And may include the following: • Raceway • Modesty Panel Legs NOTE: If the TRAIN table is specified to have a Raceway or Modesty Panel, the Stretcher will be packed in the same carton. Otherwise, the Stretcher will have its own carton.
Page 3
PN 759460 Rev. B Lock Washer 1) Attach Stretcher To Legs Unwrap the stretcher (on tables with Raceways, the stretcher is packaged inside the Raceway). Attach the stretcher to each leg casting. The Backer Plate (#811679) is installed on the outside of the casting as shown. Backer Plate The stretcher is attached to each leg casting with (2) Allen Head screws...
Page 4
PN 759460 Rev. B 2) Attach Raceway To Base Assembly (Optional) If a Raceway is specified for the table, attach it to the base assembly using (4) #73053705 Raceway Holes thread-rolling Torx head screws. attachment predrilled bracket in base casting Complete Base and Raceway Assembly.
Page 5
PN 759460 Rev. B 3) Attach Base To Table Top Place the table top upside down on a well-protected surface. Carefully turn the base assembly over onto the table top. The leg attachment brackets should fit into the pockets routed into the underside of the table top.
Page 6
PN 759460 Rev. B To set up a TRAIN table, lift up the table top. As you do, the swing arms rotate out to “greet you”. Slider Press the Press the slider to lock. slider to lock. REPEAT FOR BOTH...
Page 7
PN 759460 Rev. B To Access The Raceway: The upper access door on the aisle side of the table hinges open to reveal the Outlet Rail. Up to 4 duplex electrical outlets can be installed in the Outlet Rail (2 duplexes on 48” long tables). There is also space for (1) user- supplied, single gang faceplate for communications.
Page 8
PN 759460 Rev. B Connecting The Electrical Harnesses Each Raceway with modular electrical is supplied with a factory installed harness to connect one table to the next. This harness is “keyed” to ensure proper connection. Make sure the harness is oriented properly in order to connect it.
Page 9
PN 759460 Rev. B INSTALLATION INSTRUCTIONS UNDERWRITERS LABORATORIES LISTED MANUFACTURED WIRE SYSTEM THESE ASSEMBLIES ARE INTENDED FOR INSTALLATION IN ACCESSIBLE, DRY LOCATIONS IN ACCORDANCE WITH ARTICLE 604 OF THE NATIONAL ELECTRICAL CODE NFPA70. TYPICAL APPLICATIONS WOULD BE TO PROVIDE BRANCH CIRCUIT POWER FOR USE ABOVE DROPPED CEILINGS, IN CEILING TO FLOOR PARTITIONS, BELOW RAISED FLOORS, ON MODULAR DESK SYSTEMS, ETC.
PN 759460 Rev. B Wiring Schematic Wiring schematics must be followed to prevent overloading of neutrals. WARNING: “RISK OF FIRE OR ELECTRICAL SHOCK. DO NOT ELECTRICALLY CONNECT TO MORE THAN ONE SOURCE OF SUPPLY. ALWAYS DETERMINE THAT THE WIRING ASSEMBLY IS ELECTRICALLY CONNECTED TO ONE AND ONLY ONE SOURCE OF SUPPLY”...
Page 11
PN 759460 Rev. B Base Power Infeed Installation: Hardwire Raceways viewed from aisle side. Doors not shown for clarity Either Leg, all table lengths The hardwire base Power Infeed is supplied 72” in length, and can be routed down either leg. It can be cut to the appropriate length by the installing electrician.
Page 12
PN 759460 Rev. B Base Power Infeed Installation: Modular Raceways viewed from aisle side. Doors not shown for clarity Option A - Left Hand Leg, all table lengths The infeed needs to exit the left hand leg, as seen from the aisle. Factory Installed Table-to-Table Harness Connect the Modular Base Power Infeed here...
Page 13
PN 759460 Rev. B Base Power Infeed Installation: Single Circuit 20-amp Plug Raceways viewed from aisle side. Doors not shown for clarity. Only use with duplex outlets labeled for Circuit One (marked with a roman numeral “I”) CORD CONNECTED EQUIPMENT SHALL NOT EXCEED 125V FROM ANY CONDUCTOR TO GROUND.
