- Page 1 UHD-IPC230-K 4K@60Hz HDMI Extender (IR) - 230ft (Cat6) Follow us on Youtube and Facebook US E R M ANUA L www.orei.com Page 1...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions Application Example FAQs & Troubleshooting Thank you for purchasing this product For optimum performance and safety, please read these instructions care- fully before connecting, operating or adjusting this product. Please keep this manual for future reference. -
Page 3: Registration Page
Call, email or chat with us now. OREI Live Technical Support Hours US team (US/Canada/Mexico): Monday-Friday, 9 a.m. - 5 p.m. Central Time Support Email - info@orei.com | Support Number - 877-290-5530 Page 03... -
Page 4: Introduction
Introduction The UHD-IPC230-K HDMI Extender transmits media over CAT 6/7 cable up to 230 feet. It is HDCP 2.3 compliant and supports 18Gbps video bandwidth with resolutions up to 4K@60Hz, including HDR and HLG. It features one-way IR for controlling the source device from the Receiver location. -
Page 5: Features
6. One-way IR control to control the source from the Receiver end 7. Power over Cable technology; only requires power adapter at the Trans- mitter end 8. Compact design with plug and play setup Package Contents UHD-IPC230-K Transmitter 1pcs UHD-IPC230-K Receiver 1pcs IR Blaster Cable... -
Page 6: Specifications
Specifications Technical HDCP Compliance HDCP 2.3 HDMI Compliance HDMI 2.0 Video Bandwidth 18Gbps 480i,576i,1080i Video Resolution 480p,576p,720p,1080p,4K@60Hz Color Space YCbCr 4:4:4/YCbCr 4:2:2/YCbCr 4:2:0/RGB Color Depth 12-bit Uncompressed: LPCM Audio Formats Compressed: DTS, Dolby Digital Supported Contact discharge (±4KV), air discharge (±8kv),lmple- ESD Protection mentation of the standard: IEC61000-4-2 Connection... - Page 7 Specifications Mechanical Housing Metal Color Black L: 84mm / 3.30in Dimensions W: 76.4mm / 3.00in H: 20mm / 0.78in Weight Tx & Rx: 120g / 4.23oz Input: AC 100-240V 50/60Hz, Output: DC 12V/1A Power Supply (US/EU standards, CE/FCC/UL certified) Power Consumption Tx: 4W;...
-
Page 8: Operation Controls And Functions
Operation Controls & Functions Page 08... - Page 9 Operation Controls & Functions Name Function Description DC 12V Connect the included power adapter Connect a media device such as a DVD Player, set-top HDMI IN box, etc. IR OUT Connect the included IR Blaster cable Reset Press once to reset the unit CAT6 Connect a CAT 6/7 cable LED Indicator to confirm if the connection is estab-...
-
Page 10: Application Example
Application Example HDMI Cable HDMI Cabl e UHD T V IR T X Re ceiver Sender IR R X DVD Re mo te Contr ol Steps to Connect:- 1. Connect your media device to the HDMI IN on the Transmitter using an HDMI cable. -
Page 11: Faqs & Troubleshooting
-> Try a different media source Still have some questions? Please feel free to contact us at: info@orei.com. OR Fill out the form on the ‘Contact Us’ page on the website. Our team will be more than happy to help you. - Page 12 4K@60Hz HDMI Extender (IR) - 230ft (Cat6) UHD-IPC230-K www.orei.com © 2025 Page 12...
