Uplus Lighting IP-B1820 User Manual

Hide thumbs

Advertisement

Table of Contents

User manual
IP-B1820
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP-B1820 and is the answer not in the manual?

Questions and answers

Related Manuals for Uplus Lighting IP-B1820

Summary of Contents for Uplus Lighting IP-B1820

  • Page 1 User manual IP-B1820 Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ………………………………………………………………………………………5-8 DMX Channels ……………………………………………………………………………………9-11 …………………………………………………………………………………………11 Trouble Shooting……………………………………………………………………………………12 Fixture Cleaning………………………………………………………… …………………………12 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit.

  • Page 4: Technical Specifications

    •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

  • Page 5: Control Menu

    3.Control Menu Display the main interface: 1.Touch panel operation instructions： Display Mode Function Description Address 001—512 Address code settings 2 Channel Mode Channel 6 Channel Mode 8 Channel Mode 11CH 10 Channel Mode DMX Fail Blackout Console Data Blackout Hold Console Data Hold 600HZ 600 Refresh Frequency...
  • Page 6 Speed:00-16 Strobe Speed (static color mixing when the speed is 00) Program Auto Speed:00-16 Color Jump Fade Speed:00-16 Color Gradient Change Sound Sound:01 Sens:0 Voice controlled color change 0-99 Sound:02 Sens:0 Voice controlled mutation 0-99 Sound:03 Sens:0 Voice controlled color change strobe 0-99 Sound:04 Sens:0...
  • Page 7 2.Menu Function Description： Notes： A. In A001 status mode, press and hold the ENTER key for 3 seconds before the program automatically enters current regulation mode. Press ENTER again to select the color (up and down keys to adjust the value), and then press Menu key to return.
  • Page 8 3.Infrared remote control function: 1、Dimming up button 2、Dimming down key 3、OFF light off pause 4、ON operation 5、R、G、B、W、A、UV keys are 6 monochromes. 6、The 0 key is in the A001 console reception mode, and the up and down keys adjust the address 7、1-9 number keys for 9 mixed colors.

  • Page 9: Dmx Channels

    4.DMX Channels 2 CH Mode Channel Function DMX Value Description Total Dimmer 0-255 dimming from dark to bright 0-10 No function 11-20 2000K 21-30 2200K 31-40 2400K 41-50 2600K 51-60 2800K 61-70 3200K 71-80 3600K 81-90 4000K 91-100 4400K 101-110 4800K 111-120 5200K...
  • Page 10 R Dimmer 0-255 Red dimming from dark to bright G Dimmer 0-255 Green dimming from dark to bright B Dimmer 0-255 Blue dimming from dark to bright W Dimmer 0-255 White dimming from dark to bright A Dimmer 0-255 Amber dimming from dark to bright UV Dimmer 0-255 UV dimming from dark to bright...
  • Page 11 CH10 Function 101-150 Gradient mode 151-200 mutation pattern 201-215 Color changing voice control 216-230 Color strobe voice control 231-245 Mutant voice control 246-255 Breathing voice control CH11 Speed 0-255 Speed from slow to fast 5 .Dimension...

  • Page 12: Trouble Shooting

    6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
