- Page 1 HDMI 18Gbps Extender over Cat5e/Cat6 VER: 2.1 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. 1 / 10...
-
Page 2: Table Of Contents
Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment. Table of Contents 1. -
Page 3: Introduction
Advanced The extender will start protection mode automatically when using UTP termination, which follows the standard of cross interconnection method. 1. Introduction The 18Gbps HDMI Extender is a tool which can extend your HDMI signal over 230fts/70meters to a compatible display. It is designed to convert HDMI signal to standard HDBaseT signal which can be transmitted by LAN cable. -
Page 4: Features
the HDMI Extender. 2. Features HDMI 2.0b (18Gbps), HDCP 2.2 and DVI compliant Video resolutions up to 4K2K@50/60Hz (YUV444) 10bits HDR (High Dynamic Range) pass through Supports HDMI High Bit Rate(HBR) audio pass through Supports CEC bypass ... - Page 5 Video Bandwidth 18 Gbps up to 4K2K@50/60Hz(YUV4:4:4),4K2K@30Hz,1080P@120Hz, Video Resolutions and 1080P 3D@60Hz Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2 Color Depth 10-bit, 12-bit HDMI Audio Formats LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby (Pass-through) TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X Human body model —...
-
Page 6: Operation Controls And Functions
5. Operation Controls and Functions 5.1 Transmitter Power LED: System power indicator. DC 24V: Connect 24V/1A adaptor to AC wall outlet for power supply. HD BaseT Out: Standard HD BaseT signal output port. Connect HD BaseT receiver with a UTP cable following the standard of direct interconnection method HDMI In: Connect this to HDMI source devices such as Blu-ray or PS4 player... - Page 7 5.2 Receiver Power LED: System power indicator. DC 24V: Connect 24V/1A adaptor to AC wall outlet for power supply. HD BaseT In: Standard HD BaseT signal input port. Connect HD BaseT with a UTP cable following the standard of direct Transmitter interconnection method HDMI Out: HDMI output port.
- Page 8 ※ Description 1 POC (Power Over Cable) Application Example ※ Description 2 Bidirectional Infrared control Application Example ※ Description 3 Bidirectional RS232 control Application Example 8 / 10...
-
Page 9: Connection Diagram
6. Connection Diagram 9 / 10... - Page 10 10 / 10...
