- Page 1 USER MANUAL MODEL - WM-6P Two-way Wall Mounted Passive Speaker P/N: 2900-301840 Rev 1 www.kramerav.com...
-
Page 2: Table Of Contents
Included in the box Overview Models Typical Applications Installation Guide Achieving Best Performance Choosing the Best Location Unpacking Mounting the Speaker Wiring the Speakers – best practice Defining and calculating speaker’s sound pressure levels (SPL) Technical Specifications WM-6P – Contents... -
Page 3: Introduction
European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/il/quality/environment. -
Page 4: Overview
Kramer Electronics Ltd. Overview The WM-6P is a high-end 6.5” wall mounted passive speaker featuring exceptional sound, optimized for conferencing and background music. The speaker supports both 8Ω low impedance as well as several 70V/100V high impedance modes. The speaker is supplied with Kramer’s EasyMount mounting bracket for horizontal and vertical installations as well as for installation in corners, in addition the speaker has standard 75mm VESA mount threads for additional installation options. -
Page 5: Models
Kramer Electronics Ltd. Models Model Part Number Description WM-6P (W) (SINGLE) 60-000131 6.5” Two-way Wall Mounted Passive Speaker, white WM-6P (B) (SINGLE) 60-000132 6.5” Two-way Wall Mounted Passive Speaker, Black Typical Applications WM-6P is ideal for the following typical applications: Conferencing meeting rooms &... -
Page 6: Installation Guide
Dispose of the packaging materials according to regulations. Achieving Best Performance To achieve the best performance: Use only good quality speaker cables (we recommend Kramer high-performance, BC-2S • cables and for plenum installations we recommend the low smoke halogen free cables, BC- 2Sxx/LSHF). -
Page 7: Wiring The Speakers - Best Practice
Long cable runs (up to hundreds of meters) without significant loss. • In high impedance mode the WM-6P supports the following power ratings: Note: at 100V – 30W / 15W / 7.5W at 70V – 30W / 15W / 7.5W / 3.8W WM-6P – Installation Guide... - Page 8 When You Need High SPL or Full-Range Performance • Transformer-based 70V/100V systems often cut low frequencies to protect • transformers and reduce core size. For full-range systems where bass and clarity matter - 8Ω wins. • WM-6P – Installation Guide...
- Page 9 One amplifier can drive dozens of speakers in parallel with no complex impedance matching. Makes zoning and volume control easier with transformers. Figure 2: WM-6P Speaker’s impedance 70V/100V Line Systems In the U.S., 70V audio systems are standard because they stay just under the...
- Page 10 16 AWG / 1.31mm2 Up to 30m / 100ft 12 AWG / 3.31mm2 10 AWG / 5.26mm2 14 AWG / 2.08mm2 Up to 40m / 132ft 10 AWG / 5.26mm2 10 AWG / 5.26mm2 12 AWG / 3.31mm2 WM-6P – Installation Guide...
- Page 11 46m / 150ft (3.31mm 10 AWG 730m / 2400ft 243m / 795ft 146m / 480ft 73m / 240ft (5.26mm Note: These are maximum total distances for the entire run, based on copper cable and a 5% voltage drop. WM-6P – Installation Guide...
- Page 12 Always check amplifier compatibility before connecting (impedance setup, power ratings) Verify that the polarity of the wiring at the amplifier side and at all the speaker is correct, we recommend using color coding: red for + and black for -. WM-6P – Installation Guide...
- Page 13 Kramer Electronics Ltd. Parallel wiring and daisy chain installations Figure 3 - Parallel Wiring Figure 4 -Parallel Wiring - Separate Cables Figure 5 - Daisy Chain Wiring WM-6P – Installation Guide...
-
Page 14: Defining And Calculating Speaker's Sound Pressure Levels (Spl)
Announcements, alarms clarity and safety Depends heavily on Outdoor Areas 75–85 dB SPL Paging, music environmental noise and coverage area High dynamic range required; Auditoriums 80–95 dB SPL Speech, music, live events use zoning and delay speakers WM-6P – Installation Guide... - Page 15 WM-6P with 90dB sensitivity, driven by a 30W amplifier, the sound pressure level 3 meters from the speaker will be: = 90 + 10 ∙ log (30) – 20 ∙ log (3) = 95 dB SPL WM-6P – Installation Guide...
-
Page 16: Technical Specifications
Bracket Aluminium Environmental Operating Temperature: -5°C to +50°C (23°F to 122°F) Storage Temperature: -10°C to +55°C (14°F to 131°F) Humidity 30% to 85%, RHL non-condensing Regulatory Compliance Safety UL1480A, CE, UK CA Environmental RoHS, REACH, WEEE WM-6P – Technical Specifications... - Page 17 Kramer Electronics Ltd. Frequency Response WM-6P Frequency (Hz) Impedance Response WM-6P Frequency (Hz) WM-6P – Technical Specifications...
- Page 18 Kramer Electronics Ltd. WM-6P – Technical Specifications...
- Page 19 For the latest information on our products and a list of Kramer distributors, visit our website where updates to this user manual may be found. We welcome your questions, comments, and feedback www.kramerav.com support@kramerav.com...
