- Page 1 SIT UP BENCH BH3660B ASSEMBLY INSTRUCTIONS...
-
Page 2: Parts List
PARTS LIST DESCRIPTION Q'TY MAIN FRAME FRONT BASE REAR BASE LEG EXTENSION ARMREST CUSHION SUPPORT SLIDE TUBE ADJUSTABLE SUPPORT BACK CUSHION SUPPORT (L&R) SEAT CUSHION SUPPORT JOINT PLATE FOAM TUBE JOINT TUBE BACK CUSHION SEAT CUSHION ARMREST CUSHION FOAM ROLLER PLASTIC HEAD BOLT FAST PIN SQUARE NECK BOLT M10*90 + ARC WASHER + NUT... - Page 5 ASSEMBLY INSTRUCTIONS STEP 01 1. Attach front base (2) to main frame (1) with square neck bolt M10*90 + arc washer + nut (19). 2. Attach rear base (3) to main frame (1) with square neck bolt M10*90 + arc washer + nut (19). 3.
- Page 6 STEP 02 1. Attach leg extension (4) to main frame (1) with bolt M10*90 + washers + lock nut (21). 2. Insert foam tubes (11) into hole on main frame (1) and leg extension (4). Then push a foam roller (16) onto each side of foam tube (11). STEP 03 1.
- Page 7 STEP 04 1. Attach seat cushion supports (9) to bolts on back cushion supports (8) with lock nut M10 + washer (26). 2. Attach joint plates (10) to seat cushion supports (9) with bolt M10*45 + washers + lock nut (23). 3.
- Page 8 STEP 05 1. Attach cross beam (29) and arc joint plate (31) to right and left vertical beam (27&28) with bolt M10*95 + arc washer + nut (30). 2. Attach right and left safety lock (32&33) to adjustable barbell support (35) with lock nut M8 (34).
