Orei UHD-WPE400R-K User Manual

4k hdmi and usb-c extender with wall plate transmitter 400ft

Advertisement

Quick Links

UHD-WPE400R-K
4K HDMI
and USB-C Extend-
TM
Follow us on Youtube
and Facebook
er with Wall Plate Transmitter
400ft
U S E R M A NUA L
www.orei.com
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UHD-WPE400R-K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Orei UHD-WPE400R-K

  • Page 1 UHD-WPE400R-K 4K HDMI and USB-C Extend- Follow us on Youtube and Facebook er with Wall Plate Transmitter 400ft U S E R M A NUA L www.orei.com Page 1...
  • Page 2: Table Of Contents

    Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions Application Example FAQs & Troubleshooting Thank you for purchasing this product For optimum performance and safety, please read these instructions care- fully before connecting, operating or adjusting this product. Please keep this manual for future reference.
  • Page 3: Registration Page

    OREI Live Technical Support Hours US team (US/Canada/Mexico): Monday-Friday, 9 a.m. - 5 p.m. Cen- tral Time Support Email - info@orei.com | Support Number - 877-290-5530 Chat Live on www.orei.com Send us an instant message now. Our Technical Support Team will respond momentarily.
  • Page 4: Introduction

    Introduction The UHD-WPE400R-K is an HDMI Extender with a Wall Plate Transmitter that extends media signals up to 400 feet. Com- pliant with HDMI 2.0b, HDCP 2.2, and DP 1.4, it supports up to 4K@60Hz resolution with 18Gbps bandwidth, and video formats like HDR, Dolby Vision, and HLG.
  • Page 5: Features

    Features 1. HDCP 2.2 and DP 1.4 compliant 2. Video resolutions up to 4K@60Hz 3. 18Gbps video bandwidth 4. Extend media signals up to 400 feet over a CAT 6/7 cable 5. HDR, Dolby Vision and HLG support 6. USB C input to connect Laptops and PCs 7.
  • Page 6: Package Contents

    Package Contents Transmitter Only: UHD-WPE400R-K (Wall Plate Transmitter) 1pcs Power Adapter 1pcs 2-pin 3.5mm Phoenix Connector (Male) 1pcs 3-pin 3.5mm Phoenix Connector (Male) 2pcs User Manual 1pcs Transmitter & Receiver Kit: UHD-WPE400R-K (Wall Plate Transmitter) 1pcs UHD-WPE400R-K (Receiver) 1pcs IR Blaster Cable (1.5m) 1pcs IR Receiver Cable (1.5m)
  • Page 7: Specifications

    Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 Video Bandwidth 18Gbps Up to 4K@60Hz 4:4:4, 2K@60Hz 4:4:4 Video Resolution Including all 3D TV format Including all resolution in computer such as 1920x1200 LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, HDMI Audio Dolby Digital Plus (DD+), DTS-ES, DTS HD Master, DTS Formats...
  • Page 8 Specifications Connection Input: 1× USB-C [USB Type C, 24-pin female] 1× HDMI [HDMI Type A, 19-pin female] Output: 1× HDBT [RJ45, 8-pin female] Transmitter Control: 1× RS-232 [3-pin 3.5mm phoenix connector] 1× IR IN [3-pin 3.5mm phoenix connector] 1× IR OUT [2-pin 3.5mm phoenix connector] Input: 1×...
  • Page 9 Specifications Mechanical Housing Transmitter/Receiver: Metal Enclosure Color Transmitter: White + Black; Receiver: Black Transmitter: L: 69.8mm / 2.74in W: 39mm / 1.53in H: 114mm / 4.48in Dimensions Receiver: L: 140mm / 5.51in W: 65mm / 2.55in H: 18mm / 0.70in Transmitter: 203g / 7.16oz Weight Receiver: 155g / 5.46oz...
  • Page 10: Operation Controls And Functions

    Operation Controls and Functions Transmitter Panel HDMI USB-C SOURCE AUTO HDBaseT OUT USB-C IN Name Function Description The Green LED will light up when USB-C is selected as USB-C LED the input. The Green LED will light up when HDMI is selected as HDMI LED the input.
  • Page 11 Operation Controls and Functions Name Function Description Connect a CAT6/7 cable. The other end connects to the HDBaseT Receiver. Control the device through a laptop or PC using RS- RS-232 232 commands. IR IN Connect an IR cable to receive the signal IR OUT Connect an IR cable to transmit the signal Wire the unit through the 2-pin phoenix to power...
  • Page 12 Operation Controls and Functions Receiver Panel SERVICE AUDIO OUT IR IN IR OUT Name Function Description The LED will light up Red when the Receiver is pow- Power LED ered on. SERVICE Firmware update port. Connect the included power adapter. If the Receiver DC 24V has active power, then the Transmitter would not need a power supply.
  • Page 13 Operation Controls and Functions Name Function Description ▪ On: Transmitter and receiver are in good connection Connection status. Signal ▪ Flashing: Transmitter and receiver are in poor connec- Indicator tion status. ▪ Off: Transmitter and receiver are not connected. ▪ On: HDMI signal with HDCP. Data Signal ▪...
  • Page 14 Operation Controls and Functions IR Receiver and Blaster Cables are defined as below: IR Blaster IR Blaster Signal Power IR BLASTER IR Receiver IR Signal Power Grounding IR RECEIVER Note: When the angle between the IR receiver and the remote control is ±...
  • Page 15: Application Example

    Application Example HDMI USB-C SOURCE AUTO Transmitter HDBaseT OUT USB-C IN Power Supply TV Box UHDTV CAT6/6A 2.0 Speakers IR Blaster AUDIO OUT IR IN IR OUT Receiver The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
  • Page 16: Faqs & Troubleshooting

    Transmitter and the Receiver. They cannot be connected to a network switch. Still have some questions? Please feel free to contact us at: info@orei.com. OR Fill out the form on the ‘Contact Us’ page on the website. Our team will be more than happy to help you.
  • Page 17 4K HDMI and USB-C Extender with Wall Plate Transmitter 400ft UHD-WPE400R-K www.orei.com © 2024 Page 17...
