- Page 1 User manual 380 Beam Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………4-5 DMX Channels …………………………………………………………………………………6-10 Trouble Shooting…………………………………………………………………………………11 Fixture Cleaning………………………………………………………… ………………………11 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
2.Technical Specifications 380W beam moving head Light source:380w lamp Beam angle: 2° Movement: Pan 540°; Tilt: 250° Color wheel: 14 colors+ open Gobo Wheel: 14 gobos+open Double Prism: 12 prism+48 honeycomb prisms, two prisms can be stacked Frost DMX Channel: 16 CH/20CH Dimension:313*248*530mm;... - Page 5 Fixture operating mode setting Operating mode DMX Ctrl DMX mode, receive DMX signal, RDM signal Auto Run Fixture run automatically according to built-in programs Sound Ctrl When the fixture detects a strong sound, the fixture automatically runs a scene according to the built-in program, otherwise it will stay the last scene Scene Mode 01 runs in a set scene, which supports most of the custom editing of 10 scenes.
-
Page 6: Dmx Channels
4.DMX Channels CH16 Channel Function VALUE Describe White White+colour1 10-14 Colour1 15-19 Colour1+Colour2 20-24 Colour2 25-29 Colour2+Colour3 30-34 Colour3 35-39 Colour3+Colour4 40-44 Colour4 45-49 Colour4+Colour5 50-54 Colour5 55-59 Colour5+Colour6 60-64 Colour6 65-69 Colour6+Colour7 70-74 Colour7 75-79 Colour7+Colour8 [ CH1 ] Colour 80-84 Colour8... - Page 7 [ CH2 ] Strobe 213-251 Rand strobe slow to fast 252-255 Open [ CH3 ] Dimmer 0-255 0-100% dimmer White Gobo1 10-14 Gobo2 15-19 Gobo3 20-24 Gobo4 25-29 Gobo5 30-34 Gobo6 35-39 Gobo7 40-44 Gobo8 45-49 Gobo9 50-54 Gobo10 55-59 Gobo11 60-64 Gobo12...
- Page 8 [ CH8 ] Frost 128-255 Insert frost [ CH9 ] Focus 0-255 Far to near [ CH10 ] 0-255 0-540(degree) [ CH11 ] Pan Fine 0-255 0-2(degree) [ CH12 ] Tilt 0-255 0-270(degree) [ CH13 ] Tilt Fine 0-255 0-1(degree) 0-127 None [ CH14 ]...
- Page 9 115-119 Colour11+Colour12 120-124 Colour12 125-129 Colour12+Colour13 [ CH1 ] Colour 130-134 Colour13 135-139 Colour13+Colour14 140-144 Colour14 145-149 Colour14+Colour15 150-202 Rotate forward (fast to slow) 203-255 Rotate reverse (slow to fast) Dark [ CH2 ] Strobe 4-103 Pluse strobe slow to fast 104-107 Open 108-207...
- Page 10 231-235 Shake slow to fast Gobo9 236-240 Shake slow to fast Gobo10 241-245 Shake slow to fast Gobo11 [ CH4 ] Gobo 246-250 Shake slow to fast Gobo12 251-255 Shake slow to fast Gobo13 0-127 None [ CH5 ] Prism1 128-255 Inert prism1 0-127...
-
Page 11: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
