BEC RidgeWave 7000 R28-G User Manual

4g lte-a pro
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
®
RidgeWave
BEC 7000 R28-G
4G LTE-A Pro Outdoor Router
Last revised: April 2021
Version release: v1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RidgeWave 7000 R28-G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BEC RidgeWave 7000 R28-G

Summary of Contents for BEC RidgeWave 7000 R28-G

  • Page 1 User Manual ® RidgeWave BEC 7000 R28-G 4G LTE-A Pro Outdoor Router Last revised: April 2021 Version release: v1.0...

  • Page 2: Copyright Notice

    Copyright Notice Copyright@ 2021 BEC Technologies Inc. All rights reserved. BEC Technologies reserves the right to change and make improvement to this manual at any time without prior notice. No part of this document may be reproduced, copied, transmitted in any form or by any means without prior written permission from BEC Technologies, Inc.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS COPYRIGHT NOTICE ..............................1 SUPPORT CONTACT INFORMATION ........................1 TABLE OF CONTENTS .............................. 2 CHAPTER 1: INTRODUCTION ........................... 1 ............................ 1 NTRODUCTION TO YOUR OUTER & S ............................3 EATURES PECIFICATIONS ............................5 ARDWARE PECIFICATIONS ..............................5 PPLICATION IAGRAM CHAPTER 2: PRODUCT OVERVIEW..........................
  • Page 4 System Restart...............................97 Auto Reboot ..............................98 Diagnostics Tool.............................99 CHAPTER 5: TROUBLESHOOTING........................101 Problems with the Router..........................101 Problem with LAN Interface..........................101 Recovery Procedures............................102 APPENDIX: PRODUCT SUPPORT & CONTACT...................... 103 FCC S ..............................104 TATEMENT ® BEC 7000 R28-G) ..............105 ROFESSIONAL NSTALLATION NSTRUCTIONS IDGE...

  • Page 5: Support Contact Information

    Congratulations on your purchase of the BEC 4G LTE-A Pro Outdoor Router. Rugged Weatherproof Design The RidgeWave® by BEC 7000 R28-G is an industrial-grade outdoor fixed wireless router with an IP68 rated enclosure to withstand extreme weather conditions and harsh rugged deployments. In...

  • Page 6: Table Of Contents

    Support a WEB GUI page to install this device quickly. With this wizard, simple steps will get you connected to the Internet immediately. Firmware Upgradeable Device can be upgraded to the latest firmware through the WEB based GUI. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 7: Features & Specifications

    • Built-in NAT Firewall • Stateful Packet Inspection (SPI) • DoS attack prevention including Land Attack, Ping of Death, etc. • Access control • IP&MAC filter, URL Content Filter • Password protection for system management RidgeWave® BEC 7000 R28-G User Manual...
  • Page 8 • Firmware upgrades and configuration data upload and download via web-based GUI • Supports DHCP server / client / relay • Supports SNMP v1, v2, v3, MIB-I and MIB-II • TR-069 supports remote management ® Cloud-base Management Platform • BECentral RidgeWave® BEC 7000 R28-G User Manual...

  • Page 9: Hardware Specifications

    • Dimensions (W*H*D): 12.6" x 12.6" x 2.91" (320mm x 320mm x 74mm) • Weight: < 1.5kg • IP-67 Grade Enclosure and Vent integration enclosure • Top cover material UL-746C compliant for UV-resistant • Surge Protection: K.21 enhanced mode 6KV Application Diagram RidgeWave® BEC 7000 R28-G User Manual...

  • Page 10: Chapter 2: Product Overview

    Use the supplied PoE (Power-over-Ethernet) injector for indoor only or with any 802.3at capable PoE injectors to connect with the RidgeWave® BEC 7000 R28-G It is mandatory to earth ground the BEC 7000 R28-G. Improper Attention grounding not only could damage the unit but also all equipment connected to it.

  • Page 11: Device Description

    RSSI from -99 to -81 dBm. Fair signal condition Signal Flashing quickly Strength Orange RSSI less than -99 dBm. Poor signal condition Flashing slowly Orange No signal. 4G/LTE module is still in connected mode No 4G/LTE module or 4G/LTE module has failed RidgeWave® BEC 7000 R28-G User Manual...

  • Page 12: Mounting Kit Installation - Using Lp2S Mounting Kit

    Bracket x 1 Attach the Stainless-Steel Bracket to the Enclosure Attach the stainless-steel bracket to the back of the BEC 7000 R28-G enclosure then use the supplied M6 Washer, Spring Washer, and M6x15 screws in the mounting kit to screw the bracket tightly.
  • Page 13 (1” ~ 3”). Use a flat-head screwdriver to turn the head of the screw clockwise to tighten it. The BEC 7000 R28-G must be directed towards the nearest base station. Completed RidgeWave® BEC 7000 R28-G User Manual...
  • Page 14 Product Overview Mounting Kit Installation – Using LP2S Kit Proper Grounding to Complete the Installation Attach the grounding wire to the BEC 7000 R28-G and tighten the screw. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 15: Mounting Kit Installation - Using Rt4R Mounting Kit

    Stainless Hose Clamp 1”-3” x 2 W-Bar x 1 15. M6 Washer x 2 16. M6 Spring Washer x 2 M6 x 60 Screw Bolt x 2 M6 Washer x 2 M6 Spring Washer x 2 RidgeWave® BEC 7000 R28-G User Manual...
  • Page 16 Mounting Kit Installation – Using RT4R Kit Attach the Articulation Pole to the Enclosure Attach the articulation pole to the back of the BEC 7000 R28-G enclosure using the supplied M6 screws, M6 spring washers and M6x16 screws which are included in the mounting kit.
  • Page 17 Product Overview Mounting Kit Installation – Using RT4R Kit Note: The flexible mounting kit can be adjusted in multiple angles to align with the base station for higher efficiency. 45∘ 45∘ ∘ ∘ RidgeWave® BEC 7000 R28-G User Manual...
  • Page 18 2”, it can cause a gradually increase the bolt failure very fast. If diameter is load on both sides. smaller than 1.5”, the clamping force might be insufficient in holding the device to the pole. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 19 3. Attach the BEC 7000 R28-G Enclosure to the Pole Attach the articulation pole (BEC 7000 R28-G enclosure) to the T-formed bracket using the supplied M8 nut, M8 spring washer, M8 washer and M8x40 screw bolt.
  • Page 20 Attach the grounding wire to the BEC 7000 R28-G and tighten the screw. 5. Position Adjustment Adjust the BEC 7000 R28-G until it reaches the desire elevation and depression angle, then tight the M8 nut (see Attach the BEC 7000 R28-G Enclosure to the Pole for more information) 40°...

  • Page 21: Router Installation Instructions

    Product Overview Router Installation Instructions Router Installation Instructions 1. Power on your BEC 7000 R28-G Step 1: Assemble M25 cable gland Step 2: Unscrew the LAN (PoE) cap then insert an outdoor Ethernet cable (RJ-45) through material A-D, and then connect the RJ-45 Ethernet cable into the LAN (PoE) port.
  • Page 22 IMPORTANT: It is recommended to put the Gigabit PoE Injector on an UPS or Surge Protector. Use a grounding wire to ground your BEC 7000 R28-G is REQUIRED! 2. Set up your 4G/LTE Internet Connection Step 1: Unscrew the cap of SIM card slot.
  • Page 23 Product Overview Router Installation Instructions Step 3: Screw the cap back tightly. Please power off the device before inserting or removing the SIM card. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 24: System Recovery Procedures

    System Recovery Procedures System Recovery Procedures The purpose is to allow users to restore the BEC 7000 R28-G to its initial stage when the device is outage, upgraded to a wrong / broken firmware, cannot access to the GUI with wrong username and/or password, etc.

  • Page 25: Chapter 3: Basic Installation

    If not, please refer to your Windows-related or other operating system manuals. Any TCP/IP capable workstation can be used to communicate with or through the BEC 4G/LTE ODU. To configure other types of workstations, please consult the manufacturer’s documentation.

  • Page 26: Network Configuration - Ipv4

    When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 27 Obtain an IP address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 28: Configuring Pc In Windows 7/8 (Ipv4)

    When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 29 Obtain an IP address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 30: Configuring Pc In Windows Vista (Ipv4)

    Center at the top bar. When the Network Sharing Center window pops up, select and click on Manage network connections on the left windowpane. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 31 Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 32: Network Configuration - Ipv6

    When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 33 Obtain an IPv6 address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 34: Configuring Pc In Windows 7/8 (Ipv6)

    When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 35 Obtain an IPv6 address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 36: Configuring Pc In Windows Vista (Ipv6)

    Center at the top bar. When the Network and Sharing Center window pops up, select and click Manage network connections left windowpane. Select the Local Area Connection, and right click the icon to select Properties. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 37 Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 38: Default Settings

    Device LAN IP Settings IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 DHCP Server: DHCP server is enabled. Start IP Address: 192.168.1.100 IP pool counts: 100 RidgeWave® BEC 7000 R28-G User Manual...

  • Page 39: Information From Your Isp

    Before configuring this device, you have to check with your ISP (Internet Service Provider) what kind of service is provided, Dynamic IP address, Static IP address, PPPoE or Bridge Mode). Gather the information as illustrated in the following table and keep it for reference. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 40: Chapter 4: Device Configuration

    The default username and password are “admin” and “admin” respectively for the Administrator. NOTE: This username / password may vary by different Internet Service Providers. Congratulations! You have successfully logged on to your BEC 7000 R28-G RidgeWave® BEC 7000 R28-G User Manual...
  • Page 41 Device Configuration Login to the GUI Once you have logged on to your BEC 7000 R28-G via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you...

  • Page 42: Status

    Model Name: Name of the router for identification purpose. Firmware Version: Software version currently loaded in the router MAC Address: A unique number that identifies the router Data-Time: Setup correct time on the BEC 7000 R28-G with your PC. Check on Time Zone section for more configuration information.
  • Page 43 DHCP Server: Display LAN DHCP status of IPv4 and IPv6. Enable / 192.168.1.100~199: DHCPv4 server status on or off / DHCP IP range Enable / Stateless: DHCPv6 server status on or off / DHCPv6 server Type RidgeWave® BEC 7000 R28-G User Manual...

  • Page 44: System Status

    Memory Total / Free / Cached (in Kbyte): Display the memory consumptions in kilobytes (kB). Click Refresh button to update the status. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 45: System Log

    In system log, you can check the operations status and any glitches to the router. Refresh: Press this button to refresh the statistics. Backup: Press to save the System log, log.cfg, to your PC. Backup Last System Log: Press to save the last log saved in the system. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 46: 4G/Lte Status

    Auto Refresh: Select Disable or Enable to reload the mobile status information. Refresh: Click to refresh the statistics. Usage Allowance To enable this feature, please go to Configuration >> Interface Setup >> Internet >> click “Usage Allowance” >> enable “Save the statistics to ROM” RidgeWave® BEC 7000 R28-G User Manual...
  • Page 47 Amount Used: Display the amount of mobile data used and remaining in current billing cycle. Billing Cycle: Display the start date and number of days remaining in current billing cycle. Clean: Reset current saved mobile usage. Save: Click to save current mobile status to ROM. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 48: Statistics

    Receive Speed: Display the data rate receives from the mobile Internet. Refresh: Click to manually refresh the data. Auto Refresh: Select a time interval to refresh the data automatically or none to disable the feature. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 49 Receive Speed: Display the data rate receives from the Broadband Internet Service Provider Refresh: Click to manually refresh the data. Auto Refresh: Select a time interval to refresh the data automatically or none to disable the feature. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 50: Dhcp Table

    MAC Address: The MAC address of a device, e.g. PC, notebook, printer, etc., that is corresponded with the IP address. VRRP Status Current Status: Display current VRRP status, Master or Backup. Current Master: Display the IP address of the Master RidgeWave® BEC 7000 R28-G User Manual...

  • Page 51: Quick Start

    Once changed, please use this new password next time when accessing to the router. Click NEXT to continue. Step 2 – Time Zone Choose your time zone. Click NEXT to continue. Step 3 – ISP Connection Type Set up your 4G/LTE Internet connection. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 52 The Setup Wizard has completed. Click on BACK to make changes or correct mistakes. Click NEXT to save the current settings and complete the Quick Start setups. Go back to the Status > Device Info to view the status. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 53: Configuration

    Here are the features under Interface Setup: Internet, LAN, IPv6-464XLAT and Loopback. Internet 4G/LTE WAN Interface: List all available WAN interfaces. (In this section, you have selected to use 4G-LTE) Status: Choose Activated to enable the 4G/LTE connection. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 54 Once the feature is turned on, you can see the amount of data used and how many days left before next billing cycle starts. Go to Status >> 4G/LTE Status page for details. NOTE: This statistic information will get deleted after a factory reset. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 55 Interface Setup – Internet (4G/LTE) Disable: No action taken IP Pass-Through Mode: When enabled, BEC 7000 R28-G in bridge mode and will not obtain a WAN IP address, features such as routing capabilities, NAT, firewall, etc., will be disabled by default.

  • Page 56: Lan

    - OUT only means the router will only send but will not accept RIP packet. DHCPv4 Server DHCP (Dynamic Host Configuration Protocol) allows individual clients to obtain TCP/IP configuration at start-up from a server. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 57 If set to Disabled, the DHCP server will be disabled. If set to Relay, the BEC 7000 R28-G acts as a surrogate DHCP server and relays DHCP requests and responses between the remote server and the clients. Enter the IP address of the actual, remote DHCP server in the Remote DHCP Server field in this case.
  • Page 58 (MAC address) and information (prefix) advertised by routers, but they can obtain such information like DNS from DHCPv6 Server. Stateful: If selected, the PCs in LAN will be configured like in IPv4 mode, thus obtain addresses RidgeWave® BEC 7000 R28-G User Manual...
  • Page 59 Router Advertisement messages periodically which would multicast the IPv6 Prefix information (similar to v4 network number 192.168.1.0) to all LAN devices if the field is enabled. We suggest enabling this field. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 60: Ipv6-464Xlat

    Destination IPv6 Prefix: if select Manually, enter the IPv6 prefix of the PLAT. If you are not sure what to do with this field, select Automatically; device will request the IPv6 prefix from your internet service provider. Click Save to apply settings RidgeWave® BEC 7000 R28-G User Manual...

  • Page 61: Loopback

    Telnet management IP and involved in BGP as BGP Update-Source and OSPF as Router ID. IP Address: Enter a dedicated IP address for the loopback interface. IP Subnet Mask: Enter the subnet mask for the loopback interface. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 62: Advanced Setup

    SPI: If you enabled SPI, all traffics initiated from WAN would be blocked, including DMZ, Virtual Server, and ACL WAN side. Enabled: It activates your SPI function. Disabled: It disables the SPI function. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 63: Routing

    Metric: It represents the cost of transmission for routing purposes. The number need not be precise, but it must be between 1 and 15. Click Save to add this route RidgeWave® BEC 7000 R28-G User Manual...

  • Page 64: Dynamic Routing

    However, area border routers do not need to be physically connected to the backbone - connection to it may be simulated using a virtual link. Click Save to apply the settings. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 65 AS number are the same, thus, an inter-AS communication, please enable the allowas-in. Otherwise, the router only support EBGP routing between different domains. Next-Hop-Self: Enable to use the router’s own loopback address as the next-hop address. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 66: Nat

    Service Index: Associated to EWAN interface marking each EWAN service (0-7), to select which EWAN service the DMZ and Virtual server are applied to. Click DMZ or Virtual Server to move on to set the DMZ or Virtual Server parameters, which are represented in the following scenario. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 67 Example: Skip port 80 (UDP/TCP) in the list. All Incoming request to access to port 80 (Web GUI) will be forwarded to the embedded HTTP server of BEC 7000 R28-G instead of the DMZ host. Click Add to add an entry to the Except Listing.
  • Page 68 Configure a virtual rule in BEC 7000 R28-G for remote users accessing services such as Web or FTP services via the public (WAN) IP address that can be automatically redirected to local servers in the LAN network.
  • Page 69 IP addresses that are to be issued by the DHCP server. You can configure the virtual server IP address manually, but it must still be in the same subnet as the router. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 70 Enter the static IP assigned to the local PC that is hosting the FTP server. Ex: 192.168.1.102 Enter “21” to Local Start and End Port number. The BEC 7000 R28-G will forward port 21 request from WAN to the specific LAN PC (Example: 192.168.1.102) in the network.

  • Page 71: Vrrp

    When deactivated, the lower priority backup is left in the master state. VRIP: An IP address which is associated with the virtual router. Advertisement period: Indicates the time interval in seconds between advertisements. Default in 1 second. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 72: Static Dns

    192.0.32.10 (IPv4). IP Address: The IP address you are going to give a specific domain name. Domain Name: The friendly domain name for the IP address. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 73: Qos

    Index: The rule indicator (1-32) for identifying each host device. MAC Address: Enter the host’s MAC address. For example: 00:04:ed:12:34:56 Upload / Download (Bandwidth): Enter maximum available upload and download bandwidth for the specific device. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 74 Rate: Specify the date rate in Kbps. Priority: Set the priority given to each policy/application. Specify the priority for the use of bandwidth. You can specify which application can have higher priority to acquire the bandwidth. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 75 External Port: The Port number on the remote / WAN side. Click Save to apply settings. To Remove a Policy: Simply select the Index then hit the Delete button to remove from the list. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 76: Time Schedule

    End Time: The ending point of the interval for the timeslot, anytime in 00:00 – 24:00. Click Save to apply your settings. Example, you can add a timeslot named “TimeSlot1” which features a period from 9:00 of Monday to 18:00 of Tuesday. Another TimeSlot2 RidgeWave® BEC 7000 R28-G User Manual...

  • Page 77: Mail Alert

    WAN IP change has been detected. Recipient’s Email (4G/LTE Usage Allowance): Enter a valid e-mail address to receive an alert message when the 4G/LTE over Usage Allowance occurs. Click Apply button to save settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 78: Access Management

    80, e.g. port 8080. HTTPS Port: Similar to HTTP which is an unencrypted communication using port 80. HTTPS is encrypted by SSL using port 443 instead. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 79: Snmp

    Authentication Protocol: Select the authentication protocol, MD5 and SHA. SNMP agent can communicate with the manager station through authentication and encryption to secure the message exchange. Set the authentication and encryption information here and below. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 80 Access Management – SNMP Authentication Key: Set the authentication key, 8-31 characters. Privacy Protocol: Select the privacy mode, DES and AES. Privacy Key: Set the privacy key, 8-31 characters. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 81: Syslog

    Remote System Log: Select Activated to enable this feature Server IP Address: Assign the remote log server IP address. Server UDP Port: Assign the remote log server port, 514 is commonly used. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 82: Universal Plug & Play

    Auto-configured: Select this check box to allow UPnP-enabled applications to automatically configure the BEC 7000 R28-G so that they can communicate through the BEC 7000 R28-G, for example by using NAT traversal, UPnP applications automatically reserve a NAT forwarding port in order to communicate with another UPnP enabled device;...

  • Page 83: Dynamic Dns (Ddns)

    Wildcard support: Select this check box to enable DYNDNS Wildcard. Period: Set the time period on how often the BEC 7000 R28-G will update the DDNS server with your current external IP address. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 84 If you do not have an account with Dynamic DNS, please go to www.dyndns.org to register an account first. User test1 register a Dynamic Domain Names in DDNS provider http://www.dyndns.org/ DDNS: www.hometest.com using username/password test/test RidgeWave® BEC 7000 R28-G User Manual...

  • Page 85: Access Control

    Active: Yes to activate the rule. Secure IP Address: The default 0.0.0.0 allows any client to use this service to manage the BEC 7000 R28-G. Type an IP address range to restrict access to the client(s) without a matching IP address.
  • Page 86 Default Rule 1: (Index 1), a rule to allow only clients from LAN to have access to all embedded applications (Web, FTP, etc.). Under this situation, clients from WAN cannot access the router even from Ping. Default Rule 2: (Index 2), an ACL rule to open Ping to WAN side. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 87 Device Configuration Access Management – Access Control RidgeWave® BEC 7000 R28-G User Manual...

  • Page 88: Packet Filter

    Type: Choose type of field you want to specify to monitor. Select “IPv4” for IPv4 address, port number and protocol. Select “IPv6” for IPv6 address, port number and protocol. Select “MAC” for MAC address. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 89 Destination Port Number: This is the Port or Port Ranges that defines the application. DSCP: show the set DSCP. Protocol: It is the packet protocol type used by the application. Select either TCP or UDP or ICMP or ICMPv6 RidgeWave® BEC 7000 R28-G User Manual...
  • Page 90 Source MAC Address: show the MAC address of the rule applied. Time Schedule: Select a TimeSlot to activate the rule. Go to Time Schedule to configure a time control first. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 91 URL (Host): Specified URL which is prohibited from accessing. Time Schedule: Select a TimeSlot to activate the rule. Go to Time Schedule to configure a time control first. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 92 Domain Filter Rule Index: The indication of the rule number. Individual Active: Click Yes to enable this rule/policy. Domain: Enter the domain name in the blank field to be allowed or prohibited. Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 93: Cwmp (Tr-069)

    CWMP: Select activated to enable CWMP. ACS Login Information URL: Enter the ACS server login URL. Username: Specify the ACS Username for ACS authentication to the connection from CPE. Password: Enter the ACS server login password. RidgeWave® BEC 7000 R28-G User Manual...
  • Page 94 Bind WAN Interface Interface: Specify any available or a single WAN interface to handle TR-069 requests. NATT Config - This is a proprietary feature provided by BEC. May leave them in blank, no configuration is required. NATT Server: By BEC administrator only.

  • Page 95: Parental Control

    Host Name: It is the domain name of your OpenDNS. If you don’t have one, please leave it blink. Username / Password: Put down your OpenDNS account username and password Click Save to apply settings. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 96: Becentral Management

    BECentral Management Port: Port listened by the BECentral. Organization ID: Customer ID (By BE C administrator only) Tag ID: By BEC administrator only. Device Report Interval: Enter the interval time in seconds to send inform message periodically to the BECentral.

  • Page 97: Maintenance

    The User account is with limited access (specified by advanced users with admin account) to the GUI. Total of 8 accounts can be created to grant access to manage the BEC 7000 R28-G via the web page. Administrator Account admin/admin is the root/default account username and password.
  • Page 98 Guest Account: Enable to create this new guest account and select features to allow user account to access to. When someone accesses to the BEC 7000 R28-G using this “user” account, he/she can only manage and configure the features that is pre-selected in Web GUI Permission for this account.

  • Page 99: Time Zone

    With default, BEC 7000 R28-G does not contain the correct local time and date. There are several options to setup, maintain, and configure current local time/date on the BEC 7000 R28-G. If you plan to use Time Schedule feature, it is extremely important you set up the Time Zone correctly.

  • Page 100: Firmware & Configuration

    . To upgrade the firmware of the BEC 7000 R28-G, you should download or copy the firmware to your local environment first. Click “Choose File” to specify the path of the firmware file. Then, click “Upgrade”...

  • Page 101: System Restart

    You may also restore your router to factory settings by holding the small Reset pinhole button on the back of your router in about more than 6s seconds whilst the router is turned on. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 102: Auto Reboot

    Device Configuration Maintenance – Auto Reboot Auto Reboot Schedule an automatic reboot for your BEC 7000 R28-G to ensure proper operation and best performance. This reboot will only reboot with current configuration settings and not overwrite any existing settings. Click Save to apply settings Example: Schedule BEC 7000 R28-G to reboot at 10:00pm (22:00) every weekday (Monday thru Friday) and reboot at 9:00am on Saturday and Sunday.

  • Page 103: Diagnostics Tool

    Ping other IP Address: Click Yes if you wish to ping other IP address rather than google.com Click START to begin to diagnose the connection. Speed Time: Measure the current uplink and downlink speed rate. Take less than a minute to run the test. Result in Uplink / Downlink RidgeWave® BEC 7000 R28-G User Manual...
  • Page 104 Speed Time: Measure the current uplink and downlink speed rate. Take less than a minute to run the test. Result in Uplink / Downlink Click Back to go back to the Diagnostic Tool Click START to begin to diagnose the connection. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 105: Chapter 5: Troubleshooting

    Troubleshooting Chapter 5: Troubleshooting If your BEC 7000 R28-G is not functioning properly, you can refer to this chapter for simple troubleshooting before contacting your service provider support. This can save you time and effort but if symptoms persist, consult your service provider.

  • Page 106: Recovery Procedures

    5. Internet LED lit Red, and router starts to write firmware into flash. Please DO NOT power off the router at this step. 6. Internet LED lit Green when successfully upgrade firmware. 7. Power cycle off/on the BEC 7000 R28-G RidgeWave® BEC 7000 R28-G User Manual...

  • Page 107: Appendix: Product Support & Contact

    If you come across any problems, please contact the dealer from where you have purchased the product. Contact BEC @ http://www.bectechnologies.net MAC OS is a registered Trademark of Apple Computer, Inc. Windows 10/8/7 and Windows Vista are registered Trademarks of Microsoft Corporation. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 108: Fcc Statement

    FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 25cm between the radiator & your body. RidgeWave® BEC 7000 R28-G User Manual...

  • Page 109: Professional Installation Instructions (Ridgewave® Bec 7000 R28-G)

    Please carefully select the installation position and make sure that the final output power does not exceed the limit set force in relevant rules. The violation of the rule could lead to serious federal penalty. RidgeWave® BEC 7000 R28-G User Manual...
