- Page 1 User manual 37X15Z WASH Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………4-5 DMX Channels ……………………………………………………………………………………6-8 Trouble Shooting…………………………………………………………………………………8 Fixture Cleaning………………………………………………………… ………………………9 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 6: Dmx Channels
4.DMX Channels CH Mode Mode/Channel Value Function Type of control Pan(8bit) 0--255 Proportional Pan movement Pan(16bit) 0--255 Proportional Fine control of pan movement Tilt(8bit) 0--255 Proportional Tilt movement Tilt(16bit) 0--255 Proportional Fine control of tilt movement 0--255 Pan/Tilt speed Proportional Reserved 0--49 To activate following functions,stop in DMX value... - Page 7 0--255 Red fine(16 bit) array 1 Proportional 0--255 Green (8bit) array 1 Proportional 0--255 Green fine(16 bit) array 1 Proportional 0--255 Blue (8bit) array 1 Proportional 0--255 Blue fine(16 bit) array 1 Proportional 0--255 White (8bit) array 1 Proportional 0--255 White fine(16 bit) array 1 Proportional 0--255...
-
Page 8: Trouble Shooting
0--255 Zoom fine(16bit) Proportional 0--31 Shutter closed step 32--63 Shutter open step 64--95 Strobe-effect from slow to fast Proportional 96--127 Shutter open step 128--143 Opening pulses in sequences from slow to fast Proportional 144--159 Closing pulses in sequences from fast to slow Proportional 160--191 Shutter open... -
Page 9: Fixture Cleaning
6.Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. Clean with soft cloth using normal glass cleaning fluid.
