Call, email or chat with us now. OREI Live Technical Support Hours US team (US/Canada/Mexico): Monday-Friday, 9 a.m. - 6 p.m. Central Time Support Email - info@orei.com Support Number - 877-290-5530 Chat Live on www.orei.com...
INTRODUCTION This 18Gbps HDMI Extender can extend high definition video / audio signal, RS-232, bi-directional IR, and the dis- tance is up to 492ft / 150 meters between transmitter and receiver via a single CAT cable. It supports resolution up to 4K2K@60Hz 4:4:4, 18Gbps and HDCP 2.2.
FEATURES 1. HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant 2. Support 18Gbps video bandwidth 3. The maximum extended transmission distance via a single Cat5e/6 cable: • 394ft / 120 meters for 4K2K signal; • 492ft / 150 meters for 1080P signal 4.
SPECIFICATIONS TECHNICAL HDCP Compliance HDCP 2.2 / HDCP 1.4 Video Bandwidth 18Gbps 4K2K 50/60Hz 4:4:4 4K2K 50/60Hz 4:2:2 4K2K 50/60Hz 4:2:0 Video Resolution 4K2K 30Hz 4:4:4 1080p, 1080i, 720p, 720i, 480p, 480i All HDMI 3D TV formats All PC resolutions including 1920 x 1200 Color Space RGB / YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 8/10/12-bit (1080P60Hz, 4K30Hz, 4K60Hz YCbCr...
Page 7
Inputs: 1x HDBT IN [RJ45, 8-pin female] Outputs: 1x HDMI Type A [19-pin female] 1x AUDIO OUT [3.5mm Stereo Mini-jack] Receiver Control: 1x IR IN [3.5mm Stereo Mini-jack] 1x IR OUT [3.5mm Stereo Mini-jack] 1x RS-232 [Phoenix jack] 1x SERVICE [Mini-USB, Update port] MECHANICAL Housing Metal Enclosure...
OPERATION CONTROLS AND FUNCTIONS 5.1 Transmitter Panel Name Function Description Power LED Red LED indicates that the transmitter is powered on. SERVICE port Firmware update port. DC 24V DC 24V/1A power supply input port. Note that the extender supports PoC function, it means that either transmitter or receiver is powered on by 24V/1A power adapter, the other one doesn’t need power supply.
Page 9
OPERATION CONTROLS AND FUNCTIONS Name Function Description HDBT OUT RJ45 connector for connecting the HDBT IN port of receiver with a CAT 5e/6 cable. Connection Illuminating: Transmitter and Receiver are in good connection status. Signal Flashing: Transmitter and Receiver are in poor connection status. Indicator lamp Dark: Transmitter and Receiver are not connected.
OPERATION CONTROLS AND FUNCTIONS 5.2 Receiver Panel page 10...
Page 11
OPERATION CONTROLS AND FUNCTIONS Name Function Description Power LED Red LED indicates that the receiver is powered on. SERVICE port Firmware update port. DC 24V/1A power supply input port. DC 24V Note that the extender supports PoC function, it means that either transmitter or receiver is powered on by 24V/1A power adapter, the other one doesn’t need power supply.
OPERATION CONTROLS AND FUNCTIONS 5.3 IR Pin Definition IR Receiver and Blaster pin’s definition is as below: IR RECEIVER IR BLASTER page 12...
Page 13
OPERATION CONTROLS AND FUNCTIONS The following is IR system diagram about IR cable use method. Note: IR remote sends signal at the distance of 0~5 meters / 0~8 meters with the angle of ± 45° in vertical direction. page 13...
