Uplus Lighting IP-P150 User Manual

Hide thumbs

Advertisement

Table of Contents

User manual
IP-P150
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP-P150 and is the answer not in the manual?

Questions and answers

Related Manuals for Uplus Lighting IP-P150

Summary of Contents for Uplus Lighting IP-P150

  • Page 1 User manual IP-P150 Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 Technical Specifications………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels …………………………………………………………………………………7-22 Trouble Shooting…………………………………………………………………………………23 Fixture Cleaning………………………………………………………… ………………………23 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit.

  • Page 4: Technical Specifications

    2.Technical Specifications Voltage: AC100-240V, 50/60Hz Power: 150W Light source: 150W RGBLAC 6in1 LED+32x0.2W RGB LED Power consumption: 350W Beam angle: 55° Color temperature: 1800~8500 K DMX Control: 1CH/2CH/3CH/4CH/5CH/7CH/13CH/21CH/RGB10CH RGB15CH/CMY10CH/CMY15CH/9CH/29CH Strobe: 1 ~ 25Hz Display: OLED display IP65 rate Die-cast aluminum alloy housing Aluminum alloy heat dissipation+silent fan Dimension: 235*249*193mm;...
  • Page 5 1.Display panel operation instruction Main First Secondary range illustrate menu menu menu Address 001-512 1CH/2CH/3CH/4CH/6CH/7CH/13CH/21CH/RGB10CH/RGB Mode Channel 15CH/CMY10CH/CMY15CH/9CH/29CH Dimmer 000-255 M effect 00-3 M Speed 000-100 Auto S effect 00-19 S Speed 000-100 S Color Dimmer 000-255 M Red 000-255 M Green 000-255 M Blue...
  • Page 6 Dim Bit 8bit/16bit Standard/Stage/TV Architectural Dim Mode LED dimming speed Theatre /Stage2 Only applicable to color card fading Card Fade 000-255 speed Bulb Effect Shut down/Turn on Dim Freq 2K/5K/7K/9K/12K/14K/16K/19K/22K/25K Output Full power/Low When the power consumption is low, Mode power the fan speed decreases Shut down: Do not enter screensaver...

  • Page 7: Dmx Channels

    4.DMX Channel Channel function Total dimming Channel function Total dimming CCT preset 0-17：Empty 18-85:1800K-8500K(See table below) 86-255:8500K Channel function Total dimming Main light flicker 0-31: LED turn off 32-63: No function 64-95: Normal strobe 96-127: No function 128-159: Slow flashing 160-191: No function 192-223: Random flicker 224-255: No function...
  • Page 8 Channel function Red dimming Green dimming Blue dimming Lemon Amber Cyan Channel function Total dimming Main light adjustment Main light flicker 0-31: LED turn off 32-63: No function 64-95: Normal strobe 96-127: No function 128-159: Slow flashing 160-191: No function 192-223: Random flicker 224-255: No function CCT preset...
  • Page 9 Output mode 25-34: Full power 35-44: Low power(Fan speed decreases) 45-99:empty Refresh rate 100-105:2KHZ 106-111:5KHZ 112-117:7KHZ 118-123:9KHZ 124-129:12KHZ 130-135:14KHZ 136-141:16KHZ 142-147:19KHZ 148-153:22KHZ 154-168:25KHZ 169-200: Empty Dimming curve 201-210: Linear 211-220: square 221-230: Anti-Square 231-240: S-Line 241-255: Restore settings values 13CH Channel function Total dimming...
  • Page 10 Amber Cyan CCT preset 0-17：Empty 18-85:1800K-8500K(See table below) 86-255:8500K Red green ratio 0:0%（Only used for CCT） 1-127:-100% - 0% 128:0% 129-255:0% - +100% Color card 0: Empty 1-179: Color card (See table below) (The following settings will take effect after staying for three seconds) 0-24:empty Output mode...
  • Page 11 21CH Channel function Total dimming Main light adjustment Main light flicker 0-31: LED turn off 32-63: No function 64-95: Normal strobe 96-127: No function 128-159: Slow flashing 160-191: No function 192-223: Random flicker 224-255: No function Red dimming Red fine-tuning Green dimming Green fine-tuning Blue dimming...
  • Page 12 129-255:0% - +100% Color card 0: Empty 1-179: Color card (See table below) (The following settings will take effect after staying for three seconds) 0：empty (The following settings will take effect after staying for three seconds) 0-24:empty Output mode 25-34: Full power 35-44: Low power(Fan speed decreases) 45-99:empty Refresh rate...
  • Page 13 RGB10CH Channel function Total dimming Main light adjustment Main light flicker 0-31: LED turn off 32-63: No function 64-95: Normal strobe 96-127: No function 128-159: Slow flashing 160-191: No function 192-223: Random flicker 224-255: No function Red dimming Green dimming Blue dimming CCT preset 0-17：Empty...
  • Page 14 124-129:12KHZ 130-135:14KHZ 136-141:16KHZ 142-147:19KHZ 148-153:22KHZ 154-168:25KHZ 169-200: Empty Dimming curve 201-210: Linear 211-220: square 221-230: Anti-Square 231-240: S-Line 241-255: Restore settings values RGB15CH Channel function Total dimming Main light adjustment Main light flicker 0-31: LED turn off 32-63: No function 64-95: Normal strobe 96-127: No function 128-159: Slow flashing...
  • Page 15 Red green ratio 0:0%（Only used for CCT） 1-127:-100% - 0% 128:0% 129-255:0% - +100% Color card 0: Empty 1-179: Color card (See table below) The following settings will take effect after staying for three seconds) 0：empty (The following settings will take effect after staying for three seconds) 0-24:empty Output mode...
  • Page 16 CMY10CH Channel function Total dimming Main light adjustment Main light flicker 0-31: LED turn off 32-63: No function 64-95: Normal strobe 96-127: No function 128-159: Slow flashing 160-191: No function 192-223: Random flicker 224-255: No function Cyan dimming Magenta dimming Yellow dimming CCT preset 0-17：Empty...
  • Page 17 124-129:12KHZ 130-135:14KHZ 136-141:16KHZ 142-147:19KHZ 148-153:22KHZ 154-168:25KHZ 169-200: Empty Dimming curve 201-210: Linear 211-220: square 221-230: Anti-Square 231-240: S-Line 241-255: Restore settings values CMY15CH Channel function Total dimming Main light adjustment Main light flicker 0-31: LED turn off 32-63: No function 64-95: Normal strobe 96-127: No function 128-159: Slow flashing...
  • Page 18 Color temperature fine-tuning Red green ratio 0:0%（Only used for CCT） 1-127:-100% - 0% 128:0% 129-255:0% - +100% Color card 0: Empty 1-179: Color card (See table below) (The following settings will take effect after staying for three seconds)0：empty (The following settings will take effect after staying for three seconds) 0-24:empty Output mode...
  • Page 19 Channel function Red dimming Green dimming Blue dimming Lemon tone light Amber tone light Cyan dimming Auxiliary light R dimming, Auxiliary light G dimming Auxiliary light B dimming 29CH Channel function Total dimming Main light adjustment Main light flicker 0-31: LED turn off 32-63: No function 64-95: Normal strobe 96-127: No function...
  • Page 20 Lemon tone light Lemon fine-tuning Amber tone light Amber fine-tuning Cyan dimming Cyan fine-tuning 0-17:Empty 18-255:1800K-8500K Color temperature fine-tuning Red green ratio 0:0%（Only used for CCT） 1-127:-100% - 0% 128:0% 129-255:0% - +100% Color card 0: Empty 1-179: Color card Auxiliary light R dimming, Auxiliary light G dimming Auxiliary light B dimming...
  • Page 21 42-53: Effect 3 (requires color selection for channels 20, 21, and 22) 54-65: Effect 4 (requires color selection for channels 20, 21, and 22) 66-77: Effect 5 (requires color selection for channels 20, 21, and 22) 78-89: Effect 6 (requires color selection for channels 20, 21, and 22) 90-101: Effect 7 (requires color selection for channels 20, 21, and 22)
  • Page 22 74: Black field 75-110: Blue (from dark to bright) 111: Black field 112-147: Red green (from dark to bright) 148: Black field 149-184: Red and Blue (from Dark to Bright) 185: Black field 185-221: Green Blue (from dark to bright) 222: Black field 223-255: Red Green Blue (from dark to bright) (The following settings will take effect after staying...

  • Page 23: Trouble Shooting

    5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
