MULTISPAN PIC-4202 Manual

TECHNICAL SPECIFICATION
INPUT SPECIFICATION
Voltage:
Input Types
Current:
I/P Filter Time
0.1 Sec to 10 Sec
Resolution Decimal point selectable:
0.1, 0.01, 0.001, 0001
Range -999 to 9999 (For all I/P)
Indication ±1% FSD ± 1 digit
Accuracy (FSD - Full Scale Deflection)
DISPLAY AND KEY
Display
UPPER:
LOWER:
Keys SET,INC,DEC,ENT
DIMENSION:
Size
48 (H) x 48 (W) x 95 (D) mm
Panel Cutout 45 (H) x 45 (W) mm
POWER SUPPLY
Supply
Voltage
Power
Consuption
(VA Rating)
PROCESS INDICATOR
0 to 10V DC
0 to 20mA DC,
4 to 20mA DC
4 digit, 7 seg, 0.56" RED
4 digit, 7 seg, 0.33" GREEN
100 to 270V AC, 50-60Hz
4VA @ 230V AC MAX
ENVIRONMENT CONDITION:
PIC-4202
Operating Temp.
Relative Humidity
Protection Level
(As per request)
Outline Dimension(mm)
48
R1
R2
SET
0°C to 55°C
UP to 95% RH
(non-condensing)
IP-65 (Front side) As per IS/IEC
60529 : 2001
MECHANICAL INSTALLATION
PIC 4202
PV
SV
ENT
95
48
3
TERMINAL CONNECTION
1
L
~
100
270V AC
50/60 Hz
!
4VA
N
2
Made in India
3
NC
C
4
R1
www.multispanindia.com
NO
5
Connection for voltage I/P
6
(0-10V DC)
7
Connection for current I/P
8
(4-20mA DC or
0-20mA DC)
7
Panel Cutout
Dimension (mm)
45
45
6
I/P
0 To 10V DC
-
7
I/P
0/4 To 20
mA DC
8
NO
9
R2
10
C
Page -1
