Summary of Contents for Savaria Telecab
- Page 1 Telecab Home Lift Owner’s Manual...
- Page 2 IMPORTANT Ensure that only an authorized Savaria Dealer installs and services the Telecab Home Lift. Under no circumstances is anyone other than a dealer with Savaria training and authorization to install, adjust, service or modify any mechanical or electrical device on this equipment. Failure to follow this warning can result in safety system compromises or defeat;...
-
Page 3: Table Of Contents
Maintenance Record ..........23 Part No. 000627, 30-m01-2024 Telecab Owner’s Manual... -
Page 4: Safety Instructions
Ensure that only qualified personnel perform maintenance and service on the unit. • When replacing parts, be sure that only genuine Savaria parts are used. • This unit is intended for use by a mature person who understands its proper operation as set out in this manual. -
Page 5: Description
2. DESCRIPTION Exterior View Figure 1 shows the exterior components of the Telecab. Figure 1 Description Description Tower Hall station (call/send) Floor plug Car operating panel (COP) Emergency telephone Door handles Electromechanical door lock Door latch Non-skid platform Cab door Safety underpan Part No. -
Page 6: Safety Underpan And Floor Plug Sensors
Door Lock and Open Door Sensor The WR-500 lock keeps the cab door locked when the Telecab is operating or not at a landing. The door open sensor prevents the Telecab from moving when the cab door is open. -
Page 7: Safety Brake
Pressing the red Emergency Stop button during travel will stop the lift immediately and activate the alarm. The Emergency Stop overrides the landing stations (hall calls). Pull the Emergency Stop out to return the lift to normal operation. Part No. 000627, 30-m01-2024 Telecab Owner’s Manual... -
Page 8: Manual Lowering And Battery Lowering System
Telecab to the bottom level. The manual lowering box (Figure 5) is located on the side of the Telecab. Pull on the steel cable located inside the manual lowering box to lower the Telecab to the bottom level. -
Page 9: Specifications
3. SPECIFICATIONS Telecab Home Lift Specifications Load capacity 500 lbs. (227 kg) Maximum travel 23 ft (7.0 m) Travel speed 20 ft/min (0.1 m/s) Normal: 30 Heavy: 75 Daily cycle Excessive: 100 Maximum starts in 1 hour on standard installation: 12 Modular 8 ft (2.4 m) base guide rail assembly... - Page 10 Two LED lights in cab Telephone in cab Battery operation in up and down directions Two door concept (left/right access) Custom cab size Optional equipment Custom color Hydraulic door closer Automatic door operator Telecab Owner’s Manual Part No. 000627, 30-m01-2024...
-
Page 11: Using The Device
• The Telecab will stop moving in the up direction if it reaches the floor plug and the floor plug sensor detects an object on it that weighs more than 20 lb (9.1 kg). -
Page 12: Operating From The Landing Station Controls
• The Telecab will stop moving in the up direction if it reaches the floor plug and the floor plug sensor detects an object on it that weighs more than 20 lb (9.1 kg). -
Page 13: Cleaning
Dusting (Metal Surfaces) Dust the painted surfaces with a soft, damp microfiber cloth or chamois. Dry, gritty or previously used cloths may cause surface scratches. Part No. 000627, 30-m01-2024 Telecab Owner’s Manual... -
Page 14: Acrylic Panels
Apply a thin, even coat with a soft clean cloth and polish slightly with cotton flannel or a microfiber towel. Then wipe with a damp cloth to help eliminate electrostatic charges that can attract dust particles. Telecab Owner’s Manual Part No. 000627, 30-m01-2024... -
Page 15: Neutralizing Static (Acrylic Panels)
Natural 100% Citrus Solvent De-greaser • Any citrus-based cleaners. These above lists are for reference only and are not comprehensive. If you have any questions about the acceptability of a specific cleaner, please contact your authorized dealer. Part No. 000627, 30-m01-2024 Telecab Owner’s Manual... -
Page 16: Troubleshooting
Check to see if the Emergency Stop is pushed in; it should be pulled out for normal operation. Telecab does not move. If the Telecab is at the bottom landing, check the floor plug switches as described above. If the Telecab is at the top landing, check the underpan sensor as described above. -
Page 17: Maintenance
6. MAINTENANCE Telecab is subject to wear and tear from use. You must perform the checks and actions in the following tables to ensure safety and proper operation. IMPORTANT Savaria products are only to be installed, adjusted, serviced, or maintained by Savaria licensed dealers and technicians. -
Page 18: Maintenance Schedule (General)
Every Year Heavy: Confirm doors or gates are all self-closing. Every Year Excessive: Every 6 months Normal: Every Year Heavy: Check that the Stop button works correctly Every Year Excessive: Every 6 months Telecab Owner’s Manual Part No. 000627, 30-m01-2024... - Page 19 Every 6 months Normal: Every Year Heavy: Check the safety brake. Every Year Excessive: Every 6 months Normal: Every Year Heavy: Check for oil leaks. Every Year Excessive: Every 6 months Part No. 000627, 30-m01-2024 Telecab Owner’s Manual...
- Page 20 Every Year Excessive: Every 6 months Normal: Every Year Heavy: Ensure that all filler panels (aluminum, Plexiglas or glass) are securely fastened in the enclosure, doors and gates. Every Year Excessive: Every 6 months Telecab Owner’s Manual Part No. 000627, 30-m01-2024...
-
Page 21: Maintenance Schedule (Adjusted)
Maintenance Schedule (Adjusted) Some Jurisdictions have their own state, county or local code that deviate from national code. Please fill out the below information with the requirements of your region: Savaria Job Number: ______________________ Installation Address: ______________________ Verification Adjusted For units with an interlock, the lift should not move if any door is not closed and locked. - Page 22 N.O. contact is open when the relays are not being activated. Check the safety brake. Check for oil leaks. Check the rollers. Ensure that all filler panels (aluminum, Plexiglas or glass) are securely fastened in the enclosure, doors and gates. Telecab Owner’s Manual Part No. 000627, 30-m01-2024...
-
Page 23: Maintenance Record
Maintenance Record Date Time Reason for call Comments Dealer... - Page 24 Telecab Owner’s Manual Part No. 000627, 30-m01-2024...
- Page 25 Owner’s Manual For service or questions about this product, please contact your installing dealer. Dealer Name: Dealer Phone: Authorized Savaria Dealer Savaria Concord Lifts, Inc. savaria.com 2 Walker Drive Brampton ON L6T 5E1 Canada Part No. 000627 ©202 Savaria Corporation...
- Page 26 Telecab Owner’s Manual Part No. 000627, 30-m01-2024...
