Page 1: User Manual
USER MANUAL MODEL: Galil 2-C Closed-back Ceiling Speakers P/N: 2900-300478 Rev 4 www.kramerAV.com... -
Page 3: Table Of Contents
Getting Started Achieving the Best Performance Recycling Kramer Products Overview Defining the Galil 2-C Installing the Galil 2-C Closed-back Ceiling Speakers Choosing the Best Location Cutting the Ceiling Tile Mounting the Speaker Setting up an Array Installation Painting the Speaker... -
Page 4: Introduction
Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have redesigned and upgraded most of our... -
Page 5: Getting Started
Achieving the Best Performance To achieve the best performance: Use only good quality connection cables (we recommend Kramer high- performance, high-resolution cables) to avoid interference, deterioration in signal quality due to poor matching, and elevated noise levels (often associated with low quality cables) ... -
Page 6: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Overview
Overview The Galil 2-C is a 2.5” full-range high-performance fireproof closed-back speaker with ceramic terminals and a plastic self-extinguishing back-can. The Galil 2-C is specially designed to meet the requirements for fire alarm systems in public spaces. The Galil 2-C speaker features: ... -
Page 8: Defining The Galil 2-C
Defining the Galil 2-C Figure 1 defines the Galil 2-C: Figure 1: Galil 2-C Closed-back Ceiling Speaker Galil 2-C - Overview... -
Page 9: Installing The Galil 2-C Closed-Back Ceiling Speakers
Installing the Galil 2-C Closed-back Ceiling Speakers This section explains how to install the Galil 2-C, that is: Choosing the best place to locate your speaker (see Section 4.1) Cutting the ceiling tile (see Section 4.2) Mounting a Speaker (see Section 4.3) -
Page 10: Mounting The Speaker
The speaker cable should fit the grommet/cable gland with minimum space left (see Figure Make sure you use a UL94 V-0 compliant grommet/cable gland. Galil 2-C - Installing the Galil 2-C Closed-back Ceiling Speakers... -
Page 11: Figure 3: Grommet/Cable Gland Installation
Daisy-chaining: when one input connector is removed, subsequent speakers will be disconnected (see Figure For Array installation, we recommend that you connect to the speaker by passing the audio cable through a second knockout hole. Galil 2-C - Installing the Galil 2-C Closed-back Ceiling Speakers... -
Page 12: Figure 5: Galil 2-C Schematic Diagram
8. Push the spring clamps up as close to the back-can as possible and insert the speaker through the cutout hole. Once inside, the springs are released and clasp the ceiling (from the inside). Figure 6: Pushing the Spring Clamps Galil 2-C - Installing the Galil 2-C Closed-back Ceiling Speakers... -
Page 13: Setting Up An Array Installation
Setting up an Array Installation When installing Galil 2-C in an array installation layout, you have to define the distance between speakers as well as the layout pattern (square or hexagonal). The distance between speakers is set according to the speakers’ dispersion angle, the uniformity of the coverage desired and the budget. -
Page 14: Figure 9: Square Layout Parallel Wiring
Figure 9 shows an example of parallel wiring in a square array installation: Figure 9: Square Layout Parallel Wiring Galil 2-C - Installing the Galil 2-C Closed-back Ceiling Speakers... -
Page 15: Painting The Speaker
When painting after installation: Use the circle that you cut out of the template as a paint mask After you finish painting, remove the paint mask Galil 2-C - Installing the Galil 2-C Closed-back Ceiling Speakers... -
Page 16: Technical Specifications
External diameter: 14.4cm (5.67"); cutout diameter: 12.6cm (4.88") INSTALLATION CLEARANCE: Mounting depth: 9.5cm (3.74") ACCESSORIES: cutout template (on the Web) COLORS: white Specifications are within a 10% tolerance and are subject to change without notice at http://www.kramerelectronics.com Galil 2-C - Technical Specifications... -
Page 17: En 54-24 Requirements
Min. and Max. cross-sectional of Min. cross-sectional area: 0.32 mm square the connected conductors: Max. cross-sectional area: 0.52 mm square Working temperature, climatic -10° to +55°C category: Enclosure protection degree (IP): IP21C Environmental type: TYPE A Galil 2-C - EN 54-24 Requirements... -
Page 18: Speaker Equalizer Requirements
Frequency: 2kHz Frequency: 5kHz Gain : -6dB Gain: +6dB 1/3 Octave (Q: 4.3) 1/3 Octave (Q: 4.3) EQ Graph Shape Figure 10 defines the required EQ graph shape Figure 10: EQ Graph shape – Requirements Galil 2-C - EN 54-24 Requirements... -
Page 19: Mechanical Drawing
Mechanical Drawing Figure 11 shows the Galil 2-C mechanical drawing: Figure 11: Galil 2-C Mechanical Drawing Galil 2-C Electrical Schematic Figure 12 shows the Galil 2-C electrical schematic: Figure 12: Galil 2-C Electrical Schematic Galil 2-C - EN 54-24 Requirements... -
Page 20: Declaration Of Performance
Declaration of Performance Galil 2-C - EN 54-24 Requirements... - Page 21 Galil 2-C - EN 54-24 Requirements...
- Page 23 This page is intentionally left blank...
-
Page 24: Safety Warning
SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback.
