Summary of Contents for Uplus Lighting 3010 IP PAR
- Page 1 User manual 3010 IP PAR Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 2. Technical Specifications………………………………………………………………………4 3. Control Menu ……………………………………………………………………………………5-6 4. DMX Channels ……………………………………………………………………………………6 5. Trouble Shooting…………………………………………………………………………………7 6. Fixture Cleaning………………………………………………………… ………………………7 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Input voltage: AC100-240V, 50/60Hz Rated power: 300W Light source: 30*10W high power LED (4 in 1 RGBW) Channel:5/8 channels Color mixing: RGBW color mixing, colorful infinite change Strobe: 0-20Hz Control: international standard DMX512 Lens angle: 25° Display: OLED function menu with 4 buttons Heat dissipation: intelligent temperature control, active Maximum ambient temperature 40°C Minimum ambient temperature -20°C... -
Page 5: Control Menu
3.Control Menu Display: [MENU] menu selection or return to previous menu. [UP] press [UP] through the menu list to increase/change the value of the current function. [DOWN] press [DOWN] through the menu list to decrease/change the value of the current function. [ENTER] confirm &... -
Page 6: Dmx Channels
Display OFF after 30s no operation Display OFF after 60s no operation No function Reset Parameter restore to factory value Info RGBW/V1.8 Software version 4.DMX Channels DMX channel´ s functions and values (5 DMX channels): Channel Function Description Value Dimmer 0-255 Dimmer,0-100% 0-255... -
Page 7: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
