- Page 1 X1 Gen2 User Manual RGB-RD-UM-X1 Gen2 E001 Article No: V1.0 Revision No:...
-
Page 2: Table Of Contents
Chapter 5 Support ..............................36 5.1 Contact Us ..............................36 Chapter 6 Appendix ..............................37 6.1 Specification ..............................37 6.2 Terms & Definitions ............................40 6.4 Revision History ............................47 © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 3: Declarations
RGBlink. If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if the goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid. -
Page 4: Operators Safety Summary
To protect users from electric shock, ensure that the chassis connects to earth via the ground wire provided in the AC power Cord. The AC Socket-outlet should be installed near the equipment and be easily accessible. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... - Page 5 The environment in which you install your VENUS X1 should be clean, properly lit, free from static, and have adequate power, ventilation, and space for all components. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
-
Page 6: Chapter 1 Your Product
Chapter 1 Your Product 1.1 In the Box AC Power Cord USB Cable Note: AC Power Cable supplied as standard according to destination market. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 7: Product Overview
Note:X1 Gen2 is also compatible with sender cards from Novastar,Linsn Technology,Colorlight and Mooncell.But X1 Gen2 only supports power supply to the sender cards from other companies and can not control them. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 8: Rear Panel
DVI input Audio input OUTPUT CONNECTORS Audio Output DVI Output Slots preserved for sender cards POWER Power switch Power IEC-3 CONTROL PORT USB-A RS232 © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 9: Front Panel
Split function button. Restores/Loads saved setting from 1-16 scene and Number 6. HDMI input source selection and Number 2 CVBS input source selection and Number 3 © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... - Page 10 Number 8. Short cut button of Audio Menu and Number 9 Short cut button of Black Out and Number 0. Switch button with transition effect. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
-
Page 11: Dimension
1.2.3 Dimension Following is the dimension of X1 Gen2 for your reference: Dimension:480mm×303mm×45mm © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 12: Chapter 2 Install Your Product
TST screen shows as below，meanwhile the device enter initializing state after that，the device will load the previously saved setting. On delivery, the default input is HDMI. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 13: Chapter 3 Use Your Product
The symbol＊ means the selected item is under editing state, ready to be set or checked The operation diagram is as follows: 3.2 MENU Structure The MENU structure is shown in the figure below: © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 14: Use The Menu
1920 INPUT INFO ▶ V SIZE 1080 >SIZE ADJUST ▶ H POS USB CONTROL ▶ V POS VGA ADJUST ▶ REST SIZE ADC ADJUST © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 15: Vga Adjust
Note:If one <AUTO AJUST> cannot meet the needs, users can do <AUTO AJUST> many times. The system can automatically save the ADJUST parameter. Users can also go to <AUTO AJUST> by pressing 【VGA】 button for 10s. 4. ADC ADJUST © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... - Page 16 Image Control One with SDI optional module come with SDI ADJUST in the menu. 6. EDID MANAGE DESTINATION: DVI or HDMI SOURCE: RGB DVI, RGB HDMI, FOLLOW, CUSTOM © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
-
Page 17: Output
DVI connector which is compatible with VGA, DVI, CVBS, YPbPr via adapter. 3.3.4 Output 1. OUTPUT INFO show current input information © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... - Page 18 CUSTOMIZE: custom resolution Turn the knob to resolution line and press the knob “>” (arrow )change to “*” (star ) put in the numbers for © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
- Page 19 H POLARITY:horizontal polarity, POS (positive) or NEG (negative) V POLARITY:vertical polarity, POS (positive) or NEG (negative) RESET: reset above setting if not proper 4. SCREEN © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
- Page 20 > P I C T U R E ▶ TEST OVERLAY ▶ DISPLAY MODE G A M M A L I N E A R © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
- Page 21 >SWAP IMAGE ALPHA SELECT IMAGE B Select <SELECT> in 【PIP】menu, push knob turn Knob to select”IMAGE B”, Push <SCALE> to set the size and © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
-
Page 22: Display Mode
Select <PRESET>Push knob and turn the knob to“WhOnBk1”or “WhOnBk2” and Push knob again Note:TEXT OVERLAY only support monochrome subtitles. TEST OVERLAY AND/OR PRESET WhOnBK1 BLEND MODE MODE1 GREEN BLEND LEVEL BLUE STAND ABOVE © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... - Page 23 AUTO SWITCH ▶ SOLID COLOR SOLID COLOR COLOR:WHITE, BLUE, GREEN, RED. MODE LIVE IMAGE ▶ GREEN TEST PATTERN BLUE ▶ >SOLID COLOR RED,GREEN,BLUE: value 0-255 © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
-
Page 24: Transition
Optional Input Signal Channel Limitations HDMI CVBS HDMI √ × √ √ √ Standard × √ √ √ √ √ √ √ √ √ © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 25: Audio
H TOTAL 1920 OUTPUT ▶ V TOTAL 1080 TRANSITION ▶ H POS AUDIO ▶ V POS >SPLIT H SIZE 1920 V SIZE 1080 RESET © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 26: System
▶ After-Sale Service: SYSTEM INFO ▶ 4008-592-315 >TECH SUPPORT ▶ support@rgblink.com WORK TIME ▶ LOCK FRONT PANEL ▶ www.rgblink.com LICENSE SETUP TEL +86(592) 5771197 © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... - Page 27 After the panel is locked, keep pressing MENU for 3 S to release the panel. 5. LICENSE SET UP ▶ ENETER PASSWORD SYSTEM INFO ▶ 000000 TECH SUPPORT ▶ WORK TIME ▶ LOCK FRONT PANEL ▶ >LICENSE SETUP © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
-
Page 28: Language
Or Keep pressing MENU and SCALE button for 3 S to switch language. 3.3.10 Factory Reset ▶ FACTORY RESET SYSTEM LANGUAGE 语言 YES <OK>, NO <MENU> ▶ >FACTORY RESET © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 29: Shortcut Buttons
There are 7 layouts available in the menu. PIP L+T, PIP R+T, PIP L+B, PIP R+B, PIP CENTER, PBP L+R and PBP T+B. Here are 3 examples © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 30: Save】Button
Buttons with lights on are empty, flashing buttons are used. LCD shows as below. SAVE TO >SAVE1 KEY ON FOR EMPTY FLASH IS FOR USED © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 31: Load】Button
LCD shows below: LOAD FROM >SAVE 1 KEY ON FOR ALL SAVES FLASH IS CURRENT SET Push【MENU】to exit LOAD, the button lights go out. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 32: Scale】Button
V POS: Enter the vertical position of the splice, since the first unit is from the start point (0,0), so enter 0 here. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 33: Black】Button
Touch the key, the key light is on, the output can realise the straight black effect to achieve one-key black screen, the effect is as shown in the picture: © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... - Page 34 © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
-
Page 35: Chapter 4 Ordering Codes
Chapter 4 Ordering Codes 4.1 Product 110-0002-01-0 X1 Gen2 110-0002-02-0 X1-S Gen2 © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 36: Chapter 5 Support
Chapter 5 Support 5.1 Contact Us © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... -
Page 37: Chapter 6 Appendix
720p50/59.94/60 | 1080i50/59.94/60 | 1080P50/59.94/60 VESA 800×600@60 | 1024×768@60 | 1280×768@60 | 1280×1024@60 | 1600×1200@60 | 1920×1080@60 Signal Level TMDS pwl, single pixel input,165MHz band pixels © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... - Page 38 SMPTE 425M (Level A & B) | SMPTE 424M | SMPTE 292M | SMPTE 259M-C | DVB-ASI Standard DVI Output (Standard) Number of Outputs Connector DVI-I © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
- Page 39 1920×1080@60|1920×1080@50 | 1920×1200@60|2048×1152@60 | 2560×812@60 | 2560×816@60 Accessories and Operating Condition Communication RJ11/RS232 USB 2.0 Input Voltage AC100-240V/50-60HZ Max Power Working 0°C~45°C Temperature Working Humidity 10%~85% © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
-
Page 40: Terms & Definitions
1920 × 1080 at 120 Hz or 2560 × 1440 at 60 Hz). It added support for 10 bpc, 12 bpc, and 16 bpc color depth © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com... - Page 41 ●SFP: small form-factor pluggable, is a compact, hot-pluggable network interface module used for both telecommunication and data communications applications. ●optical fiber connector: terminates the end of an optical fiber, and enables quicker connection and disconnection © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
- Page 42 ●NTSC : The colour video standard used in North America and some other parts of the world created by the National Television Standards Committee in the 1950s. NTSC utilizes an interlaced video signals. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
- Page 43 ●RTSP : The Real Time Streaming Protocol (RTSP) is a network control protocol designed for use in entertainment and communications systems to control streaming media servers. The protocol is used for establishing and controlling media sessions between end points. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
- Page 44 The lower the temperature, the redder the light. Benchmark colour temperature for the A/V industry include 5000°K, 6500°K, and 9000°K. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
- Page 45 ●UHD: Standing for Ultra High Definition and comprising 4K and 8K television standards with a 16:9 ratio, UHD follows the 2K HDTV standard. A UHD 4K display has aphysical resolution of3840x2160 which is four times the area and twice © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
- Page 46 The source device will then output the provided EDID data, ensuring proper video image quality. © Xiamen RGBlink Science & Technology Co., Ltd. Ph: +86 0592 5771197 | support@rgblink.com | www.rgblink.com...
-
Page 47: Revision History
All information herein is Xiamen RGBlink Science & Technology Co Ltd. excepting noted. is a regis tered trademark of Xiamen RGBlink Science & Technology Co Ltd.While all efforts are made for accuracy at time of printing, we reserve the right to alter otherwise make change without notice.
