  • Page 1 4000 1100 ELEGANCE SMART SIMPLICITY STYLE ALLIANCE STYLE CLASSIC SMART HANDICARE 4000 I N S T R U C T I O N INSTRUCCIÓN INSTRUCTIE ANLEITUNG INSTRUCTION ISTRUZIONE Kit delle opzioni motorizzate Kit d’options automatiques Kit für automatische Optionen Set met automatische Opties Kit de opciones automáticas...

  • Page 3: Table Of Contents

    CONTENT 1 - USED TOOLS AND PARTS 2 - UNINSTALL COVERS 3 - POWER SWIVEL KIT 4 - POWERED FOOTREST KIT 5 - PCB 6- REINSTALL COVERS 7 - CHECK...

  • Page 4: Tools And Parts

    TOOLS & PARTS POWERED OPTIONS KIT: LH { AA28964 AA28963 without AA23803 KIT: AA28962 RH { AA28961 without AA23803 KIT: AA28957 AA28695 without AA23803 KIT: AA28963 KIT: AA28961 KIT: AA28695 AA28963 AA23803 AA28961 AA28695 AA23803 13 mm 10 mm 7 mm 10 mm 10 mm 3 mm...
  • Page 5 EXPLANATION Only a technician certified for this lift should install this lift (for more detailled information about the required competence see attachment of the installation manual). G eneral required knowledge can be found in the 4000 Techical Manual. The latest instructions for the lift and instructions for options are available for download at www.handicarepartners.com. [1.1]Check that all the components of the concerning kits are present.

  • Page 6: Uninstall Covers

    UNINSTALL COVERS POWERED OPTIONS 3 mm 3 POWERED OPTIONS KIT SPAREPARTS...
  • Page 7 EXPLANATION [2.1]Loosen the rivets(6x){A} and screws(2x){B} and remove the front cover{C}. [2.2]Disconnect the wire of the battery. [2.1]Maak de pluggen (6x){A} en schroeven (2x){B} los en verwijder de voorkap{C}. [2.2]Maak de draad van de accu los. [2.1]Afloje los remaches (6x) {A} y los tornillos (2x) {B} y retire la cubierta frontal {C}. [2.2]Desconecta el cable de la batería.

  • Page 8: Power Swivel Kit

    POWERED SWIVEL KIT POWERED OPTIONS 13 mm 4 mm 12.13 12.13 5 POWERED OPTIONS KIT SPAREPARTS...
  • Page 9 EXPLANATION POWERED SWIVEL KIT: [3.1]Disconnect all other connections of the seat looms. [3.2]Loosen the bolts and remove the seat. [3.3]Loosen the bolts{A}. Remove the seat cover {B}. AUTOMATISCHE DRAAIFUNCTIE SET: [3.1]Maak alle andere verbindingen van de stoelkabels los. [3.2]Draai de bouten los en verwijder de stoel. [3.3]Draai de bouten los{A}.
  • Page 10 POWERED SWIVEL KIT POWERED OPTIONS ONLY UPGRADE POWERED SWIVEL ONLY UPGRADE POWERED SWIVEL Ph 3 7 POWERED OPTIONS KIT SPAREPARTS...
  • Page 11 EXPLANATION [3.4]ONLY UPGRADE: Open the circlip{A}. Remove the lever{B}. Remove the circlip{C}. [3.5]ONLY UPGRADE: Position the circlip{A}. Open the circlip{B}. Install the release button{C}. [3.6]Preassemble the swivelmotor. [3.7]Fasten the screws of the motor plate. [3.4]ALLEEN UPGRADE: Open de borgring{A}. Verwijder de hendel{B}. Verwijder de borgring{C}. [3.5]ALLEEN UPGRADE: Plaats de borgring{A}.
  • Page 12 POWERED SWIVEL KIT POWERED OPTIONS RIGHT CONFIGURATION LEFT CONFIGURATION 3.7L BLACK 5 mm 26Nm 230 Lb-In 9 POWERED OPTIONS KIT SPAREPARTS...
  • Page 13 EXPLANATION [3.7L]Position the swivelmotor assembly on the seatbase, ensuring that the shaft slots into the bearing bush and the holes are lined up{A}. Place the bolts{B}. [3.7R]Position the swivelmotor assembly on the seatbase, ensuring that the shaft slots into the bearing bush and the holes are lined up{A}.
  • Page 14 POWERED SWIVEL KIT POWERED OPTIONS 4 mm 13 mm 33 Nm 292 Lb-In 3.11 3.10 12.13 3.12 3.13 11 POWERED OPTIONS KIT SPAREPARTS...
  • Page 15 EXPLANATION [3.10]Reinstall the seat cover. [3.11]Keep the seat base in the correct height position and reinstall the seat. [3.12]Reconnect the seat cable. [3.13]Place the warning labels(2x) on the seat base. [3.10]Plaats de stoelkap terug. [3.11]Houd de stoelbasis op de juiste hoogte en installeer de stoel opnieuw. [3.12]Sluit de stoelkabel opnieuw aan.

  • Page 16: Powered Footrest Kit

    POWERED FOOTREST KIT POWERED OPTIONS Torx 20 3 mm 13 POWERED OPTIONS KIT SPAREPARTS...
  • Page 17 EXPLANATION POWERED FOOTREST KIT: [4.1]Install the gearsegment of the footrest. [4.2]Install the footrest motor: ensure the motor gear is correctly meshed with the quadrant{B} and that the foot- plate cable is running behind the motor{A}. [4.3]Fasten the bolts of the footrest motor. [4.4]Unscrew the upper armrest cover{A}.
  • Page 18 POWERED FOOTREST KIT POWERED OPTIONS CLICK! YELLOW YELLOW 15 POWERED OPTIONS KIT SPAREPARTS...
  • Page 19 EXPLANATION [4.5]Remove the cap{A}. Insert the footrest switch{B}. [4.6]Connect the footrest loom to the footrest switch {U15}. [4.7]Reinstall the upper armrest cover{A}. Fasten the cover{B}. [4.8]Connect the footrest loom to the footrest switch{U7} (pay attention to the correct armrest!). [4.5]Verwijder het kapje{A}. Plaats de voetplankschakelaar{B}. [4.6]Sluit de voetenplankkabel aan op de voetenplankschakelaar {U15}.

  • Page 20: Pcb

    POWERED OPTIONS ONLY REPLACEMENT M12 _ 2 M2 _ 3 17 POWERED OPTIONS KIT SPAREPARTS...
  • Page 21 EXPLANATION POWERED OPTIONS KIT: [5.1]Disconnect the wires from the PCB{A}. Remove the PCB{B}. [5.2]Fit the PCB supports(3x). [5.3]Connect the poweropt loom to the PCB{M14}{A}. Place the PCB{B}. Be carefull with touching the print when connecting wires on the PCB and placing the PCB. [5.4]Connect the earth wire (black wire){M2_3}{A}.
  • Page 22 POWERED OPTIONS POWERED FOOTREST POWERED SWIVEL footrest swivel ONLY FOR MAINPRINTS OLDER THAN 2-2025 M12 _ 1 M3 _ 2 19 POWERED OPTIONS KIT SPAREPARTS...
  • Page 23 EXPLANATION [5.5]Connect the swivel motor loom with the PCB (LH Installation to M18, RH Installation to M19). [5.6]Connect the footplate motor loom with the PCB (M15). [5.7]Only for mainprints older than 2-2025: connect the fuse cable to the main PCB. [5.8]Tidy the fuse holder{A} and tidy footplate motor cable{B}.

  • Page 24: 6- Reinstall Covers

    REINSTALL COVERS POWERED OPTIONS 3 mm 21 POWERED OPTIONS KIT SPAREPARTS...
  • Page 25 EXPLANATION [6.1]Reconnect the cable of the battery. [6.2]Reinstall the front cover{A} and secure with the rivets(6x){B} and screws(2x){C}. [6.1]Sluit de kabel van de accu opnieuw aan. [6.2]Herinstalleer de voorkap{A} en zet hem vast met de pluggen (6x){B} en schroeven (2x){C}. [6.1]Vuelva a conectar el cable de la batería.

  • Page 26: Check

    CHECK POWERED OPTIONS CLICK! [7.1]Check the powered swivel function. [7.2]Check the powered footrest function. [7.3]Check the release button: turn the release button and swivel the seat manually. [7.1]Check de automatische draaifunctie. [7.2]Check de automatische voetenplank. [7.3]Check de ontgrendelingsknop: draai op de ontgrendelingsknop en draai de stoel. [7.1]Compruebe la función del giro automático.
  • Page 28 West Midlands DY6 7FJ, United States of America England T +44 (0)1384 408700 T 1.800.791.7999 enquiries@handicare.co.uk sales.us@handicare.com Handicare Monte-escaliers Savaria Canada 4 Rue des Piverts 2 Walker Drive Brampton, ZAC de l’ Aunaie ON L6T 5E1 Canada 91610 Ballancourt-sur-Essonne T 1.905.791.5555 France T 1.855.728.2742...
