- Page 1 User manual IP-760S Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels …………………………………………………………………………………7-8 Dimension ………………………………………………………………………………………8 Trouble Shooting…………………………………………………………………………………9 Fixture Cleaning………………………………………………………… ………………………9 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
Installation: •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. -
Page 5: Control Menu
3.Control Menu Main Menu Second Third Fourth DMX Address 001 - 512 Address Settings 001 - 512 Channel mode 24CH Control mode DMX / Master Control Horizontal inversion Off / On Vertical inversion Off / On Focus inversion Off / On Lighting settings Signal processing Reset / Hold... - Page 6 White correction 000 - 255 Motor reset Cancel / Execute Lamp reset Factory settings Cancel / Execute Language settings Chinese / English Display inversion Reverse / Normal Display Settings Display mode 60 seconds / Always on Screen saver mode Off / On Temperature unit Celsius / Fahrenheit...
-
Page 7: Dmx Channels
4.DMX Channels 24CH Mode Channel Function DMX Value Description 0 - 255 Pan fine 0 - 255 Pan fine Tile 0 - 255 Tile Tile fine 0 - 255 Tile fine Motor speed 0 - 255 Motor speed from fast to slow Focusing 0 - 255 Focusing... -
Page 8: Dimension
dimming 0 - 3 Close 4 - 103 Strobe from slow to fast 104 - 107 Open 108 - 207 Pulse from slow to fast Light strip 208 - 212 Open strobe 213 - 225 Slow random strobe 226 - 238 Medium speed random strobe 239 - 251 Fast random strobe... -
Page 9: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
