KinAn HT5832 User Manual

Cat5 kvm over ip switch (8 port/16 port/24 port/32port)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
8 Port/16 Port/24 Port/32 Port
User Manual
Cat5 KVM over IP Switch
(8 Port/16 Port/24 Port/32 Port)
User Manual
www.kinankvm.com
@All right reserved Shenzhen Kinan Technology Co., Ltd.
Date: 2025/05
Version: 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT5832 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KinAn HT5832

Summary of Contents for KinAn HT5832

  • Page 1 8 Port/16 Port/24 Port/32 Port User Manual Cat5 KVM over IP Switch (8 Port/16 Port/24 Port/32 Port) User Manual www.kinankvm.com @All right reserved Shenzhen Kinan Technology Co., Ltd. Date: 2025/05 Version: 1.0...

  • Page 2: Table Of Contents

    8 Port/16 Port/24 Port/32 Port User Manual Table of Contents Table of Contents ................................1 1. Product Overview ............................... 2 1.1 Introduction ..............................2 1.2 Features ................................2 1.3 Appearance ...............................4 2. Installation and Start-up ............................. 6 2.1 Rack Mounting ..............................6 2.2 Install KVM Components ..........................6 2.3 KVM Adapter ..............................

  • Page 3: Product Overview

    8 Port/16 Port/24 Port/32 Port User Manual 1. Product Overview 1.1 Introduction The IP-based KVM (IP-KVM) redirects the local keyboard, mouse and video data to a remote management console. The operator can safely manage one or many computers locally at the server site or remotely via a standard internet browser.
  • Page 4 8 Port/16 Port/24 Port/32 Port User Manual  Keyboard and mouse emulation to ensure the normal booting  Auto scan feature for monitoring user-selected computer  Hot pluggable – add or remove computers without having to power down the switch Remote Console ...

  • Page 5: Appearance

    8 Port/16 Port/24 Port/32 Port User Manual 1.3 Appearance Front View Figure 1.1 Front View 1．LED Module 6．Touchpad 2．Rear Bracket Slot 7．Handle 3．LED OSD Controls 8．Release Catch 4．Front Bracket 9．Display panel 5．Keyboard 10. Switch LED...
  • Page 6 8 Port/16 Port/24 Port/32 Port User Manual Structure and Size (18.5) Figure 1.2 Size Dimension Rear View 1．Power Input (AC) 6．RS485 Port 2．Power Switch 7．Monitor Port 3．Power Input (DC) 8．PC Connecting Port 4．LAN Port 8．Ground Screw 5．USB Port 10. /...

  • Page 7: Installation And Start-Up

    8 Port/16 Port/24 Port/32 Port User Manual 2. Installation and Start-up 2.1 Rack Mounting A standard rack mounting kit is provided to mount the switch in a depth of 686-770 mm in a standard 19” rack. For other mounting distances, the rear brackets need to be customized accordingly. With one person hold the switch in place, the other person slides the L bracket into the switch’s side mounting brackets from the front to the back, then screws the brackets to the rack (see below installation drawing).

  • Page 8: Kvm Adapter

    8 Port/16 Port/24 Port/32 Port User Manual Figure 2.2 Installation Diagram Installation Steps: 1. Make sure the IP KVM switch has been connected to the ground. 2. Connect the KVM adapter to the PC or Server via Cat5 cable. 3. You can remote control the KVM switch via IP. 4.

  • Page 9: Opening The Console

    8 Port/16 Port/24 Port/32 Port User Manual Model No. Keyboard/Mouse Explanation KCM-1200U Connect to USB/VGA server KCM-3200H HDMI Connect to USB/HDMI server KCM-2200D Connect to USB/DVI server KCM-4200P Connect to USB/DP server LED Indicator of the KVM Adapter Components Function Indicates that the corresponding host has been Green Online...

  • Page 10: Closing The Switch

    8 Port/16 Port/24 Port/32 Port User Manual Best Resolution : 1366x768@60Hz Figure 2.4 open angle of the switch 4. The KVM makes two “beep” sounds after power on, the orange light keeps flashing and an UI window appears for you to input user name and password. User Name admin Password...

  • Page 11: Operating The Monitor

    8 Port/16 Port/24 Port/32 Port User Manual 3. Operating the Monitor Figure 3.1 Monitor adjust menu buttons 3.1 The LED OSD allows you to set up and configure the LED display. Buttons Functions MENU SELECT Brings up the main menu. Exits the current menu and returns to the previous menu or exits the EXIT/AUTO LED OSD.

  • Page 12: Led Operation

    8 Port/16 Port/24 Port/32 Port User Manual 3.2 LED Operation Figure 3.2 16 Port LED front views Components Function Switching freely from port 1 to port 8 1-16 Switching freely from port 1 to port 16 Press【1】and 【2】at the same time for three seconds resets the Reset keyboard and mouse Press 【7】...

  • Page 13: Key Combination Function

    8 Port/16 Port/24 Port/32 Port User Manual Components Function Switching from port 1 to port 32 8 Port: If you want to switch to Port 8, press【8】, and the LED light display , then press “Enter”, you will come to Port 0~9 +Enter 32 Port : If you want to switch to Port 32, press 【3】...

  • Page 14: User Interface Operation

    8 Port/16 Port/24 Port/32 Port User Manual +【>】 Definition + Definition +【<】 Definition - Reset Video +【R】 Reset the video Lock KVM and a user login window Lock KVM + 【L】 appears 4. User Interface Operation Login UI control menu User Name admin Password...

  • Page 15: Ui Function Instruction

    8 Port/16 Port/24 Port/32 Port User Manual 4.1 UI function instruction Menu Submenu Function User List User Settings User User Group List Set user group and user permission Management Modify Set password Password Network Set IP address, subnet mask, etc. Settings Date/Time Set date and time...
  • Page 16 8 Port/16 Port/24 Port/32 Port User Manual User list interface: list all registered users, you can see more by page turning. User name or full user name search  Input user name, it shows related users which make it convenient when you have a large number of users. Add User ...
  • Page 17 8 Port/16 Port/24 Port/32 Port User Manual User group list interface: List all registered users, you can see more by page turning. User group name search  Input user group name, it shows related user groups which make it convenient when you have a large number of users.

  • Page 18: System Settings

    8 Port/16 Port/24 Port/32 Port User Manual New password: Input new password. When strong password protection is not set, the password can only consist of 1-16 letters, number of special characters (-@.$!_); if strong password protection is set, the password must be filled in according to the rules of strong password protection, please refer to “[security management]—>[security setting]”...
  • Page 19 8 Port/16 Port/24 Port/32 Port User Manual DCSG IP: the IP address should be the same with the Authentication Server IP address  DCSG Port: The port should be the same with the Authentication Server Port.  Date/Time System time setting: User-defined time: manually set by the user.
  • Page 20 8 Port/16 Port/24 Port/32 Port User Manual Left【Ctrl】+ Left【Ctrl】 Left【Alt】+ Left【Alt】 KVM Hotkeys 【Scroll Lock 】+ 【Scroll Lock 】 【Caps Lock】+ 【Caps Lock】 Left【Alt】+ Left【Ctrl】 Left【Win】+ Left【Ctrl】 Function Hotkeys Left【Alt】+ Left【Win】 1280*1024 1366*768 Set Module EDID 1920*1080 Auto...

  • Page 21: Security Management

    8 Port/16 Port/24 Port/32 Port User Manual Encoding Parameters Video format: PAL format Stream type: high definition of the main stream, low definition of the secondary stream Frame rate: the number of frames encoded per second IP ratio: the ratio of I and P frames per second Upper limit of code rate: the maximum code rate of encoding channel (1-12MBPS) Serial 4.4 Security Management...
  • Page 22 8 Port/16 Port/24 Port/32 Port User Manual Login restriction: user name login restriction  Single sign on restriction: if one user name is logged in, it can no longer log in with this user name.  Enable passwords expiration: current password use days ranges from 1-365 days, if it is enabled, the default ...

  • Page 23: System Maintenance

    8 Port/16 Port/24 Port/32 Port User Manual  Encryption mode is applied to KVM and virtual media: applied when it is selected Audit Log 4.5 System Maintenance Provide system maintenance tools such as test tools, data backup and restart Backup & Restore...

  • Page 24: Remote Control

    8 Port/16 Port/24 Port/32 Port User Manual Backup: backup current system settings.  Restore: restore the last backup of system  Factory reset: Restore to factory state (KVM must be restarted to take effect)  Ping the host Equipment Management 5.
  • Page 25 8 Port/16 Port/24 Port/32 Port User Manual Mouse configuration is different for different operating systems; please refer to below detail instructions for mouse configuration. 1) Mouse and display configuration on Windows server 2003 and above version, Windows XP and above version.

  • Page 26: Remote Web Interface Settings

    8 Port/16 Port/24 Port/32 Port User Manual Please follow the steps above to finish the setting. Configure the mouse under Linux (ubuntu 10) Input “xset m 11” in the Linux command line terminal and press [Enter] to finish the mouse setting, as shown below. 5.2 Remote WEB interface settings Install and open IE browser, click top-right settings —>...
  • Page 27 8 Port/16 Port/24 Port/32 Port User Manual Click [Security] —> [Custom Level] [ActiveX controls and plugins]...

  • Page 28: Log In

    8 Port/16 Port/24 Port/32 Port User Manual Click [Advanced], find [Allow software to run or install even if the signature is invalid] and select it. 5.3 Log in Default Items Default Value User Name admin...
  • Page 29 8 Port/16 Port/24 Port/32 Port User Manual Password admin IP Address 192.168.1.167 Notice: For security, please change the password after the first login differentiating between capital and lowercase letters. After connecting the device, open the Internet explorer web browser: http://192.168.1.167 Default Items Default Value User Name...

  • Page 30: Video Control Interface Menu

    8 Port/16 Port/24 Port/32 Port User Manual Click 5.4 Video Control Interface Menu [Hide or Show Toolbar] [Setting Option] [Send Ctrl+Alt+Del] [Mouse Synchronization] [Single Mouse] [Adaptive Window] [Source video params]...
  • Page 31 8 Port/16 Port/24 Port/32 Port User Manual [Full Screen] 1) Hide or Show Toolbar When the vide window starts, the toolbar is always displayed by default. Click the icon, the toolbar will automatically hide. If the mouse is moved to the toolbar position again, the toolbar will be displayed.
  • Page 32 8 Port/16 Port/24 Port/32 Port User Manual Relative mode: Relative mode is compatible with almost all the operating systems; the factory default mode  is relative mode. Absolute mode: The absolute mode is not compatible with LINUX operating system.  Full Screen Setting ...
  • Page 33 8 Port/16 Port/24 Port/32 Port User Manual IP address: KVM switch’s IP address  Refresh Rate: video refresh rate  Port number: video port number  Manual calibration resolution: when the resolution of the target server is not consistent with the ...
  • Page 34 8 Port/16 Port/24 Port/32 Port User Manual Click the blank input box to display the virtual keyboard, and click the keys on the virtual keyboard to display the input box. Send ------send Ctrl+Alt+De Keyboard Macro: click this button, the target server will receive shortcut key. Send Ctrl+Alt+Del Bring up the task manager of target server (Windows operating system) 4) Mouse Synchronization...

  • Page 35: Ip Menu Option

    8 Port/16 Port/24 Port/32 Port User Manual 5) Single mouse In the video window, it will hide the remote user’s mouse, and only show the target server’s mouse. 6) Source video params 7) Optimum size The initial size of the video window is 1024x768, when click this button, the video window will adjust the size of the window according to the resolution of the target server.
  • Page 36 8 Port/16 Port/24 Port/32 Port User Manual User list interface: list all registered users, you can see more by page turning  User name or full user name search Input user name, it shows related users which make it convenient when you have a large number of users. ...
  • Page 37 8 Port/16 Port/24 Port/32 Port User Manual protection. More details please check “[security management]—> [security setting]—> [strong password]”. 3) User group: Select the corresponding user group  Delete User Select the user you want to delete, click [delete] Note：admin cannot be deleted，other users can be deleted, even if they are online. ...
  • Page 38 8 Port/16 Port/24 Port/32 Port User Manual User group list User group list interface: list all registered users, you can see more by page turning  User group name search Input user group name, it shows related user groups which make it convenient when you have a large number of users ...
  • Page 39 8 Port/16 Port/24 Port/32 Port User Manual 1) User group name: it only contains low case letter, number and “_” 2) Authority: mainly refers to management authority and operation authority, click show more, permission menu appears (shown in picture above), click show less, permission menu disappears. ...

  • Page 40: System Settings

    8 Port/16 Port/24 Port/32 Port User Manual Note：SUPER_USER is system allocated which cannot be deleted  Edit user group Click【1】edit user group window pop up; For specific operation, please check “add user group” Change Password The passwords which is using for logged user 1) Old password: Enter the old password.
  • Page 41 8 Port/16 Port/24 Port/32 Port User Manual Network Settings ＩＰｖ４address setting:...
  • Page 42 8 Port/16 Port/24 Port/32 Port User Manual  I P address: preset IP address  Subnet mask: Generally, it should be consistent with other devices in the network.  Default gateway: Generally, it should be consistent with other devices in the network. ...

  • Page 43: Security Management

    8 Port/16 Port/24 Port/32 Port User Manual Video format: PAL format Stream type: high definition of the main stream, low definition of the secondary stream Frame rate: the number of frames encoded per second IP ratio: the ratio of I and P frames per second Upper limit of code rate: the maximum code rate of encoding channel (1-12MBPS) Serial port setting 6.3 Security Management...
  • Page 44 8 Port/16 Port/24 Port/32 Port User Manual Security Settings Login restriction: user name login restriction   Single sign on restriction: if one user name is logged in, it can no longer log in with this user name, if it is selected, you can log in with the user name ...

  • Page 45: System Maintenance

    8 Port/16 Port/24 Port/32 Port User Manual  Strong password length: From 1-bit to16 bits. Encryption mode   Local information encryption mode: three encryption schemes and one un-encryption scheme.  Encryption mode is applied to KVM and virtual media: applied when it is selected. Audit Log 6.4 System Maintenance Provide system maintenance tools such as test tools, data backup and restart.
  • Page 46 8 Port/16 Port/24 Port/32 Port User Manual  Backup: backup current system settings  Restore: restore the last backup of system  Factory reset: Restore to factory state (KVM must be restarted to take effect) equipment Management Remote upgrade Provide users with better upgrade experience and continuous technical support...
  • Page 47 8 Port/16 Port/24 Port/32 Port User Manual Upgrade method: Click [browse] and select upgrade file, upload the file to the device, then click [upgrade]to finish upgrade...

  • Page 48: Appendix

    8 Port/16 Port/24 Port/32 Port User Manual 7. Appendix 7.1 Specifications Model HT5808 HT5816 HT5824 HT5832 Direct Computer Connections Port Selection Keyboard, Mouse Button, UI, Web, Hotkey Model WXGA TFT View Area 18.51” Optimum Resolution 1366×768@60Hz LED Monitor Color 16.7 M Brightness 250cd/m²（...

  • Page 49: Grounding Requirements

    8 Port/16 Port/24 Port/32 Port User Manual 7.2 Grounding Requirements Make sure the KVM and the devices that connected to KVM are all connected to the ground. To improve the device safety, please make sure the device is connected to the ground and use the STP cable to connect the device. The STP cable contains four shielded twisted pair and one ground wire, the ground wire should be welded into the RJ-45 connector.
  • Page 50 8 Port/16 Port/24 Port/32 Port User Manual...
