5420 DANIELS STREET STE A, CHINO CA., 91710 · (800) 634-9166 · (909) 628-4722 · FAX (909) 591-2198
MICRO TURN SIGNAL ADAPTER PL ATES
4
3
No.
1
2
3
4
5
RESEARCH&DEVELOPMENT OF AMERICA,
www.yoshimura-rd.com
Suzuki SV650(X)
074BG116700
Item
074BG116700-B
074BG116700-IN
072BGMICRTSR
YRD Micro Combo LED Turn Signal Kit
6MMLN
M6X14BHS
6mm X 14mm Button Head Cap Screw
1
3
2
3
Description
Front Turn Signal Plate
Metal Inner Plate
M6 X 1.0 Nylon Lock Nut
4
3
Qty.
2
2
1
2
2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Yoshimura 074BG116700
Summary of Contents for Yoshimura 074BG116700
- Page 1 RESEARCH&DEVELOPMENT OF AMERICA, 5420 DANIELS STREET STE A, CHINO CA., 91710 · (800) 634-9166 · (909) 628-4722 · FAX (909) 591-2198 www.yoshimura-rd.com MICRO TURN SIGNAL ADAPTER PL ATES Suzuki SV650(X) 074BG116700 Item Description Qty. 074BG116700-B Front Turn Signal Plate 074BG116700-IN...
- Page 2 Place 074BG116700-IN, metal inner plate on the inside of the turn signal holder and orient to match the profile of the turn signal holder and 074BG116700-B, turn signal plate. Secure the assembly using M6X14BHS, button head cap screw and 6MMLN, nylon lock nut.
- Page 3 c) Making sure that the stripped ends are centered, heat the center of the solder shrink connector evenly until the solder begins to liquify. d) Allow to cool completely and tug both ends of the wires to verify that connection is secured. Scan for link to solder shrink connector instruction video.
