If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©
2018 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
Lox
™
4-Star and 5-Star Base Chairs
Customer Service Assembly Direction
Note: 4-Star Base Chair shown here.
Directions apply for 5-Star Base Chair also.
Page 1 of 6
939500684 Rev B
Advertisement
Related Manuals for Coalesse Lox 4-Star Base Chair
Summary of Contents for Coalesse Lox 4-Star Base Chair
- Page 1 ™ 4-Star and 5-Star Base Chairs Customer Service Assembly Direction Note: 4-Star Base Chair shown here. If you have a problem, question, or request, call Directions apply for 5-Star Base Chair also. your local dealer, or Steelcase Line 1 at 888.STEELCASE (888.783.3522) for immediate action by people who want to help you.
- Page 2 Replace Seat Cushion Grasp onto the seat cushion assembly and lift up forcefully. Align seat & shell. Firmly pinch shut at all five (5) star nut locations. Page 2 of 6 939500684 Rev B...
- Page 3 Replace Back Cushion Grasp onto the back cushion assembly and pull out forcefully. Align new back cushion assembly & shell. Apply firm pressure to the back cushion assembly at all velcro locations. Page 3 of 6 939500684 Rev B...
- Page 4 WITHOUT BACK WITH BACK CUSHION CUSHION Replace Chair Shell with or without Back Cushion Remove the seat cushion assembly from current chair per “Replace Seat Cushion” on page 2. Install two (2) star washers with screw provided onto all five (5) emboss locations in the new chair shell. NOTE: Star washers need to taper downward when installed onto new chair shell.
- Page 5 Replace Column Cylinder Using a mallet, remove the seat assembly. Using a mallet, remove the base from the old cylinder. Reverse steps to re-assemble chair. NOTE: Sit in finished chair to make sure there is a good connection between the tapers of the cylinder & chair shell and cylinder &...
- Page 6 Replace Base Carefully lay chair on it’s side on a scratch resistant surface. Using a mallet, remove old base and install new base. Carefully place chair in its upright position. NOTE: Sit in finished chair to make sure there is a good connection between the taper of the cylinder &...
