- Page 1 ZL9024MEVAL1Z User’s Manual: Evaluation Board Industrial Analog and Power Rev 0.00 Jan 2018...
-
Page 2: Key Features
The ZL9024M uses ChargeMode™ control (ASCR) architecture, which responds to a transient load within a single switching cycle. The ZL9024MEVAL1Z evaluation board is a 3inx4.5in 6-layer FR4 board with 2oz. copper on surface layers and 1oz. copper on buried layers. This evaluation board comes with placeholders for pin-strap resistor population to adjust output voltage, switching frequency, and device PMBus™... - Page 3 ZL9024MEVAL1Z 1. Overview Figure 1. ZL9024MEVAL1Z Block Diagram Recommended Equipment • DC power supply with two channels or two separate DC power supplies with minimum 6V/20A sourcing capacity and 6V/0.5A sourcing capabilities, respectively • Electronic load capable of sinking current up to 33A •...
-
Page 4: Functional Description
The ZL9024MEVAL1Z is capable of handling a 0A to 33A output current transient, in which the slew rate is less than 2A/µs, such as electronic load. If the slew rate exceeds 2A/µs, then it may be necessary to increase the output capacitance or change VOUT_OV_FAULT_LIMIT and VOUT_UV_FAULT_LIMIT values for proper operation. - Page 5 (5) Connect the VDD voltage supply to the VDD connectors (J9 and J10). Make sure the power supply is not enabled when making the connections. (6) Connect the ZLUSBEVAL3Z dongle (USB to PMBus adapter) to the ZL9024MEVAL1Z board using the 6-pin male connector labeled “PMBus DONGLE IN”.
- Page 6 To achieve this, select enough trace width, copper weight, and the proper connectors. The ZL9024MEVAL1Z evaluation board is designed to run at 33A at room temperature without additional cooling systems needed. However, if the output voltage is increased or the board is operated at elevated temperatures, then the available current is derated.
- Page 7 ZL9024MEVAL1Z 4. Configuration File Configuration File The following is a sample configuration file for the ZL9024M. Copy and paste (from RESTORE_FACTORY TO ### End User Store) to a plain text file and save it as Confile_file_name.txt. The # symbol is used for a comment line.
- Page 8 Dongle for PMBus option. For Multiple Board Evaluation, Connect to PMBus DONGLE OUT Connection of Other Board To Daisy Chain PMBus Connection VOUT Regulation Monitor Figure 3. ZL9024MEVAL1Z Evaluation Board Top Side UG155 Rev.0.00 Page 8 of 20 Jan 29, 2018...
- Page 9 ZL9024MEVAL1Z 5. PCB Layout Guidelines Placeholders for Pin-Strap Resistors Figure 4. ZL9024MEVAL1Z Evaluation Board Bottom Side UG155 Rev.0.00 Page 9 of 20 Jan 29, 2018...
- Page 10 ZL9024MEVAL1Z Circuit Schematic COMMUNICATION CONNECTION SALRT SALRT UNNAMED_1_SMLED_I24_B VI2C MSTR_EN VI2C MSTR_EN UNNAMED_1_SMRES_I162_A PREQUEL SEQUEL ZL9024MIRZ-CNC UNNAMED_1_NCHANNEL_I200_D 2N7002-7-F VOUT+ UNNAMED_1_SMRES_I123_B VR25 SALRT SALRT VDDC VDDC UNNAMED_1_GTSERIES_I82_NC MSTR_EN VOUT MSTR_SYNC VOUT SYNC 22.1 VSEN+ VSEN+ 108-0740-001 VSEN- VSEN- 22.1 PHASE VSWH...
-
Page 11: Bill Of Materials
ZL9024MEVAL1Z 5. PCB Layout Guidelines Bill of Materials Reference Manufacturer Part Designators Description Number C1, C2, C3, C4 CAP TANT POLY 470µF 6.3V 2917 Panasonic 6TPF470MAH C15 - C19 CAP TANT POLY 470µF 4V 2917 Panasonic 4TPE470MCL CAP ALUM 470µF 20% 25V SMD... -
Page 12: Board Layout
ZL9024MEVAL1Z 5. PCB Layout Guidelines Board Layout Figure 6. Silkscreen Top Figure 7. Top Layer UG155 Rev.0.00 Page 12 of 20 Jan 29, 2018... - Page 13 ZL9024MEVAL1Z 5. PCB Layout Guidelines Figure 8. Layer 2 Figure 9. Layer 3 UG155 Rev.0.00 Page 13 of 20 Jan 29, 2018...
- Page 14 ZL9024MEVAL1Z 5. PCB Layout Guidelines Figure 10. Layer 4 Figure 11. Layer 5 UG155 Rev.0.00 Page 14 of 20 Jan 29, 2018...
- Page 15 ZL9024MEVAL1Z 5. PCB Layout Guidelines Figure 12. Bottom Layer UG155 Rev.0.00 Page 15 of 20 Jan 29, 2018...
- Page 16 ZL9024MEVAL1Z 6. Typical Performance Curves Typical Performance Curves The following data was acquired using a ZL9024MEVAL1Z evaluation board. 0.6V_889kHz 0.6V_533kHz 0LFM 0.6V_320kHz 1V_533kHz 200LFM 1.2V_533kHz 400LFM 1.5V_533kHz Load Current (A) Ambient Temperature (°C) Figure 13. Efficiency vs Output Current at V = 3.3V for...
- Page 17 ZL9024MEVAL1Z 6. Typical Performance Curves ASCR Gain = 500 Residual = 80 (50mV/DIV) (10A/DIV) 50µs/DIV Figure 19. Load Transient Response at V = 3.3V, Figure 20. Thermal Image, 3.3V to 1.5V = 33A, = 1.2V, I = 0A to 16.5A (>15A/µs), f = 533kHz, = 25 °C, f...
-
Page 18: Revision History
ZL9024MEVAL1Z 7. Revision History Revision History Rev. Date Description 1.00 Jan 29, 2018 Updated Figure 5. 0.00 Jan 26, 2018 Initial release UG155 Rev.0.00 Page 18 of 20 Jan 29, 2018... - Page 19 10. It is the responsibility of the buyer or distributor of Renesas Electronics products, or any other party who distributes, disposes of, or otherwise sells or transfers the product to a third party, to notify such third party in advance of the contents and conditions set forth in this document.
- Page 20 ZL9024MEVAL1Z UG155...
