ZSSC3241
Sensor Signal Conditioner IC for Resistive Sensors
Description
ZSSC3241 SSC Evaluation Kit is designed for
sensor module evaluation, laboratory setup, and
module calibration development for the ZSSC3241
Sensor Signal Conditioner (SSC).
The main purpose of the ZSSC3241 Evaluation Kit
is to enable the communication between the user
and the ZSSC3241 device with the GUI (Graphical
User Interface). The ZSSC3241-GUI establishes the
communication via a USB port (configured as a
virtual COM port) to the SSC Communication Board
(CB). The microcontroller on the SSC CB interprets
these commands, converts them to the configured
interface (I2C, SPI, or OWI), and provides it to the
ZSSC3241 located on the ZSSC3241 SSC
Evaluation Board.
Almost all possible applications can be tested with
the Evaluation Kit and the GUI, so that the customer
can easily get the first experience and also evaluate
in detail the ZSSC3241 functionalities.
Kit Contents
ZSSC3241 Evaluation Board - ZSSC3241EVB
•
SSC Communication board (CB)
•
Sensor Replacement Board (SRB)
•
ZSSC3241 24-PQFN 4mm 4mm samples (5
•
pcs)
USB Cable
•
Document Number
May.22.23
Evaluation Kit User Guide
Features
Implemented I2C, SPI, or OWI interface options
•
for customer specific communication.
Connections for user's real sensor module
•
Sensor Replacement Board for sensor emulation
•
"Dry-run" calibration and calibration examples
•
Immediate applications of any functionalities
•
Modular design of kit components for evaluation
•
Clamshell 24-PQFN socket for ZSSC3241
•
device under test (DUT)
Support multi-DUT usage without soldering
•
Product specific, powerful GUI (Graphical User
•
Interface)
AFE configurator
•
AD / DA processing path transparency
•
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Renesas ZSSC3241EVB
Summary of Contents for Renesas ZSSC3241EVB
- Page 1 Evaluation Kit and the GUI, so that the customer can easily get the first experience and also evaluate in detail the ZSSC3241 functionalities. Kit Contents ZSSC3241 Evaluation Board - ZSSC3241EVB • SSC Communication board (CB) • Sensor Replacement Board (SRB) •...
- Page 2 Evaluation Kit User Guide Figure 1. ZSSC3241 Evaluation Kit Disclaimer Integrated Device Technology, Inc. and its affiliated companies (herein referred to as “RENESAS”) shall not be liable for any damages arising out of defects resulting from delivered hardware or software (ii) non-observance of instructions contained in this manual and in any other documentation provided to user, or (iii) misuse, abuse, use under abnormal conditions, or alteration by anyone other than RENESAS.
- Page 3 ZSSC3241 Evaluation Kit User Guide Contents Evaluation Kit Setup ............................6 User Computer Requirements and Setup ..................... 6 1.1.1. Computer Requirements ......................6 1.1.2. Software Installation and Setup ....................7 Evaluation Board Configuration and Connections ................. 7 Communication Interfaces ........................10 Power Supply Options .........................
- Page 4 ZSSC3241 Evaluation Kit User Guide Figures Figure 1. ZSSC3241 Evaluation Kit ......................... 2 Figure 2. Connected ZSSC3241 Evaluation Kit ....................... 6 Figure 3. ZSSC3241 SSC Evaluation Board – Overview ..................7 Figure 4. Communication Board LED Status after Initialization ................11 Figure 5.
- Page 5 ZSSC3241 Evaluation Kit User Guide Tables Table 1. Signal Connections to the Communication Board ..................8 Table 2. Signal Connections to the SRB ........................8 Table 3. Sensor Signals at Connectors on EB ......................8 Table 4. LEDs on EB ..............................8 Table 5.
- Page 6 ZSSC3241 Evaluation Kit User Guide Evaluation Kit Setup This document describes the ZSSC3241 Evaluation Kit, including the hardware components, the product- specific configuration, the ZSSC3241 Evaluation Software, and its installation. The software is designed for Windows®-based operating systems to communicate with the ZSSC3241 Evaluation Kit via an USB connection to the master PC on user’s side.
- Page 7 Software Installation and Setup The ZSSC3241 Evaluation Software is not part of the Evaluation Kit packet; it is shared via the responsible Renesas team members. Note: FTDI USB drivers are needed for proper communication. If these drivers are not already installed on the user’s computer, they can be downloaded from the FTDIs homepage, https://www.ftdichip.com/FTDrivers.htm.
- Page 8 ZSSC3241 Evaluation Kit User Guide The complete list of connected signals between CB and EB is given in Table 1. Table 1. Signal Connections to the Communication Board Name Description 5VDC power supply 5VDC power supply switch controlled (for timing) KS5P 2,4,6,24,40 Ground connection...
- Page 9 ZSSC3241 Evaluation Kit User Guide Table 5 provides a summary of all possible connectors and headers available at the EB. Table 5. Connectors and Headers Connector Type Description 4-Pin Header Sensor signal connections ZSSC3241 socket 24-Pin ZIF socket Direct access to the pins of the ZSSC3241. Each IC pin can be connected to VDD or GND J2, J3, J6, J7 2-10-Pin Header with an optional 2.54mm jumper...
- Page 10 ZSSC3241 Evaluation Kit User Guide 1.3 Communication Interfaces All three supported digital interfaces (I2C, SPI, and OWI) can be used with the Evaluation Kit for the communication with the ZSCC3241. The desired interface has to be configured in the ZSSC3241 GUI (see Figure 8) as well as on the Evaluation Board by jumpers.
- Page 11 ZSSC3241 Evaluation Kit User Guide Figure 4. Communication Board LED Status after Initialization The Evaluation Board is preconfigured for SPI communication and a direct 5V power supply to VDD, coming from the CB. The necessary jumper settings for are the following (see Figure 5): JP12: 5V supply at VDD via KS5V (from the CB) •...
- Page 12 ZSSC3241 Evaluation Kit User Guide Figure 6. Evaluation Board LED Status after Starting GUI Figure 7. Initial GUI Display May.22.23 Page 12...
- Page 13 ZSSC3241 Evaluation Kit User Guide 2. GUI The initial display of the GUI could be divided in nine different sections (see Figure 8), where functional contents and operating instructions are put together to simplify the evaluating process. 1. Menu Bar: capabilities for NVM data transfer and interface configuration changes (see section 2.1). 2.
- Page 14 • The configuration text files have the suffix ‘nvm’ for quick identification. They are containing the complete memory content, including the customer and the Renesas register information. 2.1.1.1. Load NVM Configuration To load a configuration file, select File / Load NVM Config. Each row content (register value) is compared to the current value of the relevant register of the ZSSC3241 memory.
- Page 15 ZSSC3241 Evaluation Kit User Guide To change setting for an interface, follow these steps: 1. Click on Interface / Setup. Digital Interface Setup pop-up window opens. 2. Select the communication protocol from the ‘Interface Type’ drop-down list. 3. Make the necessary changes to the configurable parameters, see Figure 11. Due to limitations of the Communication Board the GUI does not allow the full bandwidth of settings supported by the ZSSC3241, for example, Fast and High Speed (HS) mode for I2C.
- Page 16 ZSSC3241 Evaluation Kit User Guide 2.2 Active Interface The basic interface settings are summarized in this section. Additionally, there is an option to scan the I2C bus to identify the connected I2C slave. The Scan I2C bus button is only active when I2C communication is selected, as shown in Figure 12.
- Page 17 ZSSC3241 Evaluation Kit User Guide Note: In Cyclic Mode, the ZSSC3241 always provides BUSY=1 until the STOP_CYC (Command BF command is sent. In the drop-down menu it can be selected weather raw measurements are run for temperature measurements, external sensor or both (see Figure 15). Figure 15.
- Page 18 ZSSC3241 Evaluation Kit User Guide Each measurement result coming from the ZSSC3241 is structured in 3 bytes (24-bit). The GUI defines the data display by in the Display Control section. The full measurement data stream of bits can be considered in the communication log.
- Page 19 ZSSC3241 Evaluation Kit User Guide Figure 20. Communication Log Examples 2.5.2. Measurement Data Log Measurement data can be recorded by activating the ‘Log Measurements Data’ checkbox in the Log section of the GUI (see Figure 19). While the ‘Log Measurement Data’ is checked all measurement results are appended to the log file.
- Page 20 The ZSSC3241 is in Sleep Mode. Sleep Mode The ZSSC3241 is not in Test Mode. Test Mode Test Mode The ZSSC3241 is in Test Mode (only for Renesas use). Test Mode Cyclic Mode The ZSSC3241 is not in Cyclic Mode. Cyclic Mode Cyclic Mode The ZSSC3241 is in Cyclic Mode.
- Page 21 ZSSC3241 Evaluation Kit User Guide 2.6.3. Sensor and Temperature Readings Sensor (external and temperature) readings from the ZSSC3241 are indicated in the numerical displays (see Figure 23). The displays show the recent measurement value in the decimal notation. As the measurement values in Measurement tab and measurement log, the output of the numerical displays is defined by the settings in the Display Control (see section 2.4).
- Page 22 ZSSC3241 Evaluation Kit User Guide background, due to mismatch between the old CRC in register 35 and changed data in the NVM. New CRC calculation can be triggered by clicking the ‘Write CRC’ button (see Figure 42). On start-up, the GUI automatically attempts to read the memory content of the connected ZSSC3241. If it fails, the NVM tab displays the value 0 for all registers.
- Page 23 ZSSC3241 Evaluation Kit User Guide 2.7.2.3. DAC Configuration The analog output, controlled by the DAC, can be configured to clip at a defined lower and upper limit. Both can be entered as a decimal value, on the parameter side of this tab. The function is switched on and off via the ‘Clipping’...
- Page 24 ZSSC3241 Evaluation Kit User Guide 2.7.3. Calibration Tab The Calibration tab (see Figure 27) allows the user to execute the calibration procedure for the external bridge sensor and/or the temperature sensor. The tab is divided into three main areas: Calibration Points Positions: distribution of the calibration points. •...
- Page 25 ZSSC3241 Evaluation Kit User Guide Calculated Coefficients Required Set Points Type External Tempera Sensor ture S(O+G+TC(O+G+SOT(O+G))) 6 Point T(O+G+SOT)) S(O+G+SOT+TC(O+G+SOT(O+ 7 Point G))) T(O+G+SOT)) 2 Point T(O+G) 3 Point T(O+G+SOT) The number of entries in the table of this section is updated accordingly. It contains up to 7 rows and 4 columns for each combination of sensor and temperature conditions, see Table 12.
- Page 26 ZSSC3241 Evaluation Kit User Guide Figure 28. Activate Analog Calibration Note: Raw measurement commands are not driving the analog output stage. To get the analog measurement values for the calibration table it is mandatory to use SSC commands in combination with default coefficients value in the NVM.
- Page 27 ZSSC3241 Evaluation Kit User Guide 2.7.3.4. Calibration Examples The calibration points drop-down menu contains at the lowest entries example calibration data for digital analog calibrations. Depending on user choice between voltage and current loop, the according raw data is updated in the calibration table.
- Page 28 ZSSC3241 Evaluation Kit User Guide 2.7.4.2. ADC Diagnostic When the ‘Apply ADC-Diagnostic’ button is clicked to activate the ADC Diagnostic, the standard sensor processing path is disconnected. Instead, an analog differential voltage ranging from -15mV to +15mV is directly input to the ADC, which performs a conversion using the SM_config registers setup. The input is realized via a decimal number from 0 to 31, which are directly mapped to the mV stages from -15mV to 15mV.
- Page 29 The command syntax can be found in the SSC Command Syntax for V4.x Communication Boards spreadsheet, which is available using the following link: SSC-CB - SSC Communication Board | Renesas. Figure 35 shows an example of Write/Read command. May.22.23 Page 29...
- Page 30 ZSSC3241 Evaluation Kit User Guide Figure 35. Read/Write Operations via Terminal A script can be loaded and executed by clicking the ‘Loading Script’ button, see Figure 35. The GUI is limiting its search focus on text files with ‘.src’ extension. Any text file can be loaded, but each line of the script must contain a nonempty string.
- Page 31 ZSSC3241 Evaluation Kit User Guide 2.7.5. AFE Configuration Tab Figure 37 shows how the tab is divided into the following parts: AFE Configurator: allows the input of a general sensor characteristic, which is used to determine an • optimized AFE Configuration. The resulting configuration can be directly transferred and written to the ZSSC3241 registers by clicking the ‘Copy to SM_Config1’...
- Page 32 ZSSC3241 Evaluation Kit User Guide Figure 38. Sensor Characteristic Since the min/max values have the unit mV/V already, they can be directly put into the Sensor Output windows. Figure 39 illustrates the calculation for this sensor example, the resulting configuration on the right side, and the effective usage of the ADC dynamic range below the calculated voltages in the processing chain.
- Page 33 ZSSC3241 Evaluation Kit User Guide Figure 40. Parameter Description Depending on Sensor Type The sensor type choice implies a different IC-internal processing. Since the ZSSC3241 analog frontend is designed and optimized to process differential voltages, the input of the absolute voltage measurement must be referenced versus an internal voltage.
- Page 34 ZSSC3241 Evaluation Kit User Guide Figure 42. Raw Measurement Calculator 2.8 Information Bar The bar provides additional information for users, such as certain application status and warning messages. An example is shown in Figure 43, applying the I2C interface scan by the Scan I2C-Bus button. Figure 43.
- Page 35 ZSSC3241 Evaluation Kit User Guide 3. Glossary Term Description Analog-to-Digital Analog-to-Digital Converter Analog Front End Arithmetic Logic Unit Communication Board Current Loop Command (received and processing) Communication Port Cyclic Redundancy Check Digital-(to)-Analog Direct Current DC/DC DC-to-DC converter Device Under Test Evaluation Board End of Conversion Field-Effect Transistor...
- Page 36 ZSSC3241 Evaluation Kit User Guide 4. Ordering Information Orderable Part Number Description and Package ZSSC3241EVB ZSSC3241 Evaluation Board SSCCOMMBOARDV4P1C SSC Communication Board V 4.1 SSCSENSORREPBDV2P0 SRB (Sensor Replacement Board) V2.0 Revision History Revision Date Description of Change May.22.23 Initial release May.22.23...
