Summary of Contents for Tecnosicurezza TechMaster

  • Page 1 TechMaster User Instructions...
  • Page 2 User instructions TechMaster Table of contents TABLE OF CONTENTS IMPORTANT NOTES! GENERAL INFORMATION OVERVIEW FUNCTIONS OPENING THE LOCKS SERS VERRIDE USERS OPENING WITHOUT TIME DELAY SERS OPENING WITH TIME DELAY ANAGER VERRIDE ANAGER OPENING WITHOUT TIME DELAY ANAGER VERRIDE ANAGER...
  • Page 3 User instructions TechMaster VERRIDE SERS MANAGEMENT USER CONFIGURATION DUAL MODE DISABLING ENABLING ANAGER IME LOCK ASSOCIATION DISASSOCIATION ANAGER ARIABLE ELAY ASSOCIATION DISASSOCIATION CODE CHANGING HANGE CODE FOR STANDARD AND OVERRIDE SERS HANGE CODE FOR ANAGER HANGE CODE FOR VERRIDE ANAGER...
  • Page 4 User instructions TechMaster Important notes  Before installing this product, please carefully read the installation and operating instructions.  Locks have been designed to correctly operate in a temperature range from -5°C (23°F) to + 50°C (122°F) and in an environment with non-condensing humidity between 25% and 90%.
  • Page 5 User instructions TechMaster General information Using your keypad  Press any button to power up the keypad. LCD which displays: ENTER CODE X X – X X X X X X If more locks are installed, LCD displays: SELECT LOCK Enter the lock number and press to select it.
  • Page 6 User instructions TechMaster  If a wrong dynamic/activation code is entered, LCD displays the message:  If a dynamic/activation code is entered more than 30 minutes WRONG DYNAMIC CODE before its beginning validity time, LCD displays:  If a dynamic/activation code is entered more than 30 minutes...
  • Page 7 User instructions TechMaster = Membrane test = System info and time and date info = Exit and back to the main menu = Master menu Pre-setup & Configurations When the lock is uninstalled and in pre-setup mode:  lock can be simply opened by pressing ...
  • Page 8 User instructions TechMaster Master Manager Access to Master Menu Access to Manager Menu Set time and date Standard users management Set automatic DST Override users management Set Time Lock periods Set time delay Audit download Set variable time delay Manager Management...
  • Page 9 The lock saves the last 15000 operations with time, date, user and operations description. The keypad can save the last 250 operations. It is possible to download the events for locks and keypad by using the Tecnosicurezza DMT Audit software. For further information refer to the IU_DMT_Audit_XX.
  • Page 10 Some options/characteristics reported in this user manual, can only be used if previously programmed through the setup software. Therefore, please refer to the user manual IU_TechMaster_setup_XX. Please contact Tecnosicurezza for further information. Opening the locks Users (or Override users): opening without time delay Power up the keypad.
  • Page 11 User instructions TechMaster ENTER CODE Press , LCD displays: X X – X X X X MANAGER Press for opening with Manager code or press it two times for X X X X X X opening with Manager Ovr code. LCD displays:...
  • Page 12 User instructions TechMaster created code deletes all the previous ones (i.e. if three codes are created and the third one is used before using the first two ones, those first two codes are deleted). In this case indeed LCD displays:...
  • Page 13 User instructions TechMaster hh:mm _ _ _ Press to change time and date. DD / MM / YYYY Enter the new time and date values and press to confirm. VALUES SAVED LCD displays: Time and Date recovery through DyamaWeb (OTC software) This option can only be performed after activating the dynamic codes and the deletion of all static codes (including the Master code).
  • Page 14 User instructions TechMaster Master menu, allows to add/delete the settings for time lock/closing periods/opening periods, only if current time and date values are included in an opening period. TIME LOCK Power up the keypad. Enter the Master menu. Press until LCD...
  • Page 15 User instructions TechMaster hh:mm Press . LCD displays the values for the first day. hh:mm Press to scroll all the schedules list. DELETE VALUES? Press on a schedule. LCD displays:  Press to confirm or to exit. END OF LIST At the end of the list, press .
  • Page 16 User instructions TechMaster DD/MM/AA hh:mm Press to check the first closing period scheduled. DD/MM/AA hh:mm Press to scroll all the scheduled closing periods. DELETE VALUES? Press to delete the scheduled closing periods.  Press to confirm or to exit. END OF LIST...
  • Page 17 User instructions TechMaster GG/MM/AA hh:mm Press . LCD displays the first opening period. GG/MM/AA hh:mm Press to scroll all the scheduled opening periods. DELETE VALUES? Press to delete. LCD displays:  Press to confirm or to exit. END OF LIST...
  • Page 18 User instructions TechMaster Manager configuration After configuring the option Allow user mode change with Setup software and after installing the Manager, this option allows to configure it as code only or as code and Dallas key. It is also possible to configure the Manager as Dallas key only (allowed only if it is configured in dual mode with setup software).
  • Page 19 User instructions TechMaster Manager Variable Time Delay association/disassociation After configuring the options Allow user Variable Time Delay change and Variable Time delay with Setup software and after installing the Manager, this option allows to associate it to a variable time delay or not.
  • Page 20 User instructions TechMaster Manager menu Power up the keypad. MANAGER MENU X X X X X X Press , then press . LCD displays: Users Management Power up the keypad. Enter Manager menu and press until LCD USERS MANAGEMENT displays:...
  • Page 21 User instructions TechMaster NOTE: the configuration of user groups with the dual mode option can only be established with setup software. Moreover, dual mode it is enabled by default after the configuration is sent to the lock system. Enter User Management menu and select an installed user.
  • Page 22 User instructions TechMaster VALUES SAVED Enter the new values and press to confirm. LCD displays: Time delay can be programmed between 0 and 99 minutes, the open window can be programmed between 1 and 19 minutes instead. It is possible to program a shorter time delay with the lock open or closed. In this latter case, after confirming the new values a time delay count is started from the keypad and at count elapsed the LCD automatically confirms the values updating.
  • Page 23 User instructions TechMaster END OF LIST At the end of the list, press . LCD displays:  EXIT AND SAVE? PC connection Use this function to enable the connection between the keypad and PC. PC LINK Power up the keypad. Enter the Manager menu. Press...
  • Page 24 User instructions TechMaster key. It is also possible to configure and OVR user as Dallas key only (allowed only if it is configured in dual mode). WARNING: to perform this configuration, lock must be open. Enter the OVR User Management menu and select an OVR user Press to select “Configuration?”...
  • Page 25 User instructions TechMaster Manager Variable Time Delay association/disassociation After configuring the options Allow user Variable Time Delay change and Variable Time delay with Setup software and after installing an OVR user, this option allows to associate it to a variable time delay or not.
  • Page 26 User instructions TechMaster CONFIRM CODE Confirm the new code e insert the Dallas key (if programmed). X X X X X X Change code for Override Manager CHANGE OVR Power up the keypad. Access Change Code menu and press . Then,...
  • Page 27 User instructions TechMaster Press . If a time lock is already programmed, LCD displays the next activation time for the time lock (automatically calculated adding 30 minutes to the last activation time): Press to confirm. It is also possible to enter different values. Enter date and time (max.
  • Page 28 User instructions TechMaster MASTER CODE If the lock selected is instead connected with the keypad (but not X X X X X X X X installed), LCD displays: OPERATION DONE Enter Master code and then Manager code. LCD displays: Remove Locks WARNING: it is recommended to perform this operation always with lock open and connected with the keypad.
  • Page 29 With AUTOMATIC instead, lock automatically re-closes after the time set with Setup software. I/O Interface This menu allows for installing removing and configuring the IP parameters of Tecnosicurezza I/O interface. Access Configuration Menu and press until LCD displays: I/O INTERFACE Install I/O interface WARNING: I/O interface must be in pre-setup mode before the installation.
  • Page 30 User instructions TechMaster Press again, enter the new IP address value and press OPERATION DONE  times to confirm ( ). LCD displays: Subnet Mask SUBNET MASK Access I/O Interface and press until the LCD displays: SUBNET MASK Press . LCD displays the current Subnet Mask.
  • Page 31 User instructions TechMaster DISPLAY Press until the LCD displays: Press to access this menu. Regulation of display contrast Access Display menu. LCD displays: CONTRAST CONTRAST Press . LCD displays the current contrast level. Press again X→ (→) and enter a value for contrast level (between 1 and 9) or select it...
  • Page 32 User instructions TechMaster BUZZER Press . LCD displays the current value for buzzer volume. XX→ Press again (→) and use keys ÷ to enter a new value for busser volume (Low, Medium, High, OFF for deactivating it) or select it with...
  • Page 33 RTC Correction This menu allows for compensating the time and date drift for the keypad. To enter it, lock must be open. Contact Tecnosicurezza for further information or in case it is necessary to perform a Time and date compensation.
  • Page 34 User instructions TechMaster Correct disposal of this product: (Waste Electrical & Electronic Equipment) Applicable in the European Union and other European countries with separate collection systems. This marking displayed on the product or its literature indicates that it should not be disposed with other wastes at the end of its working life.
