Page 1
Keep all stock parts from your existing system as some components may be necessary to install your new Yoshimura exhaust depending on the application. Read through all instructions before beginning installation. Exhaust system can be extremely hot.
4 Slide stock exhaust clamp over inlet of slip-on tail-pipe. (See Fig.3) 5 Remove stock chassis mount insert and insert from outside. (See Fig 4) 6 Install Yoshimura tail-pipe with muffler onto stock header. Fig. 2 7 Bolt tail-pipe to chassis mount using supplied bolt.
Page 3
Insert Spacer with flat 11 Re-install stock heat shield onto stock header and side facing out as shown Yoshimura tail-pipe using stock bolts and washers. Fig.4 12 It is recommended that the muffler and tail-pipe be wiped down with rubbing alcohol to remove oil and Fingerprints.
Part List: Page 4 #2165600-SA Parts Diagram DESCRIPTION PART # Yoshimura Slip-On Tail-pipe Stainless Steel 2165-142 8mm x 25mm Flange Head Bolt M8X25H Stainless Steel Muffler Clamp COS400S8ASD RS-3 Muffler Assembly 8mm x 85mm Socket Head Bolt M8X85 8mm Large Washer...
Page 5
4555 CARTER COURT, CHINO CALIF. 91710 · (800)634-9166 · (909)628-4722 · FACSIMILE (909)591-2198 www.yoshimura-rd.com T E C - S A S p a r k A r r e s t e r C l e a n i n g Information...
Dear Yoshimura Customer, Congratulations and thank you for purchasing a Yoshimura Exhaust System. Over six decades of experience in research and development, state of the art machinery, materials and craftsmanship of the highest quality all come together in a product of exceptional quality and performance—in other words, this is the best thing you can put on your bike.
Page 7
When you are performing periodic maintenance on your vehicle (like a tire change, or an oil change) you can remove your Yoshimura muffler from the vehicle and weigh it again.
Page 8
(found on header and tail-pipe components). 6. Also, feel free to ask through online e-mail at sales@yoshimura-rd.com, or fax your question/problems to (909) 591- 2198. To obtain technical information directly from Yoshimura, call (909) 628-4722.
