Summary of Contents for Savaria Multilift
- Page 1 Multilift Vertical Platform Lift Owner’s Manual...
- Page 2 Failure to follow this warning can resultin safety system compromises or defeat; this can result in serious injury or death. Savaria accepts no liability for property damage, warranty claims or personal injury, including death, in this circumstance.
-
Page 3: Table Of Contents
WARRANTY Ensure your Savaria Dealer provides you with a copy of the manufacturer’s limited parts warranty and documentation relating to any Dealer labour warranty. ------------------------------------------------------------------------------------------------- CONTENTS 1. SAFETY INSTRUCTIONS ..........4 To Ensure Safety . -
Page 4: Safety Instructions
Ensure that only qualified personnel perform maintenance and service on the unit. • When replacing parts, be sure that only genuine Savaria parts are used. • This unit is intended for use by a mature person who understands its proper operation as set out in this manual. -
Page 5: Description
2. DESCRIPTION Exterior View Figure 1 shows the exterior components of the Multilift. Figure 1 Part No. 000609, 30-m01-2024 Multilift Owner’s Manual... -
Page 6: Platform Gate
The safety underpan (shown in Figure 3) is located under the platform. The underpan has sensors that detect any obstacles and stop the downward travel of the lift. This is optional on enclosed units and required on other units. Figure 3 Multilift Owner’s Manual Part No. 000609, 30-m01-2024... -
Page 7: Emergency Stop Button
This mechanism is for emergency use only. After use of any emergency function (access key or manual lowering device), ensure that all doors/gates are secure and locked. While the emergency function is in use, DO NOT leave the area unattended. Figure 4 Part No. 000609, 30-m01-2024 Multilift Owner’s Manual... -
Page 8: Door Locks
Insert the key into the lock and turn it a half turn clockwise to unlock the door. Pull the door open and then turn the key a half turn counter-clockwise to remove it from the lock. Figure 5 Multilift Owner’s Manual Part No. 000609, 30-m01-2024... - Page 9 After use of any emergency function (access key or manual lowering device), ensure that all doors/gates are secure and locked. While the emergency function is in use, DO NOT leave the area unattended. Part No. 000609, 30-m01-2024 Multilift Owner’s Manual...
-
Page 10: Specifications
1 hp (0.75 Kw) motor, 110 VAC Optional 1/2 hp, 12-volt battery model available Control system Electronic-free relay logic controller Beige electrostatic powder coat paint on all steel Finish surfaces and vacuum-formed plastics Multilift Owner’s Manual Part No. 000609, 30-m01-2024... - Page 11 Continuous-pressure type buttons Operating control buttons on platform Manual lowering/raising device Features Low-voltage controls Underpan sensors Non-skid platform surface Automatic access ramp Emergency stop button Battery back-up option Options Savaria Link monitoring option Part No. 000609, 30-m01-2024 Multilift Owner’s Manual...
-
Page 12: Using The Device
If the lift is enclosed, the lift can be operated from the upper landing provided the operator has view of the rider at all times. • During attendant operation, the car directional controls must not be operational. Multilift Owner’s Manual Part No. 000609, 30-m01-2024... -
Page 13: Operating From The Cop Controls
2 Apply constant pressure on the UP/DOWN switch (as required) to move the platform to the desired landing. Note that the Multilift will not move if one of the doors /gates is open. 3 When the lift reaches the landing, the door will unlock automatically (for units with mechanical GAL locks). -
Page 14: Operating From The Landing Station Controls
2 Apply constant pressure on the appropriate button to call the platform to the desired landing. Note that the Multilift will not move if one of the doors/gates is open. 3 When the lift reaches the landing, the door will unlock automatically (for units with mechanical GAL locks). -
Page 15: Troubleshooting
Only qualified technicians are authorized to perform repairs and maintenance. DO NOT manipulate, modify or remove any safety feature of the lift. If any issues persist, please contact your authorized Savaria Dealer Potential Problem Possible Solution Check the underpan sensor. Pull down on the... -
Page 16: Maintenance
6. MAINTENANCE Multilift is subject to wear and tear from use. You must perform the checks and actions in the following tables to ensure safety and proper operation. IMPORTANT Savaria products are only to be installed, adjusted, serviced, or maintained by Savaria licensed dealers and technicians. -
Page 17: Maintenance Schedule (General)
Every 6 months with the key - The key cannot be removed from the lock Normal: Every Year Heavy: Every 6 Verify that all hardware is tightened. months Every Year Excessive: Every 6 months Part No. 000609, 30-m01-2024 Multilift Owner’s Manual... - Page 18 Normal: Every Year Lubricate the acme screw, and upper and lower Heavy: Every 6 bearings using high-quality wheel bearing months Every Year grease. Excessive: Every 6 months Multilift Owner’s Manual Part No. 000609, 30-m01-2024...
- Page 19 Normal: Every Year Ensure that all filler panels (aluminum, Plexiglas Heavy: Every 6 or glass) are securely fastened in the enclosure, months Every Year doors and gates. Excessive: Every 6 months Part No. 000609, 30-m01-2024 Multilift Owner’s Manual...
-
Page 20: Maintenance Schedule (Adjusted)
Maintenance Schedule (Adjusted) Some Jurisdictions have their own state, county or local code that deviate from national code. Please fill out the below information with the requirements of your region: Savaria Job Number: ______________________ Installation Address: ______________________ Verification Adjusted Verify correct operation of the phone (where applicable). - Page 21 Lubricate the acme screw, and upper and lower bearings using high-quality wheel bearing grease. Ensure that all filler panels (aluminum, Plexiglas or glass) are securely fastened in the enclosure, doors and gates. Part No. 000609, 30-m01-2024 Multilift Owner’s Manual...
- Page 22 THIS PAGE WAS INTENTIONALLY LEFT BLANK Multilift Owner’s Manual Part No. 000609, 30-m01-2024...
-
Page 23: Maintenance Record
Maintenance Record Date Time Reason for call Comments Dealer... - Page 24 Owner’s Manual For service or questions about this product, please contact your installing dealer. Dealer Name: Dealer Phone: Authorized Savaria Dealer Savaria Concord Lifts, Inc. savaria.com 2 Walker Drive Brampton ON L6T 5E1 Canada ©202 Savaria Corporation Part No. 000609...
