Transmits and receives data between MC220L and
Note:
MC220L could be connected to MC200CM or MC210CS, however, the
SFP module in MC220L must use the same mode and the same
wavelength as the opposite end. (Please refer to the table below) And
the connection fiber must be LC-SC fiber.
Model No.
MC220L connect with
Transmission
SFP module
Media
4.2

Configuration

In order to achieve the aim of effectively expanding a Gigabit Ethernet
network, please take the following examples for reference:
1.
Place two converters back to back between the following end
devices.
MC200CM/MC210CS
MC200CM
850nm, Multi-mode
7
MC210CS
1310nm,
Single-mode
