Page 1
Yamaha WR250X/R THIS PRODUCT IS NOT DOT APPROVED. Yoshimura R&D of America, Inc. is not liable or responsible for any resulting event caused by the installation of this product. Check with local laws and regulations for compliance prior to installation and use. This product is not intended for use on public highways.
Page 2
Yoshimura LED Rear Turn Signal Kit w/ Relay 070BGUNVTBKT Universal Turn Signal Bracket Kit ** Not shown on diagram. *** The Yoshimura Universal Turn Signal Bracket Kit is to be used with aftermarket stud-mounted turn signals and is sold separately.
Page 3
Removal 3. Install stock left and right turn signals onto (No. 5,6) 13300-TSB-L/R, turn signal brackets. 1. Remove rider seat. 4. Install (No. 5,6) 13300-TSB-L/R, left and right 2. Remove tail by removing the two bolts securing turn signal brackets and (No. 4) 070BG-LPF, tail to frame from above.
