Eaton 93PX 400V 15–20kVA UPS
User and Installation Guide
p/n: DSD-93PX2406
Revision 01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 93PX Series and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton 93PX Series

Summary of Contents for Eaton 93PX Series

  • Page 1 Eaton 93PX 400V 15–20kVA UPS User and Installation Guide p/n: DSD-93PX2406 Revision 01...

  • Page 2: Suppliers Declaration Of Conformity

    I I n n n n o o v v a a t t i i o o n n , , S S c c i i e e n n c c e e a a n n d d E E c c o o n n o o m m i i c c D D e e v v e e l l o o p p m m e e n n t t C C a a n n a a d d a a N N o o t t i i c c e e This Class A digital device apparatus complies with Canadian ICES-003. CAN-ICES-003A/NMB-003A. ©Copyright 2025 Eaton, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton.
  • Page 3 S S p p e e c c i i a a l l S S y y m m b b o o l l s s The following are examples of symbols used on the product to alert you to important information: RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of electric shock symbol.
  • Page 4 – Determine whether the battery is inadvertently grounded. If inadvertently grounded, remove the source from the ground. Contact with any part of a grounded battery can result in electrical shock. The likelihood of such shock can be reduced if such grounds are removed during installation and maintenance (applicable to equipment and remote battery supplies that do not have a grounded supply circuit).
  • Page 5 • To reduce the risk of overheating the UPS, do not cover the unit’s cooling vents and avoid exposing the UPS to direct sunlight or installing the unit near heat-emitting appliances such as space heaters or furnaces. • Ensure that the UPS is connected only to the appropriate electrical supply system (e.g., TN, IT). Connecting to an incompatible system may result in equipment damage or safety hazards.

  • Page 6: Table Of Contents

    3.3.6 Battery mode............................. 56 3.3.7 Battery Test mode ..........................56 3.3.8 CVCF (Constant Voltage/Constant Frequency) mode .................. 57 3.3.9 Fault mode ............................57 3.3.10 Shutdown mode ..........................57 3.3.11 Automatic Restart ..........................57 Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 7 7 7 S S p p e e c c i i f f i i c c a a t t i i o o n n s s ......................................................... . 7 7 6 6 7.1 Product Specifications ..........................76 Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 8: Introduction

    The Eaton 93PX uninterruptible power system (UPS) delivers an innovative plug-and-play rack mounted three- phase UPS solution that aligns with the growing trend of distributed IT and Edge installations. The Eaton 93PX protects sensitive electronic equipment from the most common power problems, including power failures, sags, surges, brownouts, line noise, high voltage spikes, frequency variations, switching transients, and harmonic distortion.

  • Page 9: Dimensions

    1 1 . . 2 2 D D i i m m e e n n s s i i o o n n s s Figure 1. 93PX15KIPMB / 93PX20KIPMB Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 10 Dimensions Figure 2. 93PX2EBM480U Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 11 Dimensions Figure 3. MBP20KIU Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 12 Dimensions Figure 4. MBP20KIUHW Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 13 Dimensions Figure 5. MBP20KIUPARA Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 14: Physical Features

    (for future use) ⑭ RJ45 MODBUS/BMS ④ LED indicator ⑨ USB communication port ⑲ Parallel cable grounding detection port screw ⑤ UPS rear panel ⑩ RS232 communication port ⑮ Dip Switch Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 15 ② External battery module back panel ⑥ RJ45 port (detects External Battery Module) ③ M6*12 grounding screw ⑦ Battery connection port #2 ④ Battery connection port #1 ⑧ Battery port breakers #1 and #2 Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 16 ④ Neutral breaker ⑪ UPS output connector (L1+L2+L3+N+N+G) ⑤ Maintenance bypass switch ⑫ UPS intput connector (L1+L2+L3+N+N+G) ⑥ MBP back panel ⑬ Cable retention bracket ⑦ RJ45 port (Detect EBM / MBP) Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 17 ④ Neutral breaker ⑪ UPS input connectors (L1+L2+L3+N+N+G) ⑤Maintenance bypass switch ⑫ UPS output connectors (L1+L2+L3+N+N+G) ⑥ MBP back panel ⑬ Cable retention bracket ⑦ RJ45 port (Detect EBM / MBP) Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 18 ⑤ UPS neutral breaker ⑬ UPS #1 input connectors (L1+L2+L3+N+N+G) ⑭ UPS #2 input connectors (L1+L2+L3+N+N+G) ⑥ Maintenance bypass switch ⑦ MBP back panel ⑮ Cable retention bracket ⑧ MBP AC output (L1+L2+L3+N+N+G) Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 19 U U n n p p a a c c k k i i n n g g t t h h e e E E q q u u i i p p m m e e n n t t The Eaton 93PX UPS System can be easily installed in a temperature-controlled indoor environment free from contaminants.

  • Page 20: Unpacking The Equipment

    Unpacking the Equipment Figure 11. Unpacking the UPS and MBP Modules Figure 12. Unpacking the Extended Battery Module Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 21: Package Contents

    Table 6. UPS Package Contents ① 93PX UPS ⑤ UPS parallel cable ② Rail kit ⑥ RS232 cable ③ Quick start guide ⑦ USB cable ④ Mounting ears ⑧ Mounting hardware Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 22 Table 7. EBM Package Contents ① 93PX External Battery Module ⑤ EBM detection cable ② Rail kit ⑥ Mounting hardware ③ Quick start guide ⑦ EBM cable ④ Mounting ears ⑧ EBM lifting strap Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 23 ⑤ MBP detection cable ② Rail kit ⑥ Quantity cable retention brackets (2) ③ Quick start guide ⑦ UPS to MBP quick connection cables (4) ④ Mounting ears ⑧ Mounting hardware Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 24 ⑥Cable retention brackets (2) ② Rail kit ⑦ UPS to MBP quick connection cables (4) ③ Quick start guide ⑧ Mounting hardware ④ Mounting ears ⑨ Cable glands ⑤ MBP detection cable Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 25 ⑥ Cable retention brackets (4) ② Rail kit ⑦UPS to MBP quick connection cables (8) ③ Quick start guide ⑧ Mounting hardware ④ Mounting ears ⑨ Cable glands ⑤ MBP detection cable Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 26: System Mechanical Installation

    R R a a i i l l K K i i t t I I n n s s t t a a l l l l a a t t i i o o n n The Eaton 93PX series supports installation in a rack mount orientation only.
  • Page 27 650–1050 mm. Attach the rear of each mounting rail to the equipment rack enclosure with four M6 screws and washers, and finger-tighten only. See Figure Figure 20. Securing the Rear Rails Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 28 Attach the rack ears to each of the 93PX system components with eight M4 flat head-screws. See Table NOTE NOTE: There are optional installation positions for the rack ears to meet different depth requirements. Figure 21. Rack Ear Installation Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 29 If you are installing an MBP20KIUHW or the MBP20KIUPARA, remove the AC terminal wiring box from the back the unit. Set the box and the screws aside in a safe place. Figure 22. MBP20KIUHW AC Terminal Wiring Box Removal Figure 23. MBP20KIUPARA AC Terminal Wiring Box Removal Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 30 Single UPS System Parallel UPS System Secure each system module to the rack enclosure using four M5 screws and washers. See Figure Figure 25. Secure Each Unit to the Equipment Rack Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 31: Electrical Installation

    8 AWG MBP20KIUPARA 3–3 3 AWG 3 AWG 3 AWG 4 AWG 4 AWG 4 AWG NOTE For input supply connections, use wires suitable for at least 90°C copper or equivalent. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 32 Panel MM Bypass Input Plug Rated Voltage Panel [IN] MM [IN] [IN] Model IEC309-60 (5 380/400/415 40/30.4 3.05m [120 in] 140mm 100mm (5.51in) (3.94in) WIRE) 3Phase 200–415V IP67 Input Connector MBP20KIU Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 33 Loosen the two screws and remove the MBP front cover. Ensure the UPS input circuit breaker is in the OFF (O) position. Figure 26. MBP20KIU Cover Removal UPS INPUT UPS NEUTRAL MAINTENANCE BYPASS SWITCH Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 34 UPS OUTPUT UPS INPUT INTELLEGENT SLOT PARALLEL PORT PARA Install the blue cable retention bracket over the cable connectors on both the UPS and the MBP. Figure 28. Cable Retention Bracket Installation Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 35: Breaker And Wire Sizes

    Input neutral must be wired for proper operation. Failure to connect an input neutral will void the warranty. • The Eaton 93PX UPS is a single-feed UPS only. To hardwire the MBP20KIUHW: Verify that the electrical connections to the installation site have been properly installed.
  • Page 36 For a detailed view, see Figure Connect phase A, B, C, output power wiring from the output terminals and the neutral terminals to the critical load. For a detailed view, see Figure Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 37: Ebm Installation

    DETECT MBP/BATT. AC OUTPUT DETECT Arrows AC INPUT UPS OUTPUT UPS INPUT AC OUTPUT 1 AC OUTPUT 2 AC INPUT PARALLEL PORT PARA PARALLEL PORT 11. Proceed to 2.4.5 EBM Installation. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 38 Input neutral must be wired for proper operation. Failure to connect an input neutral will void the warranty. • The Eaton 93PX UPS is a single-feed UPS only. To hardwire the MBP20KIUPARA: Verify that the electrical connections to the installation site are properly installed.
  • Page 39 Detach the knockouts from the AC terminal wiring box and install the cable glands included in the MBP accessory kit. NOTE The AC terminal wiring box input and output knockout hole sizes are two inches in diameter. Figure 34. MBP20KIUPARA Cable Gland Installation Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 40 10. Remove the UPS Parallel port cover and connect the parallel cables to each UPS, and secure the ground cables to the chassis of each UPS. See Figure Figure 36. Connecting the Parallel Cable PARALLEL PORT PARA PARALLEL PORT PARA Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 41 Figure 38. MBP20KIUPARA UPS Cable Installation MBP/BATT. DETECT MBP/BATT. DETECT AC OUTPUT AC OUTPUT Arrows AC INPUT AC INPUT PARALLEL PORT PARALLEL PORT PARALLEL PORT PARA 13. Proceed to 2.4.5 EBM Installation. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 42 If the UPS will not be operational by the recharge date, it's imperative to contact Eaton (Technical support 1-800-356-5737, option 2, option 4) without delay. •...
  • Page 43 To remove a battery cable, press and hold the release button on the top of each battery cable connector, then gently remove it from the UPS or EBM. Proceed to 4.1 Normal Mode Startup. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 44 Lisez le manuel d'utilisation et les avertissements de sécurité avant utilisation ! Pour une protection continue BATTERY contre les risques d'incendie, PORT 2 remplacez-le uniquement par un fusible du même type. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 45 Lisez le manuel d'utilisation et les avertissements de sécurité avant utilisation ! Pour une protection continue BATTERY contre les risques d'incendie, PORT 2 remplacez-le uniquement par un fusible du même type. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 46 Pour une protection continue BATTERY contre les risques d'incendie, PORT 2 contre les risques d'incendie, PORT 2 remplacez-le uniquement par un remplacez-le uniquement par un fusible du même type. fusible du même type. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 47 Lisez le manuel d'utilisation et les avertissements de sécurité avant utilisation ! Pour une protection continue BATTERY contre les risques d'incendie, PORT 2 remplacez-le uniquement par un fusible du même type. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 48 Pour une protection continue BATTERY contre les risques d'incendie, PORT 2 contre les risques d'incendie, PORT 2 remplacez-le uniquement par un remplacez-le uniquement par un fusible du même type. fusible du même type. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 49 Steady green The UPS is in Line mode or High Efficiency mode. Light off The UPS has no output. It is in Power-on mode, Shutdown mode, or Bypass mode without output. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 50: Control Panel Menu Structure

    C C o o n n t t r r o o l l P P a a n n e e l l M M e e n n u u S S t t r r u u c c t t u u r r e e Figure 48. Menu Structure Initial Settings Screen Main screen Menu screen Meters screen History screen Control screen Settings screen Information screen Maintenance screen Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 51 Figure 50. Select Language Set and confirm a six digit user password in order to access the Settings, Control and History menus. Figure 51. Set the User Password Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 52 LCD will switch back to the main page, and the menus will be locked for five minutes. To reset the password, contact Eaton Support. If password protection is not needed, you can turn it off in Settings menu.
  • Page 53 Battery status Displays battery information. Output information Displays output information. Time Displays the UPS system time. If it does not match the actual time, modify it in Settings → General → Date/Time. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 54 3 3 . . 2 2 . . 4 4 M M e e t t e e r r s s S S c c r r e e e e n n Selecting the Meters screen displays a real-time metering snapshot of the UPS operating parameters. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 55 3 3 . . 2 2 . . 5 5 H H i i s s t t o o r r y y S S c c r r e e e e n n Tap the History icon on the menu page to view the History page and enter the User password to access the History menu. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 56 Figure 59. Event Log To clear the records, select Clear. Use the Clear function carefully. The logs are permanently deleted and cannot be retrieved once the Clear function has been selected. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 57 In a parallel system, there are six different types of control functions. In a single system, there are four control functions. Figure 61. Parallel System Control Screen Figure 62. Single System Control Screen Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 58: Settings Menu

    [English] [French] [German] [Spanish], [English] [Portuguese] [Italian] [Russian] General Menus, status, notices and alarms, UPS fault, Event Log data and settings are in all supported languages. Date/Time [Year: Month:Day] [Hour: Min:Sec] Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 59 Bypass in Standby mode. Auto restart [disabled][enabled] (See 3.3.11 Automatic [enabled] Restart) Clear SC fault [disabled][enabled] (See 3.3.12 Short Fault [disabled] Clearance Function) Overload prealarm 50%~105% (See 3.3.13 Overload Warning) 105% Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 60: External Battery Settings

    [Old Password][New Password][Confirm New 100000-999999 (only 6 Password] digit PIN) Enter the old password and the new password. If the old password is correct, the new password will become active immediately. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 61 • Manual EBM Set -allows for setting the number of battery strings manually. • Manual Ah Set - sets the amp hour rating for the quantity of Eaton external battery modules attached to the UPS. See Table 23 for the recommended settings for the EBM Ah ratings.

  • Page 62: Ups Information Screen

    3 3 . . 2 2 . . 1 1 0 0 U U P P S S M M a a i i n n t t e e n n a a n n c c e e S S c c r r e e e e n n The Maintenance screen is reserved for service personnel only. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 63: Operating Modes

    See Table To run a battery test manually, from the Main Screen press the button and then press the Control Menu icon and enter the password. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 64: Battery Deep Discharge Protection

    Flexible adjustment of low voltage warning points and discharge end points helps achieve deep battery discharge protection. Deep discharge protection is enabled by default. This setting is recommended to avoid damaging the battery. The warranty is void if deep discharge protection is disabled. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 65 In the Rest mode, the battery charger is completely turned off. The battery system receives no charge current during this rest period of approximately 28 days (user-adjustable). During the Rest mode, the open circuit battery voltage is monitored constantly, and battery charging is resumed when necessary. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 66: Normal Mode Startup

    Remove the UPS Neutral breaker cover and verify it is in the ON position. See Figure 68 Figure The MBP neutral breaker must be switched to the ON position prior to applying power to the MBP to prevent damage to the load equipment. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 67 MBP. Switch each of the UPS input breaker(s) to the ON position. The UPS fans will begin to rotate, the LCD will display the Eaton startup animation screen and enter the Initial Settings Screens. (See 3.2.1 Initial Settings Screens).

  • Page 68: Maintenance Bypass Startup

    Switch each of the UPS input breaker(s) to the ON position (See Figure 68 Figure 69). The UPS fans will begin to rotate, the LCD will display the Eaton startup animation screen and display the Initial Settings Screens. (See 3.2.1 Initial Settings Screens).

  • Page 69: Ups Cold Start

    The UPS will operate in battery mode and the buzzer will beep once every ten seconds. Press the power button for approximately one second to turn the UPS off. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 70: Ups Bypass And Shutdown

    10. The UPS will enter the Shutdown mode, the LCD will turn off and the fans will stop rotating. The load equipment will still be energized and is being supported from utility even thought the UPS is shut down. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 71 P P o o w w e e r r M M a a n n a a g g e e m m e e n n t t S S o o f f t t w w a a r r e e Eaton Intelligent Power Protector (IPP) Eaton® Intelligent Power® Protector (IPP) is protection software that gracefully shuts down local computers and servers powered by a UPS in the event of a power outage. IPP acquires information through local or network communication using: •...

  • Page 72: Communication Cards

    EMPDT1H1C2: The EMPDT1H1C2 Environmental Monitoring Probe (EMP) Gen 2 enables you to collect temperature and humidity readings in rack enclosures and monitor environmental data remotely using SNMP or a web browser. It features one temperature, one humidity and two dry-contact status data points. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 73 Remove the intelligent slot cover, which is secured by two screws. See Figure 6 for the intelligent slot location. Insert the communication card into the slot. NOTE It is not necessary to shut down the UPS before installing a communication card. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 74: Communication Ports

    C C o o n n n n e e c c t t i i n n g g t t o o t t h h e e R R S S 2 2 3 3 2 2 o o r r U U S S B B C C o o m m m m u u n n i i c c a a t t i i o o n n P P o o r r t t The UPS has USB and RS232 communication ports for use with Eaton IPP or IPM management software. Use the communication cables included in the UPS accessory kit for communication port connections.

  • Page 75: Relay Contact Port

    Battery disconnected - activates when the UPS external battery is disconnected. Bypass Output - activates when the load is supplied by internal bypass. UPS Normal - activates when the UPS operation is normal. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 76: Battery Replacement

    Replace the EBM with an Eaton-supplied battery module ONLY! Ensure the UPS has been powered off and safely isolated from AC input power before replacing the battery. Although the UPS may be disconnected from the utility power, a hazardous voltage may still be present through the UPS battery.

  • Page 77: Storage

    T T r r o o u u b b l l e e s s h h o o o o t t i i n n g g The Eaton 93PX UPS system has an audible alarm feature to alert you of potential power problems. When activated, the alarm sounds at different intervals according to a particular condition.

  • Page 78: Troubleshooting

    Positive battery is not The battery is not Examine the battery and the battery connected connected. cable. If the battery is damaged, it must be replaced immediately by qualified service personnel. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 79 Byp Wire Wrong The bypass phase Examine the bypass phase number and number is incorrect. 1- connection. or 2-phase loss on the 3-phase bypass input. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 80 Battery voltage is low. Examine the battery. If the battery is damaged, it must be replaced immediately by qualified service personnel. Positive charger fault The UPS charger is not Contact Eaton support. operating correctly. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 81 L3 Output short Contact Eaton support. LCD FW Version Incompatible The LCD FW version is Contact Eaton support. incompatible. Maintenance Bypass The UPS is operating in Maintenance Bypass mode and the loads unprotected. Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 82: Service And Support

    S S e e r r v v i i c c e e a a n n d d S S u u p p p p o o r r t t If you have any questions or problems with the UPS, call your Local Distributor or Eaton Support at one of the following telephone numbers and ask for a UPS technical representative.
  • Page 83 (17.24” X 5.08” X 24.37”) 438 x 129 x 719 38.2 lbs MBP20KIUHW (17.24” X 5.08” X 28.31”) (17.4 kg) 438 x 129 x 719 49.4 lbs MBP20KIUPARA (17.24” X 5.08” X 28.31”) (22.4 kg) Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...

  • Page 84: Product Specifications

    >200V 125–150%: unit will alarm and the load transfers to Bypass mode after one minute (Line Mode) >150%: unit will alarm the and load transfers to Bypass mode after 0.5 seconds Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 85 Mode Line Mode 3201 BTU/H Battery 3486 BTU/H Battery 2490 BTU/H Battery 2429 BTU/H Battery Mode Mode Mode Mode Audible Noise 65dB max Leakage Current <7 mA Communication DB-9 / USB Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 86 3 EBM 42.5 98.5 100% 39.5 39.5 61.5 4 EBM 199.5 One EBM = Two Battery Modules NOTE Battery times are approximate and vary depending on the load configuration and battery charge Eaton 93PX 400V 15–20kVA UPS User Guide DSD-93PX2406—Rev 01...
  • Page 87 DSD-93PX240601 DSD-93PX2406 01...
