Summary of Contents for Autel MaxiDiag MD909 Pro

  • Page 1 MaxiDiag MD909 Pro...

  • Page 2: Copyright Information

    Autel will not be liable for any direct, special, incidental, or indirect damages, or for any economic consequential damages (including the loss of profits) as a result of using this product.

  • Page 3: Safety Information

    The safety messages herein cover situations Autel is aware of at the time of publication. Autel cannot know, evaluate or advise you as to all of the possible hazards. You must be certain that any condition or service procedure encountered does not jeopardize your...
  • Page 4 DANGER When an engine is operating, keep the service area WELL VENTILATED or attach a building exhaust removal system to the engine exhaust system. Engines produce carbon monoxide, an odorless, poisonous gas that causes slower reaction time and can lead to serious personal injury or loss of life.

  • Page 5: Table Of Contents

    CONTENTS USING THIS MANUAL ....................1 ......................1 ONVENTIONS 2 GENERAL INTRODUCTION ..................3 ....................... 3 — V VCI V150 L ........7 EHICLE OMMUNICATION NTERFACE ....................8 THER CCESSORIES 3 GETTING STARTED ...................... 9 ......................9 OWERING ....................13 OWERING 4 DIAGNOSTICS ......................
  • Page 6 YSTEM ETTINGS ..................55 UIDE ESET ....................55 RINTER ANAGER ..................57 PLOAD EPORT TO LOUD ........................57 ........................57 BOUT 9 UPDATE ........................59 10 REMOTE DESKTOP ....................60 10.1 ....................... 60 PERATIONS 11 AUTEL USER CENTER ....................62...
  • Page 7 12 BATTERY TEST ......................65 12.1 BAS BT506 B ..............65 ATTERY ESTER 12.2 ..................... 67 REPARATION 12.3 ....................68 VEHICLE 12.4 ....................76 VEHICLE 13 MAINTENANCE AND SERVICE .................. 78 13.1 ................78 AINTENANCE NSTRUCTIONS 13.2 ................78 ROUBLESHOOTING HECKLIST 13.3 ..................

  • Page 8: Using This Manual

    Using This Manual This manual contains tool usage instructions. Some illustrations shown in this manual may make reference to modules and optional equipment that are not included in your system. Contact your sales representative for availability of other modules and optional tools or accessories. 1.1 Conventions The following conventions are used: 1.1.1 Bold Text...
  • Page 9 vehicle being tested. Observe the menu titles and on-screen instructions to make correct option selection. 1.1.5 Procedures An arrow icon indicates a procedure. Example: ➢ To power down the MaxiDiag tool Long press the Power/Lock button. Tap Power Off. Tap OK. The tool will turn off in a few seconds.

  • Page 10: General Introduction

    General Introduction There are two main components to the MaxiDiag system: MaxiDiag Tool — the central processor and monitor for the system. ⚫ MaxiVCI V150 Lite — a vehicle OBDII communication interface. ⚫ This manual describes the construction and operation of both devices and how they work together to deliver diagnostic solutions.
  • Page 11 Power/Lock Button — long press to turn on/off the MaxiDiag tool; short press to lock the screen. Table 2-1 Power LED Description Color Description ⚫ Flashes green when the MaxiDiag tool is charging. Green Lights solid green when the MaxiDiag tool is fully ⚫...

  • Page 12: Power Sources

    Figure 2-3 MaxiDiag Tool, Bottom View Micro SD Card Slot USB Type-C Port Microphone 2.1.2 Power Sources The MaxiDiag tool can receive power from any of the following sources: Internal Battery Pack ⚫ AC/DC Power Supply ⚫ Vehicle Power ⚫ IMPORTANT Do not charge the battery when the temperature is lower than 0 °C (32 °F) or higher than 45 °C (113 °F).

  • Page 13: Technical Specifications

    2.1.3 Technical Specifications Table 2-2 Technical Specifications Item Description Operating System Android 9.0 Processor Quad-core processor (1.5 GHz) Memory 2 GB RAM & 64 GB ROM 5.5-inch LCD capacitive touchscreen with 1280 x 720 Display resolution ⚫ Wi-Fi (802.11 a/b/g/n/ac) Connectivity ⚫...

  • Page 14: Maxi Vci V150 Lite - V Ehicle Communication Interface

    2.2 MaxiVCI V150 Lite — Vehicle Communication Interface MaxiVCI V150 Lite is a small vehicle communication interface (VCI) used to connect to a vehicle’s DLC and can wirelessly connect with the MaxiDiag tool for vehicle data transmission. 2.2.1 Function Description Figure 2-4 MaxiVCI V150 Lite Views Power/Connection LED —...

  • Page 15: Other Accessories

    2.2.2 Technical Specifications Table 2-4 Technical Specifications Item Description Communications Bluetooth V5.0 + BR/EDR Wireless Frequency 2.4 GHz Input Voltage Range 8 to 24 V DC Supply Current 500 mA @ 12 V DC Operating Temperature −10 to 50 °C (14 to 122 °F) Storage Temperature −20 to 60 °C (−4 to 140 °F) Dimensions (L*W*H)

  • Page 16: Getting Started

    Getting Started Ensure the tool is sufficiently charged or is connected to an external power supply. (See Power Sources.) NOTE The images and illustrations depicted in this manual may differ slightly from those in the most recent product. 3.1 Powering Up Long press the Power/Lock button on the right side of the tool to power it on.

  • Page 17: Application Buttons

    3.1.1 Status Information Bar The status information bar varies according to the stage of operations, and may display the items described in the table below. Table 3-1 Status Information Bar Icon Name Description Displays the VCI connection status. When the V150 Lite is properly connected to the vehicle and the tool, the VCI VCI Status status icon will display a green “√”...
  • Page 18 Remote Configures the tool to receive remote support using the Desktop TeamViewer application. See Remote Desktop. Autel User Allows you to register an account, view, and edit your Center personal profile, and link your tool. See Autel User Center. Accesses the Battery Test menu with two functions: in- Battery Test vehicle and out-of-vehicle tests.

  • Page 19: System Status Icons

    view the previous or next screen. 3.1.4 System Status Icons By swiping down from the top of the screen, a Shortcuts Panel will appear, allowing you to adjust various system settings of the tool. The operations of each button on the panel are described in the table below.

  • Page 20: Powering Down

    3.2 Powering Down All vehicle communications must be terminated before shutting down the tool. A warning message appears if you attempt to shut down the tool while it is communicating with the vehicle. Forcing a shut-down while communicating may lead to ECU problems on some vehicles.

  • Page 21: Diagnostics

    Diagnostics By establishing a data connection to the electronic control systems of the vehicle being serviced through the VCI (MaxiVCI V150 Lite) device, the Diagnostics application allows you to access the electronic control unit (ECU) for various vehicle control systems, including engine, electrical, and transmission.
  • Page 22 4.1.2.1 Bluetooth Connection Connect the MaxiVCI V150 Lite to the MaxiDiag tool via Bluetooth connection. The Bluetooth connection does not need to repeat the plugging and unplugging procedure, which is unavoidable when using the traditional wired connection, saving more time and providing higher efficiency.

  • Page 23: No Communication Message

    Tap the Home button or Back button on the upper-left corner of the screen to return to the Job Menu. NOTE A VCI device can only be paired with one tool at a time, and once it is paired, the VCI will not be discoverable to other devices.

  • Page 24: Getting Started

    4.2 Getting Started Before beginning the diagnostics process, ensure that a communication connection has been established between the test vehicle and the MaxiDiag tool using the MaxiVCI V150 Lite. See Establishing Vehicle Communication for details. 4.2.1 Vehicle Menu Screen When the MaxiDiag tool is properly connected to the vehicle, it is ready to start vehicle diagnosis.
  • Page 25 Manual VIN Input Automatic Selection Manual Selection 4.3.1 Auto VIN Scan The MaxiDiag tool features the latest VIN-based Auto VIN Scan function to identify vehicles, scan all the diagnosable ECUs, and run diagnostics on the selected system. ➢ To perform an Auto VIN Scan Tap the Diagnostics application on the Job Menu.
  • Page 26 Figure 4-4 VIN Information Screen Review the vehicle information on the screen. Tap Yes to confirm the vehicle profile or tap No to cancel. The tool establishes communication with the vehicle and opens the Main menu. Tap Diagnosis and then select Auto Scan to scan all the test vehicle available systems or tap Control Unit to access a specific system to diagnose.

  • Page 27: Automatic Selection

    4.3.3 Automatic Selection The vehicle VIN can also be automatically acquired after a vehicle manufacturer is selected. ➢ To perform the Automatic Selection Tap the Diagnostics application on the Job Menu. Select a vehicle manufacturer from the Vehicle Menu screen. Select the Automatic Selection option.

  • Page 28: Navigation

    Follow the on-screen instructions to complete the step-by-step selection and finally enter the Vehicle Diagnostics screen. 4.4 Navigation After the test vehicle is identified, the Vehicle Diagnostic screen will display. This section consists of various commonly used functions, including Auto Scan and Control Unit. The available functions displayed vary depending on the test vehicle.
  • Page 29 When encountering an error during testing and diagnosing, use this function to contact Data Logging Autel’s technical support for solutions. The Data Logging function is available in the Diagnostics and the Service applications. See Data Logging for details.

  • Page 30: Screen Messages

    4.4.2 Screen Messages Screen messages will appear when additional input is needed before proceeding. There are three main types of on-screen messages: Confirmation, Warning, and Error. 4.4.2.1 Confirmation Messages Confirmation messages inform you when you are about to perform an action that cannot be reversed or when an action has been initiated and confirmation is needed to continue.
  • Page 31 Figure 4-7 Auto Scan Screen Progress Bar — indicates the test progress. Main Section Column 1 — displays the sequence numbers. Column 2 — displays the scanned systems. Column 3 — displays the diagnostic indicators describing test results:  Fault(s) | #: Fault(s) indicate(s) there is/are detected fault code(s) present; “#” indicates the number of the detected faults.

  • Page 32: Control Unit

    Generates a PDF file based on the current page data. Saves the diagnostics data in a report form. The reports can Save Report be saved locally or uploaded to the Autel cloud platform for sharing. Report Display the DTC status report after scanning the test vehicle.

  • Page 33: Ecu Information

    Figure 4-8 Function Menu Screen Available functions may vary by vehicle. The function menu may include: ECU Information — provides the retrieved ECU information in detail. ⚫ Trouble Codes — retrieves DTCs directly after tapping this button. ⚫ Live Data — retrieves and displays live data and parameters from the vehicle’s ECU. ⚫...

  • Page 34: Trouble Codes

    Figure 4-9 ECU Information Screen 4.6.2 Trouble Codes This function retrieves and displays the DTCs from the vehicle’s control system. The Trouble Codes screen varies for each vehicle being tested. On some vehicles, freeze frame data can also be retrieved for viewing. Figure 4-10 Trouble Codes Screen...
  • Page 35 Generates a PDF file based on the current page data. Saves the diagnostics data in a report form. The reports can Save Report be saved locally or uploaded to the Autel cloud platform for sharing. Search Searches the selected DTC for additional information.
  • Page 36  Tap No to exit. Tap ESC on the Confirmation screen to exit the Erase DTCs function. Tap Trouble Codes again to confirm whether the DTCs have been erased successfully. 4.6.3 Live Data When this function is selected, the screen displays the data list for the selected module. The items available for any control module vary by vehicle.
  • Page 37 Display Mode There are three types of display modes available for data viewing, allowing you to view various types of parameters in the mode best suited to represent the data. Each parameter item displays the selected mode independently. Figure 4-12 Live Data Details Screen The table below describes the three display modes in detail.
  • Page 38 ➢ To select the display mode Tap the Settings icon on the right side of a parameter name to access the Live Data Details screen. Select the display mode you need, and the parameters will display based on your selection. Tap the Restore Default Settings button to return to the default settings if needed.

  • Page 39: Generic Obdii Operations

    Tap the Back button to return to the Live Data screen. 4.7 Generic OBDII Operations This option presents a quick way to check for DTCs, isolate the cause of an illuminated malfunction indicator lamp (MIL), check monitor status prior to emissions certification testing, and perform a number of other services that are emissions-related.

  • Page 40: Function Descriptions

    Figure 4-14 OBDII Diagnostics Function Menu NOTE Tap the button for additional function information. Select a function option to continue. DTC & FFD ⚫ I/M Readiness ⚫ Live Data ⚫ On-Board Monitor ⚫ Component Test ⚫ Vehicle Information ⚫ Vehicle Status ⚫...
  • Page 41 Codes. When the freeze frame data of certain DTCs are available for viewing, a snowflake icon will display on the right side of the DTC item. The Erase Codes and Read codes functions can be applied by tapping the function buttons at the bottom of the screen.
  • Page 42 4.7.2.2 I/M Readiness This function is used to check the readiness of the monitoring system. It is an excellent function to use prior to having a vehicle inspected for state emissions compliance. Selecting I/M Readiness opens a submenu with two choices: Since DTCs Cleared —...

  • Page 43: Exiting Diagnostics

    4.8 Exiting Diagnostics The Diagnostics application remains open as long as there is an active communication with the vehicle. You must exit the diagnostics operation to stop all communications with the vehicle before closing the Diagnostics application. NOTE Damage to the vehicle electronic control module (ECM) may occur if the communication is disrupted.

  • Page 44: Service

    Service The Service application is specially designed to provide quick access to the vehicle systems for various scheduled service and maintenance tasks. The typical service operation screen is a series of menu-driven executive commands. Follow the on-screen instructions to select appropriate execution options, enter correct values or data, and perform necessary actions.

  • Page 45: Oil Reset Service

    Menu that supports that function. Choose a vehicle from the menu, and then select the diagnostics type to enter the Main Menu screen. In the Main Menu screen, you will find two options: Diagnosis and Hot Functions. The Diagnosis option includes Auto Scan and Control Unit, which are identical operations to those found in the Diagnostics application.

  • Page 46: Tire Pressure Monitoring System (Tpms) Service

    Ensure that the EPB control system is reactivated after the maintenance work has been completed. NOTE Autel accepts no responsibility for any accident or injury arising from the maintenance of the Electric Parking Brake system. 5.3 Tire Pressure Monitoring System (TPMS) Service This function allows you to quickly look up the tire sensor IDs from the vehicle’s ECU, as...

  • Page 47: Steering Angle Sensor (Sas) Service

    Vehicles driven a lot at idle speed and low load will attempt to regenerate earlier than those driven with higher load and speed. In order for regeneration to take place, a prolonged high exhaust temperature must be obtained. In the event of the vehicles being driven in such a way that regeneration is not possible, i.e., frequent short journeys, a diagnostic trouble code will eventually be registered in addition to the DPF light and “Check Engine”...
  • Page 48 ⚫ part of the steering system may have occurred. NOTE Autel accepts no responsibility for any accident or injury arising from servicing the SAS system. When interpreting DTCs retrieved from the vehicle, always follow the manufacturer’s recommendation for repair. All software screens shown in this manual are examples, actual test screens may vary by test vehicle.

  • Page 49: Data Manager

    Data Manager The Data Manager application allows you to store, print, and review the saved files, manage the workshop information, and keep test vehicle records. Selecting the Data Manager application opens the file system menu. There are seven main functions available. Figure 6-1 Data Manager Screen...
  • Page 50 Table 6-1 Buttons in Data Manager Button Name Description Test Records Tap to review the test vehicle history records. Workshop Tap to edit the information of workshops. Information Image Tap to review the screenshots. Tap to review the reports stored as PDF format.

  • Page 51: Test Records

    6.1 Test Records This function stores the test vehicle records during diagnostics or service functions. All test information, including the vehicle information and the retrieved DTCs from the previous diagnostics sessions, is summarized and will be displayed in an easy-to-read table listing, from which you can tap one to access to the previously tested vehicle and directly restart a diagnostics session without the need for auto scan or manual vehicle selection.

  • Page 52: Workshop Information

    6.2 Workshop Information The Workshop Information form allows you to edit, input, and save the detailed workshop information, such as shop name, address, phone number, and other remarks, which, when printing vehicle diagnostics reports and other associated test file, will display as the header of the printed documents.

  • Page 53: Image

    6.3 Image The Image section is a PNG database containing all captured screenshots. Figure 6-4 Image Screen ➢ To edit/delete image(s) Tap the Data Manager application on the Job Menu. Select Image to access the PNG database. Tap Edit on the top-right corner of the screen. The editing screen displays. Select the image(s) you want to edit by tapping the check box at the bottom- right corner of the image or tap the Select All button to select all images.

  • Page 54: Pdf

    6.4 PDF The PDF files designated for local viewing are displayed in this section. After entering the PDF database, select a PDF file to view the stored information. ➢ To view, share, and print the PDF files Tap the Data Manager application on the Job Menu. Select PDF to enter the PDF database.

  • Page 55: Report

    6.5 Report This section stores and displays all reports. The reports stored in this area will be uploaded to the Autel cloud automatically when you set the Report Upload to Cloud option in the Settings application to ON. Figure 6-7 Report List Screen...
  • Page 56 ➢ To view the local reports Tap the Data Manager application on the Job Menu. Select Report to access the report list. Select the report you need from the list. A pop-up screen will appear. Select the View Local Reports option. Figure 6-8 View and Share Report Screen The report with detailed information will be displayed.

  • Page 57: Remove Vehicle

    The Data Logging screen keeps records of all Feedback (submitted), No feedback (saved) and History (up to the latest 20 test records) data on the diagnostics system. Autel support personnel will receive and process the submitted reports through the Support platform, and will send back solutions to the corresponding Data Logging session, on which you are also allowed to have a direct conversation with the support personnel.
  • Page 58 Tap on the input field at the bottom of the screen and enter your reply, or tap the Audio button to record a voice message or the Camera button to take a screenshot. Tap Send to deliver your message to Autel support.

  • Page 59: Vci Manager

    VCI Manager The application enables the pairing of the MaxiDiag tool with the MaxiVCI V150 Lite, the communication status checking, and VCI firmware upgrades. Figure 7-1 VCI Manager Screen Function Buttons Bluetooth — pairs the MaxiDiag tool with the MaxiVCI V150 Lite via Bluetooth. ⚫...

  • Page 60: Vci Bluetooth Pairing

    7.1 VCI Bluetooth Pairing The MaxiVCI V150 Lite needs to be connected to a vehicle, so that it is powered during the synchronization procedure. Turn the vehicle’s ignition to the ON position. Ensure the MaxiDiag tool has sufficient battery power or is connected to an external power supply. Refer to Bluetooth Connection for detailed information.

  • Page 61: Settings

    Settings Access the Settings menu to adjust default settings and view information about the MaxiDiag system. The following options are available for the MaxiDiag system settings: BAS Manager ⚫ OBFCM Upload ⚫ Laws and Regulations ⚫ System Settings ⚫ New User Guide Reset ⚫...

  • Page 62: Laws And Regulations

    To ensure the protection of the rights and interests of both software developers and users, we have provided a list of legal terms and statements. Please read them carefully before using Autel software. 8.4 System Settings This function provides you with direct access to the System Settings screen, where you can adjust various system settings for the tool, including wireless and network settings, sound, display, and language settings.

  • Page 63: Print Via Wi-Fi

    Downloads > Autel Update Tools, and install it to your windows-based PC. Double click on the Setup.exe item. Select the installation language and the wizard will load momentarily. Follow the instructions on the screen and click Next to continue. Click on Install and the printer driver program will be installed onto the PC.

  • Page 64: Upload Report To Cloud

    Select the printer from the list, and the file will be automatically sent to the printer for printing. NOTE The printer and the MaxiDiag tool must be using the same network. 8.7 Upload Report to Cloud This option automatically synchronizes the diagnostics information of the vehicle to the vehicle history and forms a diagnostic report for the user to upload.
  • Page 65 Back button to select another option to adjust.

  • Page 66: Update

    Any updates that are found can be downloaded and installed on the tool. NOTE Ensure the tool is registered before utilizing the Update application. See Autel User Center for a comprehensive registration guide. ➢...

  • Page 67: Remote Desktop

    You can use the application to receive ad-hoc remote support from Autel’s support center, colleagues, or friends, by allowing them to control your MaxiDiag tool on their PC via the TeamViewer software.
  • Page 68 ➢ To receive remote support from a partner Power on the MaxiDiag tool. Tap the Remote Desktop application on the Job Menu. The TeamViewer interface displays and the ID is generated and shown. Your partner must install the Remote Control software to his/her PC by downloading the TeamViewer program (full version) online (see http://www.teamviewer.com), and then launch the software.

  • Page 69: Autel User Center

    Tap Autel User Center from the Job Menu. The following screen displays. Figure 11-1 Autel User Center Screen If you already have an Autel account, tap the blue bar or tap Log In with Other Account to log in with your phone number (or email) and password. If you don’t...
  • Page 70 If you have an Autel account, sign in with your account ID and password and skip to step 7. If you are a new member to Autel, click the Register button to create your Autel Enter the required personal information in the input fields.
  • Page 71 check the box to accept the terms. After all the information is entered, click Register. A Product Registration screen will appear. Your product serial number and password are required to complete your registration. To find your serial number and password on the tool: go to Settings ＞About.

  • Page 72: Battery Test

    Battery Test The BT506 is a battery and electrical system analysis tool that uses Adaptive Conductance, an advanced battery analysis method, to produce a more accurate examination of the battery’s cold cranking ability and reserve capacity, vital to determining a battery’s true health. The BT506 battery tester enables technicians to view the health status of the vehicle’s battery and electrical system.
  • Page 73 Table 12-1 LED Description Color Description Flashing Green The tester is communicating via USB cable. Status LED Flashing Blue The tester is communicating via Bluetooth. Battery clamps are connected to the wrong Flashing Red battery terminals. The tester is powered on and the battery is Solid Green sufficiently charged.

  • Page 74: Test Preparation

    12.1.3 Technical Specifications Table 12-2 Technical Specifications Item Description USB 2.0, Type C ⚫ Connectivity Bluetooth 4.2 ⚫ Input Voltage 5 V DC Working Current < 150 mA at 12 V DC Internal Battery 3.7 V/800 mAh lithium-ion polymer battery CCA Range 100 to 2000 A Voltage Range...

  • Page 75: In-Vehicle Test

    Tap Scan at the upper-right corner of the tablet’s screen. The device name may display as “Maxi” suffixed with a serial number. Select the appropriate device for pairing. When paired successfully, the connection status displays the device name with the message “Paired.” ➢...
  • Page 76 IMPORTANT Before using the diagnostic functions, download the desired vehicle software on the Update application. A Disclaimer page will appear when accessing any function on the Battery Test screen for the first time. Please read the end user agreement and tap Accept to continue.
  • Page 77 Figure 12-4 Battery Test Screen Perform OBD connection by following the on-screen instructions. Figure 12-5 OBD Connect Screen Confirm the vehicle information. The vehicle information will be automatically populated when vehicle communication is established. A Battery Information tab will pop up from the bottom of the screen.
  • Page 78 Figure 12-6 Vehicle Information Screen Table 12-3 Upper Toolbar Buttons Button Name Description Back Returns to the previous screen. Returns to the Home screen. Displays the battery connection status. The Battery number on the icon indicates the real-time Connection voltage of the tested battery. Tap Next and access to the Battery screen.
  • Page 79 Figure 12-7 Battery Screen Wait for the battery test to complete and view the test results and suggestions. Figure 12-8 Battery Results Screen...

  • Page 80: Starter Test

    Table 12-4 Test Results Result Description Good Battery Battery is good. Good & Battery is good but insufficiently charged. Recharge the battery. Recharge Charge & Retest Battery requires charge to determine its condition. Bad Cell Replace the battery. Replace Battery Replace the battery.

  • Page 81: Generator Test

    Figure 12-10 Starter Test Results Screen Table 12-5 Starter Test Results Result Description Cranking Normal The starter is good. Current Too Low Low momentary discharge capacity. Voltage Too Low Low battery storage capacity. Not Started The starter is not detected for starting. 12.3.3 Generator Test ➢...
  • Page 82 Figure 12-11 Generator Test Results Screen Table 12-6 Generator Test Results Result Description Charging Normal The generator is good. The belt linking the starter and the generator is loose. ⚫ Output Too Low The cable linking the starter and battery is loose or ⚫...

  • Page 83: Out-Vehicle Test

    12.4 Out-vehicle Test Out-vehicle test is used to test the condition of batteries that are not connected to a vehicle. This function aims to check the health status of the battery only. The battery types and standards able to be tested are as follows. Types: FLOODED, AGM, AGM SPIRAL, EFB, and GEL Standards: CCA, SAE, CA, EN, IEC, DIN, JIS and MCA 12.4.1 Battery Test...
  • Page 84 Figure 12-13 Out-vehicle Test Results Screen Table 12-7 Out-vehicle Test Results Result Description Good Battery Battery meets required standards. Battery is good, but low on charge. Fully charge Good & Recharge the battery. Check for causes of low charge. Charge & Retest Retest after charging.

  • Page 85: Maintenance And Service

    Maintenance and Service To ensure that the tool and the combined VCI device perform at their optimum level, we advise that the maintenance instructions in this section are strictly followed. 13.1 Maintenance Instructions The following includes how to maintain your devices, together with precautions to take. Use a soft cloth dampened with alcohol or mild glass cleaner to clean the tool’s ⚫...

  • Page 86: About Battery Usage

    Your device may not be connected to the charger properly. Check the connector. ⚫ NOTE If the problems persist, please contact Autel’s technical support or your local selling agent. 13.3 About Battery Usage Your tool is powered by a built-in lithium-ion polymer battery, which enables you to recharge your battery when there is electricity left.

  • Page 87: Service Procedures

    This section provides information on technical support, repair service, and application for replacement or optional parts. 13.4.1 Technical Support If you have any question or problem on product operations, please contact us. Autel China Headquarters Phone: +86 (0755) 8614-7779 (Monday-Friday, 9AM-6PM Beijing Time) ⚫ Email: support@autel.com...

  • Page 88: Repair Service

    Web: www.autel.com/br ⚫ 13.4.2 Repair Service If it is necessary to send back your device for repair, please download and fill out the repair service form from www.autel.com. The following information must be included: Contact name ⚫ Return address ⚫...

  • Page 89: Other Services

    Floor 2, Caihong Keji Building, 36 Hi-tech North Six Road, Songpingshan Community, Xili Sub-district, Nanshan District, Shenzhen City, China 13.4.3 Other Services You can purchase the accessories directly from authorized tool suppliers of Autel, or your local distributor or agent. Your purchase order should include the following information: Contact information ⚫...

  • Page 90: Compliance Information

    Compliance Information FCC Compliance FCC ID: WQ8-DV2411 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 91 Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.

  • Page 92: Warranty

    Warranty 12-Month Limited Warranty Autel Intelligent Technology Corp., Ltd. (the Company) warrants to the original retail purchaser of this MaxiDiag tool that should this product or any part thereof during normal usage and conditions, be proven defective in material or workmanship and results in product failure within 1 year period from the date of purchase, such defect(s) will be repaired, or replaced (with new or rebuilt parts) with Proof of Purchase, at the Company’s...
  • Page 93 V1.0 | 2025.05...
