User Manual
ECU-1170
High-Performance All-in-One
Gateway for Battery Energy
Storage Systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECU-1170 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech ECU-1170

Summary of Contents for Advantech ECU-1170

  • Page 1 User Manual ECU-1170 High-Performance All-in-One Gateway for Battery Energy Storage Systems...
  • Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.

  • Page 3: Declaration Of Conformity

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering information.

  • Page 4: Safety Instructions

    SELV output, rated 10 to 30Vdc, 2.7 to 0.9Aminimum and maximum ambient temperature (Tma) 70 degree C minimum without power source or adapter. If you need further assistance, please contact Advantech for further information. Ensure that the voltage of the power source is correct before connecting the equipment to a power outlet.

  • Page 5: Consignes De Sécurité

    If the equipment is used in a manner not specified by the Advantech, the protec- tion provided by the equipment may be impaired. The equipment contains no user-serviceable parts. Do not open, Return to man- ufacturer for servicing. Do not block air ventilation holes.
  • Page 6 Les matériels sont destinés à être installés dans des EMPLACEMENTS À ACCÈS RESTREINT ATTENTION! Danger d'explosion si la batterie est mal remplace. Remplacer unique- ment par le meme type ou equivalent recommandé par le fabricant. Jeter les piles usagées selon les instructions du fabricant. ECU-1170 User Manual...

  • Page 7: Table Of Contents

    Edgelink*..................4 Table 1.4: Edgelink..............4 Table 1.5: ..................4 Software Configurations................4 Table 1.6: Software Configurations ..........4 Chassis Dimensions.................. 5 Figure 1.1 ECU-1170 Chassis Dimensions ......... 5 Packing List....................5 Chapter Hardware Functionality.......7 Overview ....................8 Figure 2.1 ECU-1170 Overview........... 8 LED Status Indicators and Buttons ............
  • Page 8 Table 4.2: 5G Module Assembly ..........31 Figure 4.2 5G Module Assembly ..........32 4.3.3 Mini-PCIe Slot Module Assembly ..........33 Table 4.3: Mini-PCIe Slot Module Assembly ......33 Figure 4.3 Mini-PCIe Slot Module Assembly ......33 ECU-1170 User Manual viii...

  • Page 9: Chapter 1 Overview

    Chapter Overview...

  • Page 10: Introduction

    The ECU-1170 is a purpose-built gateway designed specifically for Battery Energy Storage System (BESS) applications. Featuring integrated multi-I/O interfaces and paired with EdgeLink software, the ECU-1170 supports a wide range of communica- tion protocols, enabling seamless connectivity between various BESS sub-systems.

  • Page 11: System

    4 x Isolated HSD, Source Type, 10-30V, 1A 2 x isolated LSD, Sink Type, 10- (LSD, HSD) 30V, 1A 2000VDC isolation 8 x Isolated relay (Form A): 5A@250VAC; 3A@30VDC Breakdown voltage: 750VAC (Relay Ω Output) Initial insulation 1G at 500VDC Console 1 x RS-232 (RJ-45) ECU-1170 User Manual...

  • Page 12: Edgelink

    Software Configurations Table 1.6: Software Configurations Operating System: Ubuntu 22.04 / Yocto+EdgeLink Programming: IEC-61131-3, Linux C, Python Login Details: User Name: root Password: no password (press "Enter") Default IP: LAN1: 10.0.0.1 LAN2: 11.0.0.1 LAN3: 12.0.0.1 LAN4: 13.0.0.1 ECU-1170 User Manual...

  • Page 13: Chassis Dimensions

    Chassis Dimensions Figure 1.1 ECU-1170 Chassis Dimensions Packing List The accessory package of the ECU-1170 contains the following items: (A) ECU-1170 (B) Connectors (C) Din Rail (D) Screws ECU-1170 User Manual...
  • Page 14 ECU-1170 User Manual...

  • Page 15: Chapter 2 Hardware Functionality

    Chapter Hardware Functionality...

  • Page 16: Overview

    Overview Figure 2.1 ECU-1170 Overview ECU-1170 User Manual...

  • Page 17: Led Status Indicators And Buttons

    Power On Programmable LED 2.2.2 Ethernet Status Indicators Figure 2.3 Ethernet Status Indicators Table 2.2: Ethernet Status Indicators Status Description 10 Mbps Link Orange 100 Mbps Green 1000 Mbps Green Lighting Not transmitting data Green Blinking Transmitting data ECU-1170 User Manual...

  • Page 18: System Button

    Recovery restores the last updated image, not the factory image. Table 2.4: Table 2.4: Recovery Options Yocto + EdgeLink Ubuntu Image that Supports Supported from Supported from 2.8.4.2 and above Recovery 1.0.3 and above Folders/Files that #/home/sysuser/project/elic (license file) None Will Be Retained #/home/sysuser/project/edgelink.lic (license file) ECU-1170 User Manual...

  • Page 19: Chapter 3 Pins, Jumper Settings, And Wiring

    Chapter Pins, Jumper Settings, and Wiring...

  • Page 20: Power Supply

    Power Supply The ECU-1170 supports a power input range of 10~30 VDC DC-In Connector Wiring Must be installed by a skilled professional. Only use copper conductors. Choose the appropriate wire diameter. The terminal block is suitable for a 14 AWG torque value of 7 in-lbf.

  • Page 21: Usb Ports

    USB Ports 3.3.1 1 x USB2.0 HOST, 1 x USB3.0 HOST Figure 3.3 USB Ports Table 3.3: USB Ports USB2.0 Pin Number Description DATA+ DATA- USB3.0 Pin Number Description DATA+ DATA- STDA_SSRX- STDA_SSRX+ Shield GND_DRAIN STDA_SSTX- STDA_SSTX+ ECU-1170 User Manual...

  • Page 22: Usb3.0 Otg (Function Reserved)

    3.3.2 1 x USB3.0 OTG (Function Reserved) Short CN 40 and pins 1-2 of CN1 to enter maskrom mode. Table 3.4: OTG Jumper Settings USB 3.0 USB HOST 1-2 ON 3-4 ON CN40 Figure 3.4 USB3.0 OTG ECU-1170 User Manual...

  • Page 23: Console Ports

    Figure 3.5 Console Ports Table 3.5: Console Ports Pin Number Description Not used Not used Debug Tx Debug Rx Not used Not used Console Configuration Serial Port RS-232 Baud Rate 115200 Parity None Data Bits Stop Bits Flow Control None ECU-1170 User Manual...

  • Page 24: Hdmi Ports

    HDMI Ports Figure 3.6 HDMI Ports Table 3.6: HDMI Ports Description Pin Number Description HDMI1_z_DATA2+ HDMI1_z_CLK- HDMI1_z_DATA2- HDMI1_z_CEC HDMI1_z_DATA1+ HDMI1_DDC_CLK HDMI1_z_DATA1- HDMI1_DDC_DATA HDMI1_z_DATA0+ +V5_HDMI HDMI1_z_DATA0- HDMI1_HPD HDMI1_z_CLK+ ECU-1170 User Manual...

  • Page 25: Can Ports

    2 x CAN bus Figure 3.7 CAN Ports-1 Table 3.7: CAN Ports Description CAN High CAN Low Ports 120Ω Jumper CN26 CN26(1-2) CAN1 CAN2 CN26(3-4) ON: Termination resistor connected OFF: Termination resistor disconnected (default) Figure 3.8 CAN Ports-2 ECU-1170 User Manual...
  • Page 26 Do not input value over range and short unused channel to GND to avoid interfere. Figure 3.9 Analog Input Ports Table 3.8: Analog Input Ports Description Analog Input AGND Analog GND Table 3.9: Voltage/Current Jumper Settings Status Description Voltage (Default) CN29/30 Current Figure 3.10 Voltage/Current Jumper Settings ECU-1170 User Manual...

  • Page 27: Serial Ports

    Table 3.10: Serial Ports Description Pin Number RS-232 RS-485 Data+ Data- Table 3.11: RS-232/485 Jumper Settings Ports Jumper RS-232 RS-485 (Default) COM1 COM2 COM3 CN12 COM4 CN14 COM5 CN17 COM6 CN18 COM7 CN21 COM8 CN22 Figure 3.12 RS-232/485 Jumper Settings ECU-1170 User Manual...
  • Page 28 Table 3.12: RS-232/485 Termination Resistors Ports 120Ω Jumper CN13/20 COM1 CN13(1-2) COM2 CN13(3-4) COM3 CN13(5-6) COM4 CN13(7-8) COM5 CN20(1-2) COM6 CN20(3-4) COM7 CN20(5-6) COM8 CN20(7-8) ON: Termination resistor connected OFF: Termination resistor disconnected (default) Figure 3.13 RS-232/485 Termination Resistors ECU-1170 User Manual...
  • Page 29 Figure 3.14 Digital Input 0~3 (Wet Contacts) -1 Table 3.13: Digital Input 0~3 (Wet Contacts) Definition Digital Input Logic 1: 5~30V Logic 0: 0~2V Input Common IGND Input Ground Figure 3.15 Digital Input 0~3 (Wet Contacts) -2 ECU-1170 User Manual...
  • Page 30 Table 3.14: Digital Inputs 4~19 (Dry/Wet Contacts) Definition Wet: Logic 1: 5~30V Digital Input 4~13,14~19 Logic 0: 0~2V Input Common Dry: Logic 1: Grounding IGND Input Ground Logic 0: Open Circuit Figure 3.17 Digital Input 4~19 (Dry/Wet Contacts) -2 ECU-1170 User Manual...
  • Page 31 Digital Output 0~1 (Low Side Drive) Figure 3.18 Digital Output 0~1 (Low Side Drive) -1 Table 3.15: Digital Output 0~1 (Low Side Drive) Definition Digital Output Output Common OGND Output Ground Figure 3.19 Digital Output 0~1 (Low Side Drive) -2 ECU-1170 User Manual...
  • Page 32 Digital Output 0~3 (High Side Drive) Figure 3.20 Digital Output 0~3 (High Side Drive) Table 3.16: Digital Output 0~3 (High Side Drive) Definition Digital Output Output Common OGND Output Ground Figure 3.21 Digital Output 0~3 (High Side Drive) ECU-1170 User Manual...
  • Page 33 Digital Output 0~7 (Relay Output) Figure 3.22 Digital Output 0~7 (Relay Output) - 1 Table 3.17: Digital Output 0~7 (Relay Output) Pin Number Definition NO (Normal Open) COM (Output Common) Figure 3.23 Digital Output 0~7 (Relay Output) - 2 ECU-1170 User Manual...
  • Page 34 3.14 SD And SIM Slots The ECU-1170 is equipped with 1 x full-size Mini-PCIe and 1 x M.2 B-Key socket. It also includes 1 x SD card and 2 x SIM card slots to the left side of chassis. Figure 3.24 SD and SIM slots Table 3.18: Location of Mini-PCIe and M.2 Socket...
  • Page 35 Chapter Installation...
  • Page 36 Jumper and RTC Battery Location Disassemble the chassis and upper board to set jumpers and replace RTC battery on the lower board. Assemble upper board ECU-1170 User Manual...
  • Page 37 DIN Rail And Wall Mount Installation The wall mount bracket is built-in with the chassis and Din rail is also offered in accessories. To mount the wall plate, use screws of the size M4*6Lmm min, 4pcs. DIN rail mounting screws (4pcs, M3x6L). ECU-1170 User Manual...

  • Page 38: Module Installation

    PO. The set of post and screws is within the BOM of shipment and pre- installed. In the case of 2280, the IO board needs to be removed before installation Table 4.1: M.2 Slot Module Assembly Part Number Description 1960102502T000 Adapter 19350304A0 Screw Figure 4.1 M.2 Slot Module Assembly ECU-1170 User Manual...
  • Page 39 The set of thermal accessories and screws in the below table are upon customer's Table 4.2: 5G Module Assembly Part Number Description 1960116055N001 5G thermal bracket 1990042003N000 Support rubber 1990042007N000 Thermal pad 1930007459-01 Screw for thermal bracket 1930000071 Screw for 5G thermal bracket connected chassis ECU-1170 User Manual...
  • Page 40 Figure 4.2 5G Module Assembly ECU-1170 User Manual...
  • Page 41 PO. The screw for the adapter is pre-installed. Table 4.3: Mini-PCIe Slot Module Assembly Part Number Description EXM-CMPF1-M2E01E M.2 E-Key to mPCIe adapter board 1930000016 Screw Figure 4.3 Mini-PCIe Slot Module Assembly ECU-1170 User Manual...
  • Page 42 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2025...

This manual is also suitable for:

Ecu-1170-551a
