 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 47 Dimension CV-117/P1001 Unit: mm CV-117/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 48: Cv-119/P1001 Series

    1.3.9 CV-119/P1001 Series Model Name CV-119R CV-119C CV-119G Display • 19" (5:4) LCD Size • Max. Resolution 1280 x 1024 • 350 Brightness (cd/m2) • Contrast Ratio 1000 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.294 (H) x 0.294 (V) •...
  • Page 49 Model Name P1001 P1001E System • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Processor • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) Memory • Support up to 8 GB • AMI 64Mbit SPI BIOS BIOS Graphics •...
  • Page 50 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 51 Dimension CV-119/P1001 Unit: mm CV-119/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 52: Cv-W121/P1001 Series

    1.3.10 CV-W121/P1001 Series Model Name CV-W121R CV-W121C CV-W121G Display • 21.5" (16:9) LCD Size • Max. Resolution 1920 x 1080 • 350 Brightness (cd/m2) • Contrast Ratio 5000 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.24825 (H) x 0.24825 (V) •...
  • Page 53 Model Name P1001 P1001E System • Onboard Intel® Atom™ Processor E3845 Quad Core, 1.91 GHz Processor • 1x DDR3L 1066/1333 MHz SO-DIMM Socket (un-buffered and non-ECC ) Memory • Support up to 8 GB • AMI 64Mbit SPI BIOS BIOS Graphics •...
  • Page 54 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 55 Dimension CV-W121/P1001 Unit: mm CV-W121/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 56: Cv-W124/P1001 Series

    1.3.11 CV-W124/P1001 Series Model Name CV-W124R CV-W124C CV-W124G Display • 24" (16:9) LCD Size • Max. Resolution 1920 x 1080 • 350 Brightness (cd/m2) • Contrast Ratio 5000 : 1 • 16.7M LCD Color • Pixel Pitch(mm) 0.27675 (H) x 0.27675 (V) •...
  • Page 57 • EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz •...
  • Page 58 • Operating, 1 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) Vibration * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CV-100/P1001 Series | User Manual...
  • Page 59 Dimension CV-W124/P1001 Unit: mm CV-W124/P1001E Unit: mm CV-100/P1001 Series | User Manual...

  • Page 60: System I/O

    1.4 System I/O 1.4.1 Front ATX Power On/Off CFast and SIM card Slot Used to power-on or power-off the system Used to insert a CFast card and SIM card Antenna Hole Removable HDD Bay Used to connect an antenna for optional wireless Used to insert a 2.5”...

  • Page 61: Rear

    1.4.2 Rear DC IN USB 2.0 port Used to plug a DC power input with terminal block Used to connect USB 2.0/1.1 device Reset Button LAN port Used to reset the system Used to connect the system to a local area network Mic-in Used to connect a microphone Used to connect an analog VGA monitor...

  • Page 62: Left

    1.4.3 Left USB 3.2 GEN1 port Digital I/O Terminal Block Used to connect USB 3.2 GEN1/2.0/1.1 device The Digital I/O terminal block supports 4 digital input USB 2.0 port and 4 digital output AT/ATX mode select switch Used to connect USB 2.0/1.1 device Used to select AT or ATX power mode CV-100/P1001 Series | User Manual...

  • Page 63: Right

    1.4.4 Right COM port OSD Function: COM 2 supports RS232/422/485 serial device LCD On/Off DisplayPort Press to turn-on or turn-off the display Used to connect a DisplayPort devices Increase Brightness Power LED Press to increase brightness of the screen Indicates the power status of the system Decrease Brightness HDD LED Press to decrease brightness of the screen...

  • Page 64: Chapter 2 Jumpers, Switches & Connectors

    Chapter 2 Jumpers, Switches & Connectors CV-100/P1001 Series | User Manual...

  • Page 65: Jumpers Settings

    2.1 Jumpers Settings When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.

  • Page 66: Bottom View

    2.2.2 Bottom View CV-100/P1001 Series | User Manual...

  • Page 67: Definition Of Jumpers/Switches/Connectors

    2.3 Definition of Jumpers/Switches/Connectors List of Jumpers/Switches/Connectors Location Definition AT_ATX1 AT / ATX Power Mode Switch BL_PWR1 Backlight Power on / off switching BL_UP1 Backlight Increase BL_DN1 Backlight Decrease CFAST1 CFast Connector CLR_CMOS1 Clear BIOS Switch COM1_1, COM2_1 RS232 / RS422 / RS485 Connector COM12_SEL1 COM1 / COM2 with Power Select DC_IN1...

  • Page 68: Definition Of Jumpers

    2.4 Definition of Jumpers COM12_SEL1: COM1 / COM2 with Power Select Connector Type: 2X5 10-pin Header, 2.0mm pitch COM1 COM2 Definition Definition 1-3 On 2-4 On 3-5 On +12V 4-6 On +12V 7-9 On 8-10 On Reserved Reserved (Default) (Default) 2.5 Definition of Switches AT_ATX1: AT / ATX Power Mode Switch Definition...

  • Page 69: Definition Of Connectors

    Switch Definition Push Reset System 2.6 Definition of Connectors CFAST1: CFast Connector Definition Definition Definition PC10 SATA_TX2+ PC11 SATA_TX2- PC12 PC13 +3.3V SATA_RX2- PC14 +3.3V SATA_RX2+ PC15 PC16 PC17 COM1~COM2: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 RS485 RS232 Definition...
  • Page 70 DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~48VIN Chassis GND Please disconnect the power source before mounting the DC power cables or connecting the DC power connector to system. DP1: DisplayPort Connector Definition Definition DP_LANE0_P...
  • Page 71 LED1: Power / HDD Access LED Status Definition HDD LED+ HDD LED- POWER LED+ POWER LED- LED Status LED Color Yellow POWER Green LINE_OUT1: Line-out Jack (Green) Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L MIC1: Microphone Jack (Pink) Connector Type: 5-pin Phone Jack Definition MIC_R MIC_L...
  • Page 72 POWER1: Power Connector Connector Type: 1X4-pin Wafer, 2.0mm pitch Definition +12V SATA1: SATA with Power Connector Definition Definition SATA_TX1+ SATA_TX1- SATA_RX1- SATA_RX1+ +3.3V +3.3V +12V +3.3V +12V +12V SIM1：SIM Card Socket Definition UIM_PWR UIM_RESET UIM_CLK UIM_VPP UIM_DATA CV-100/P1001 Series | User Manual...
  • Page 73 SPK_L1: Left Internal Speaker Connector Definition OUT_L SPK_R1: Right Internal Speaker Connector Definition OUT_R USB1_2_1：USB2.0 Connector, Type A Definition Definition USB_DATA0- USB_DATA_1- USB_DATA0+ USB_DATA_1+ USB2_1: USB2.0 Connector, Type A Definition USB2_DATA1- USB2_DATA1+ USB3_1: USB 3.0 Connector, Type A Definition Definition USB3_RX0+ USB2_D0- USB2_D0+...
  • Page 74 MINIPCIE1: Mini PCI-Express Socket Pin Definition Pin Definition Pin Definition WAKE# +3.3V +3.3V USB2_3P +3.3V MINIPCIE RST# MINIPCIE_RXN +3.3V +1.5V +3.3V CLKREQ# MINIPCIE_RXP UIM_PWR UIM_DATA +1.5V MINIPCIE_CLKN UIM_CLK SMB_CLK +1.5V MINIPCIE_CLKP MINIPCIE_TXN UIM_RESET SMB_DATA MINIPCIE_TXP UIM_VPP +3.3V USB2_3N CV-100/P1001 Series | User Manual...

  • Page 75: Chapter 3 System Setup

    Chapter 3 System Setup CV-100/P1001 Series | User Manual...

  • Page 76: Removing The Top Cover

    This chapter takes P1001 as an example to demonstrate the installation of hardware components. 3.1 Removing the Top Cover In order to prevent electric shock or system damage, must turn off power and disconnect the unit from power source before removing the chassis cover. (Afin d'éviter tout risque d'électrocution ou d'endommagement du système, vous devez couper l'alimentation et débrancher l'appareil de la source d'alimentation avant de retirer le couvercle du châssis.)

  • Page 77: Installing A Half Size Mini Pcie Card

    3.2 Installing a Half Size Mini PCIe Card Locate the Mini PCIe slot. Use provided two screws on bracket to fasten the module and bracket together. Tilt the Mini PCIe module at 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot.

  • Page 78: Installing A Full Size Mini Pcie Card

    Press down the module and use the two screws to fix the module. 3.3 Installing a Full Size Mini PCIe Card 1. Locate the Mini PCIe slot. 2. Tilt the Mini PCIe module at 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot.

  • Page 79: Installing Antennas

    3. Press down the module and use the two screws to fix the module. 3.4 Installing Antennas Remove the antenna hole covers at front panel. Have antenna jack penetrate through the hole. Put on washer and fasten the nut with antenna jack. CV-100/P1001 Series | User Manual...
  • Page 80 Assemble the antenna and antenna jack together. Attach the RF connector at another end of cable onto the module. CV-100/P1001 Series | User Manual...

  • Page 81: Installing A So-Dimm

    3.5 Installing a SO-DIMM 1. Locate SO-DIMM socket. 2. Tilt the SODIMM module at a 45-degree angle and insert it to SODIMM socket until the gold-pated connector of module contacted firmly with the socket. 3. Press the module down until its fixed firmly by the two locking latches on each side. CV-100/P1001 Series | User Manual...

  • Page 82: Installing The Top Cover

    3.6 Installing the Top Cover 1. Put on the cover. 2. Fasten the 8 screws to fix the cover. CV-100/P1001 Series | User Manual...

  • Page 83: Installing A Sata Hard Drive

    3.7 Installing a SATA Hard Drive 1. Locate the removable HDD bay and loosen the 3 screws. 2. Pull out the HDD bracket. 3. Make the PCB side of the HDD face up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together.

  • Page 84: Installing A Sim Card

    4. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket until the connector of HDD contact the SATA connector firmly. 3.8 Installing a SIM Card 1. SIM card slot is at the front panel of the system. 2.

  • Page 85: Installing A Cfast Card

    3.9 Installing a CFast Card 1. Locate the CFast card slot. 2. Remove the mounting cover by unscrewing the two screws. 3. Insert the CFast card until it clicks. CV-100/P1001 Series | User Manual...

  • Page 86: Connecting With Display Module

    3.10 Connecting with Display Module 1. Locate the module connector slot and loosen the 1 screw. 2. Turn over the unit to have the bottom side face up, loosen the 2 screws of the module connector bracket. The photos show the male connector (on display module) and female connector (on PC module) CV-100/P1001 Series | User Manual...
  • Page 87 3. Connect the modules. 4. Fasten the 6 screws to fix the PC module on the display module. CV-100/P1001 Series | User Manual...

  • Page 88: Vesa Mount Bracket

    3.11 VESA Mount Bracket The following picture indicates VESA mounting hole pattern on P1000, which is compliant with VESA mounting standard. 1. The following picture uses a panel PC (P1000+CV display module) as a demonstration. To attach the panel PC to a VESA stand, please fasten eight screws as indicated to fix it on the stand. CV-100/P1001 Series | User Manual...

  • Page 89: Installing Panel Mount

    3.12 Installing Panel Mount 1. Accessories provided by Cincoze are as follows. (Please note that the quantity of mounting kits varies with the size of the display module, please refer to the datasheet for the actual quantity) CV-100/P1001 Series | User Manual...
  • Page 90 2. All mounting kits displayed are to be inserted into holes. 3. Installation preparation and steps. CV-100/P1001 Series | User Manual...
  • Page 91 CV-100/P1001 Series | User Manual...
  • Page 92 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below. CV-100/P1001 Series | User Manual...

  • Page 93: Installing Rack Mount

    3.13 Installing Rack Mount 1. Locate the screw holes on the PC or monitor module. Then fasten 8 screws (M4x6) as indicated to fix it on the rack mount base. 2. Assemble two rack mount brackets by fastening 4 screws (M5x6) at each side. For 8.4”...
  • Page 94 For 19” ~ 24” Panel PC For P2002E For P2002 / P1001E For M1101/ P1001 / P1101 / P1201/ P1301/ P2102 / P2102E/P2202/P2202E/P2302/P2302E Left Side Right Side Bottom Side 3. Assemble two rack mount brackets by fastening 4 screws (M5x12), flat washers and hex nuts at each side.

  • Page 95: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup CV-100/P1001 Series | User Manual...

  • Page 96: Bios Introduction

    4.1 BIOS Introduction The BIOS (Basic Input/ Output System) is a program located on a Flash Memory on the motherboard. When you start the computer, the BIOS program will gain control. The BIOS first operates an auto-diagnostic test called POST (power on self-test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.
  • Page 97 Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 4.2.1 System Date Set the date. Please use <Tab> to switch between date elements. 4.2.2 System Time Set the time.

  • Page 98: Advanced Setup

    4.3 Advanced Setup 4.3.1 ACPI Settings Enable or disable ACPI Auto Configuration. CV-100/P1001 Series | User Manual...

  • Page 99: Super Io Configuration

    4.3.2 Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. ■ Serial Port 1 Configuration ❑ Serial Port This item will allow users to enable or disable serial port. ❑...

  • Page 100: Hardware Monitor

    You can setup the system watch-dog timer, a hardware timer that generates a reset when the software that it monitors does not respond as expected each time the watch dog polls it. ❑ Watch Dog Mode Change the Watch dog mode. Select <Sec> or <Min> mode. ❑...

  • Page 101: Serial Port Console Redirection

    4.3.4 Serial Port Console Redirection ■ Console Redirection This item allows users to enable or disable console redirection. 4.3.5 CPU Configuration ■ Socket 0 CPU Information This section provides information on your CPU, frequency, and cache memory. ■ Active Processor Cores Change the active processor cores.

  • Page 102: Thermal Configuration

    Allows user to determine whether to limit CPUID maximum value. Set this item to Disabled: For Windows XP operating system. Enabled: For legacy operating system such as Windows NT4.0. (Default: Disabled) ■ Execute Disable Bit Enables or disables Intel Execute Disable Bit function. ■...

  • Page 103: Sata Configuration

    ■ Passive Trip Point Allows user to set the CPU temperature threshold. If the CPU temperature reaches this value, the CPU frequency will be automatically reduced. This item is configurable only when DTS is enabled. ■ DTS Enables or disables the CPU overheating protection function. (Default: Disabled) 4.3.7 SATA Configuration ■...

  • Page 104: Os Selection

    4.3.8 OS Selection This allows you to configure Windows OS version to install. The purpose of this is to enable USB 3.0 controller interface. If you set Windows 7 and install the OS, you will need to install USB 3.0 driver at the OS level to fully support USB 3.0 interfaces.

  • Page 105: Usb Configuration

    ■ CSM Support Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■ Boot option filter Allows user to select which type of operating system to boot. UEFI and Legacy: Allows booting from operating systems that support legacy option ROM or UEFI option ROM.
  • Page 106 ■ XHCI Hand-off Determines whether to enable XHCI (USB3.0) Hand-off feature for an operating system without XHCI (USB3.0) Hand-off support. ■ EHCI Hand-off Determines whether to enable EHCI Hand-off feature for an operating system without EHCI Hand-off support. ■ USB Mass Storage Driver Support Enables or disables support for USB storage devices.

  • Page 107: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics-related configuration options. ■ Intel IGD Configuration This section provides onboard graphics-related configuration options. CV-100/P1001 Series | User Manual...

  • Page 108: Primary Display

    ❑ GOP Driver This item will allow users to enable or disable GOP Driver. ❑ Integrated Graphics Device This item will allow users to enable or disable Integrated Graphics Device. ❑ IGD Turbo Enable This item will allow users to enable or disable IGD Turbo. ❑...

  • Page 109: South Bridge

    4.4.2 South Bridge ■ Azalia HD Audio Control detection of the Azalia device. ❑ Audio Controller Enabled: Azalia will be unconditionally enabled. Disabled: Azalia will be unconditionally disabled. ■ USB Configuration ❑ XHCI Mode This setting disables/enables the USB XHCI controller. The eXtensible Host Controller Interface (XHCI) is a computer interface specification that defines a register-level description of a Host Controller for Universal Serial Bus (USB), which is capable of interfacing to USB 1.0, 2.0, and 3.0 compatible devices.
  • Page 110 This item will allow users to enable or disable USB Port 3. ■ Wake On LAN Enable This item enables or disables Wake On LAN (WOL) function. ■ PCI Express Configuration ❑ PCI Express Port 0 This item will allow users to enable or disable PCI Express Port 0. ❑...

  • Page 111: Security Setup

    Power On: Leave the computer in the power on state. Last State: Restore the system to the previous status before power failure or interrupt occurred. 4.5 Security Setup This section allows users to configure BIOS security settings. 4.5.1 Administrator Password Administrator Password controls access to the BIOS Setup utility.

  • Page 112: Boot Setup

    4.6 Boot Setup This section allows you to configure Boot settings. 4.6.1 Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. 4.6.2 Bootup NumLock State Allows users to select the power-on state for keyboard NumLock. 4.6.3 Full Screen Logo Show This item allows user to enable or disable full screen logo show.

  • Page 113: Save & Exit

    4.7 Save & Exit 4.7.1 Save Changes and Reset This item allows user to reset system setup after saving changes. 4.7.2 Discard Changes and Reset This item allows users to reset system setup without saving any changes. 4.7.3 Restore Defaults This item allows user to restore/ load default values for all the options.

  • Page 114: Chapter 5 Product Application

    Chapter 5 Product Application CV-100/P1001 Series | User Manual...

  • Page 115: Digital I/O (Dio) Application

    This section describes DIO application of the product. The content and application development are better understood and implemented by well experienced professionals or developers. 5.1.1 Digital I/O Programming Guide 5.1.1.1 Pins for Digital I/O of Cincoze P1001 series product Item Standard...
  • Page 116 -o 4e aa (disable configuration) 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. CV-100/P1001 Series | User Manual...
  • Page 117 5.1.1.4 Sample Code in C Language 5.1.1.4.1 Control of GP74 to GP77 (DI1 ~ DI4) #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h...
  • Page 118 WriteByte(AddrPort, 0xAA) 5.1.1.4.2 Control of GP80 to GP83 (DO1 ~ DO4) #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(DataPort, 0x06) // Select logic device 06h <Output Mode Selection>...
  • Page 119 5.1.1.5 Change base address - DIO base address (Cincoze default 0xA00) <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h...
  • Page 120 = DI1 = DO1 = DI2 = DO2 = DI3 = DO3 = DI4 = DO4 5.1.1.7 DIO I/O Port Address CV-100/P1001 Series | User Manual...

  • Page 121: Digital I/O (Dio) Hardware Specification

    5.2 Digital I/O (DIO) Hardware Specification ⚫ XCOM+: Isolated power in V+ ⚫ XCOM-: Isolated power in V- ⚫ Isolated power in DC voltage: 9~30V ⚫ 4x Digital Input (Source Type) ⚫ Input Signal Voltage Level Signal Logic 0: XCOM+ = 9V, Signal Low <...
  • Page 122 CV-100/P1001 Series | User Manual...
  • Page 123 © 2018 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.

This manual is also suitable for:

Cv-108/p1001 seriesCv-110/p1001 seriesCv-110h/p1001 seriesCv-112h/p1001 seriesCv-115/p1001 seriesCv-w115/p1001 series ... Show all

Table of Contents
