Uplus Lighting LL06 User Manual

Hide thumbs

Advertisement

Table of Contents

User manual
LL06
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LL06 and is the answer not in the manual?

Questions and answers

Related Manuals for Uplus Lighting LL06

Summary of Contents for Uplus Lighting LL06

  • Page 1 User manual LL06 Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels …………………………………………………………………………………7-10 Product structure…………………………………………………………………………………11 Trouble Shooting…………………………………………………………………………………12 Fixture Cleaning………………………………………………………… ………………………12 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions To ensure proper operation, please read this manual carefully before using the product. After reading it, keep it in a safe place for future reference. The following chapters explain important information about lasers in general, basic laser safety and some tips about how to use this device correctly. Please spend some time reading these information as some of them are critical for safe and efficient operation of this laser display system.

  • Page 4: Technical Specifications

    The laser system contains precision electronic circuitry. Never attempt to disassemble the laser yourself. If the laser is suddenly brought in from the cold into a warm room, condensation may form on the laser and internal parts. If condensation forms on the laser body, do not use the laser as this may damage the laser system.

  • Page 5: Control Menu

    3.Control Menu LCD setting of menu Menu Main menu Setting item Setting instructions Note description DMX address DMX address value DMX Address 1-512 setting ILD program single loop playback Play according to PRG Automatically switch to list order Play mode DMX mode when connected Show Mode to DMX...
  • Page 6 Voice control Voice control sensitivity Sound sense 0-100 sensitivity percentage Animation open content voice SD Sound turn off control switch Brightness Highlight setting Set as a highlight at the Highlight 0-100 setting percentage color junction Locked as input signal Select lock to switch to ILDA from ILDA ILDA mode lock input when using RJ45...

  • Page 7: Dmx Channels

    4.DMX Channels 19CH Channel Function Value Description Dimmer 0-255 Dimmer from dark to bright 0-49 Auto 50-99 Voice control mode Mode selection 100-149 PRG file sequential playback 150-199 ILD file loop playback 200-255 Built-in graphics Graphics Graphic selection, one graphic for every two 0-255 selection values...
  • Page 8 246-255 Voice-controlled irregular jump 0-10 No scaling 11-87 Resize manually Zoom 88-150 zoom 151-200 Zoom out 201-255 Loop zoom No rotation X rotation 1-128 Manual adjustment 129-255 Automatic rotation No rotation CH10 Y rotation 1-128 Manual adjustment 129-255 Automatic rotation No rotation 1-128 Manual adjustment...
  • Page 9 32CH Channel Function Value Description Graphics Graphic selection, one graphic for every two CH20 0-255 selection values 0-63 Normal Display mode 64-127 Highlight display CH21 128-191 Segmented display 192-255 point display 0-16 white 17-33 34-50 green 51-67 blue 68-84 yellow 85-101 purple 102-118...
  • Page 10 No rotation CH27 Y rotation 1-128 Manual adjustment 129-255 Automatic rotation No rotation 1-128 Manual adjustment CH28 Center rotation Automatic clockwise rotation 129-192 193-255 Automatic counterclockwise rotation 0-10 No fade 10-74 Adjust the fader manually 75-104 Auto-grading (increase) Gradual CH29 105-144 Automatic fade (minus) painting...

  • Page 11: Product Structure

    5.Product structure...

  • Page 12: Trouble Shooting

    6.Trouble Shooting To prolong the life of the product, it is very important to do maintenance work. The environment is hash outdoors, or if the product is idle for a long time, damp, smoke or particularly dirty surroundings can cause greater accumulation of dirt on its cover and housing.
