Nitrogen Oxide Analyzer
Also supports operation of: when used in conjunction with:
© TELEDYNE ADVANCED POLLUTION INSTRUMENTATION (TAPI)
Copyright 2010
Teledyne Advanced Pollution Instrumentation
Operation Manual
Model T200
Model T200U Analyzer T200U addendum, PN 06861
T200U-NOy Converter T200U addendum, PN 06861 and
Model T201 Analyzer T201 addendum, PN 07271
9480 CARROLL PARK DRIVE
SAN DIEGO, CA 92121-5201
Toll-free Phone: 800-324-5190
Phone: 858-657-9800
Website:
T200U-NOy addendum, PN 07303
USA
Fax: 858-657-9816
Email:
api-sales@teledyne.com
http://www.teledyne-api.com/
Part Number 06858 Rev A
DCN5847
21 September 2010
