OPERATING MANUAL
1 PHASE METER
PF-11
ConnectionDiagram
PF-11
Technical Specification
Model
Display
Size (mm)
Panel Cutout
Voltage Input
Current Input
POWER FACTOR
Power Supply
Frequency
Wiring
System
Protection
Level
(As Per Request)
Operating
Temperature
Relative
Humidity
20
19
18
17
16
PF 11-A2-N0
Range:
Voltage(L-N) : 30-300V AC
CAT III
Current : 30mA To 5A AC
PF:
0.100 To 1.000
CT Selection up to 9999/5 Amp AC
Made in India
~
100
!
270V AC
50/60 Hz
3VA
1 Amp
L
N
S1
1
2
3
4
5
Page - 1
8 digit, 7 segment, 0.5" Red display
101 (H) X 101 (W) X 43 (D) mm
92 X 92 mm
30 To 300V AC VLN CAT III
5 Amp or higher through external CT
0.1 To 1.000 PF
100 To 270V AC,50/60Hz,Approx 3VA
45 To 65 Hz
1Ph-2W
IP-65 (Front side) As per IS/IEC 60529 : 2001
0°C To 50°C
Up to 95% RH Non Condensing
15
14
13
12
11
V
N
P
System:
1Ø-2W
Accuracy Class:
0.5
www.multispanindia.com
5 Amp
S2
S1
S2
6
7
8
9
10
PF-11
www.multispanindia.com
Advertisement
Related Manuals for MULTISPAN PF-11
Summary of Contents for MULTISPAN PF-11
- Page 1 OPERATING MANUAL 1 PHASE METER PF-11 Technical Specification Model PF-11 8 digit, 7 segment, 0.5” Red display Display Size (mm) 101 (H) X 101 (W) X 43 (D) mm Panel Cutout 92 X 92 mm Voltage Input 30 To 300V AC VLN CAT III...
- Page 2 ControlPanels To view Power Factor GeneratorSet PARAMETER SETTING MODE PowerDistributionboards To Set Parameter Value Press For 5 Sec BuildingManagementSystem QualityControlSystem To Increment parameter value MotorControlPanel To Decrement parameter value EnergyAudit To Exit from parameter setting PF-11 Page - 2 www.multispanindia.com...
- Page 3 ‘ON’ or ‘OFF’ function. However this mains switch or circuit breaker must be installed at convenient place normally accessible to the operator. 3) Use and store the instrument within the specified ambient temperature and humidity ranges as mentioned in this manual. PF-11 Page - 3 www.multispanindia.com...
- Page 4 NOTE : PF-11 www.multispanindia.com Page - 4...
