CIC850
CIC850_850394_OM_20240904
INDOOR
CYCLE
Online Support
If you require assistance or are
experiencing issues with your
Spirit Machine, please contact
customer care for additional help.
1-800-258-8511
questions@spiritfitness.com
Warranty Registration
Scan to quickly and easily
register your new Spirit
Fitness machine.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIC850 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Spirit CIC850

  • Page 1 Online Support If you require assistance or are experiencing issues with your Spirit Machine, please contact customer care for additional help. 1-800-258-8511 questions@spiritfitness.com Warranty Registration Scan to quickly and easily register your new Spirit CIC850 INDOOR Fitness machine. CYCLE CIC850_850394_OM_20240904...
  • Page 3: Table Of Contents

    Table of Contents Product Registration ............2 Exploded View Diagram ..........35 Warning / Safety Instructions Parts List ................36 Product Labels ..............3 Warranty Warnings, Compliance, and Notes .........4 Warranty ................38 Safety Instructions .............5 Electrical Safety ..............6 Parts and Assembly Parts Included ..............
  • Page 4: Product Registration

    PRODUCT REGISTRATION WARRANTY REGISTRATION Thank you for your purchase of this quality unit from Spirit Fitness. Your new unit was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available. Through your dealer, Spirit Fitness will do all we can to make your ownership experience as pleasant as possible for many years to come.
  • Page 5: Product Labels

    PRODUCT LABELS SERIAL NUMBER STICKER SERIAL NUMBER This sticker will be found on the front stabilizer tube. Please record the number below the barcode for the purpose of registering your Indoor Cycle’s warranty. 1234 5678 9876 (870) 935-1107 SAFETY WARNING STICKER This sticker will be found on the left side of your Indoor Cycle’s upright.
  • Page 6: Warnings, Compliance, And Notes

    WARNINGS, COMPLIANCE AND NOTICES NOTE: This equipment has been tested and found to comply This product has been certified to meet the following with the limits for a Class B digital device, pursuant to Part standards: 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a •...
  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS When using an appliance, basic precautions should always be followed, 13. Do not attempt to use your equipment for any purpose other than including the following: for the purpose it is intended. Read all instructions before using this appliance. 14.
  • Page 8: Electrical Safety

    IMPORTANT OPERATION INSTRUCTIONS WARNING! NEVER expose the bike to rain or moisture. This product is NOT designed for use outdoors, near a pool or spa, or in any other high humidity environment. Maximum environmental ratings are 40-120 degrees Fahrenheit, 95% humidity non- condensing (no water droplets forming on surfaces).
  • Page 9: Parts Included

    CIC850 PRE-ASSEMBLY PARTS INCLUDED TOOLS INCLUDED: ‰ 4mm Allen Wrench A ‰ 5mm Allen Wrench B ‰ 13/17mm Combination Wrench C ‰ M22 Wrench D Front Stabilizer Rear Stabilizer Main Frame PARTS INCLUDED: ‰ 1 Main Frame ‰ 1 Front Stabilizer ‰...
  • Page 10: Parts Of Your Indoor Cycle

    PARTS OF YOUR INDOOR CYCLE A. Tablet Holder B. Seat C. Dumbbell Holders D. Handlebar Forward/Aft Ajustment E. Waterbottle Holder F. Handlebar Adjustments G. Seat Heigh Adjustment H. Resistance Adjustment I. Flywheel J. Pedal K. Main Frame L. Front Stabilizer M.
  • Page 11: Pre-Assembly

    PRE-ASSEMBLY 1. Cut the straps, then lift the box over the unit and unpack. 2. Carefully remove all parts from the carton and inspect for any damage or missing parts. If parts are damaged or missing, contact your dealer immediately. 3.
  • Page 12: Assembly

    FLAT WASHERS (5). Do not overtighten as deformation of the stabilizer may occur. 4. Make sure the LEVELING FEET with nut are fully screwed into the STABILIZER. HARDWARE FOR STEP 1 PART TYPE DESCRIPTION M8 X 1.25 X 55L SCREW FLAT WASHER Spirit Fitness...
  • Page 13 ASSEMBLY - STEP TWO Gather HARDWARE FOR STEP 2. 2. Position the REAR STABILIZER (10) on the FRAME BRACKET as shown in the figure. 3. Attach the STABILIZER with 2 HEX SCREWS (65) and 2 FLAT WASHERS (5). Do not overtighten as deformation of the stabilizer may occur.
  • Page 14 CIC850 ASSEMBLY - STEP THREE STEP THREE Remove the STAR-POP PIN (104) from the PART components box and turn clockwise to tighten firmly into the FRAME with WRENCH (D). HARDWARE FOR STEP 3 PART TYPE DESCRIPTION KNOB STAR POP-PIN Spirit Fitness...
  • Page 15 CIC850 ASSEMBLY - STEP FOUR STEP FOUR Gather HARDWARE FOR STEP 4. Handlebars should be attached for assembly process. Remove the battery cover from the back of the CONSOLE (1 10-1). Screw for securing the battery cover can be found inside the compartment. Insert 2 AAA batteries inside the compartment and reinstall the cover.
  • Page 16 CIC850 STEP FIVE ASSEMBLY - STEP FIVE Gather HARDWARE FOR STEP 5. Pull out the SAFETY PIN (35) and slide the HANDLEBAR onto the POST (37). Insert the HANDLEBAR ASSEMBLY into the FRAME TUBE and tighten firmly with the STAR-POP PIN.
  • Page 17 CIC850 STEP SIX ASSEMBLY - STEP SIX Remove pedals from the components box. Look at the end of the pedal axle and notice each pedal is marked with an R and L on the spindle. It is indicated which side of bike the pedal is intended to assemble.
  • Page 18 ASSEMBLY - STEP SEVEN CIC850 STEP Loosen the SCREW (119) using the Wrench (C). Remove the LEFT CHAIN GUARD B (118). PART Insert the new battery on the sensor board. Replace the SMALL CHAINGUARD COVER (118) and secure with the SCREW.
  • Page 19 STEP EIGHT ASSEMBLY - STEP EIGHT Loosen the SCREWS (138) using the Wrench (E). STEP EIGHT Dig out the BRAKE KNOB UP COVER (97) with your fingers and pull it off. Insert 2 AAA batteries into the BRAKE KNOB UP COVER (97). HARDWARE FOR STEP 8 Replace the BRAKE KNOB UP COVER (97) into the BRAKE 1.
  • Page 20: Tension Knob

    Plastic, no metal touched. 2. A blue light will show when the tension knob is touch, and when it is working properly. The blue light will go off when it is Spirit Fitness Start Level Plastic, no metal End Level Plastic, no metal 2.
  • Page 21: Battery Life

    SETTING UP YOUR BIKE - CONTINUED Battery Life Adjusting the Pedal Straps Tension Knob - 2 AAA battery approximately 450hrs Place your feet in between the aluminum surface of the Console - 40hr with backlight; 2200hr without backlight pedal and the nylon foot strap that wraps around it. To function.
  • Page 22: Belt Tension Adjustment

    SETTING UP YOUR BIKE - CONTINUED Belt Tension adjustment The belt tension had been set before shipping. It should not need to be adjusted when first using. However, you may need to make the minor tension adjustment over time. NOTE: Make sure you adjust both sides equally - either tighten or loosen the belt tension so that the flywheel maintains alignment with the frame.
  • Page 23 The pitch of the saddle can be adjusted to accommodate all users. Loosen the horizontal bolt under the seat to adjust the pitch, then retighten. TRANSPORTATION The indoor cycle is equipped with two transport wheels, which are engaged when the rear of the CIC850 indoor cycle is lifted.
  • Page 24: Handlebar Height Adjustment

    2. Tighten the knob to secure the handlebar assembly. top of your shin is above the pedal axle. Spirit Fitness 2. Dismount the bike. Loosen the knob under the seat and slide the seat forward or backward as desired; tighten the knob.
  • Page 25: Resistance Adjustment

    SETTING UP YOUR BIKE - CONTINUED RESISTANCE ADJUSTMENT Resistance can be adjusted easily at any time while riding to change the intensity of workout. Turn the knob clockwise (+) to increase resistance. Turn the knob counterclockwise (-) to decrease resistance. EMERGENCY BRAKE In case of emergency or before dismounting the indoor cycle, presses directly DOWN on the resistance knob to stop the flywheel and pedal.
  • Page 26: Console Screen - Overview

    BUTTON Cadence Bar Graphic: 0 - 199RPM RPM: 0 - 199RPM SPEED: 0 - 99 KM/H PULSE: 30 - 240BPM TIME: Count Down Range 1 - 99 Minutes Count Up Range 00:01 - 99:59 LEVEL: 1-100 Protocol: BLE4.0 Spirit Fitness...
  • Page 27: Console Screen - Options

    CONSOLE SCREEN - OPTIONS QUICK START TIME In Power Saving Mode, Press Page Key will bring the CONSOLE to ‘QUICK Time is the length of time (min. / sec.) The time will count up Start’ active state. or count down during user peddling. When peddling stopped, Power Saving Mode Quick Start Mode the time will stop to count up or count down after 3 seconds.
  • Page 28: Timer Setting

    CONSOLE SCREEN - OPTIONS RESETTING ALL MEASURED VALUE HEART RATE TARGET ZONES To clear all the measured values, press and hold the Page Under the DIST or KCAL, hold the Page Key for 3 seconds to go into key under the TIME Mode for 3 seconds. All the measured the settings.
  • Page 29: Bluetooth Pairing

    CONSOLE SCREEN - OPTIONS PERSONAL DATA SETTINGS Accurate personal data will make your calories burned more accurate. Under KCAL or DISTANCE MODE, Hold Page key for 3 seconds to go into the setting, continually press ‘MODE’ key to get to the heart rate windows. 1.
  • Page 30: Connecting To Apps

    CONNECTING TO ZWIFT 1. Log in to Zwift 4. Select ride to start 2. Select the power source and cadence, the system will prompt you to select machine. 5. Enjoy the ride!
  • Page 31 5. Select “sensor” at the very bottom 2. Select equipment management 6. Select machine you wish to connect SPIRIT BIKE 3. Select “+” on the top right corner 7. Successfully paired machine will show up on this page 4. Select exercise bike...
  • Page 32 CONNECTING TO KINOMAP - CONTINUED 8. Go to browse to select a video you would like to play 10. Press start on the console when kinomap ask you to start pedaling 11. Enjoy the ride! 9. Select Start The console is compatible with most virtual active apps available.
  • Page 33: Troubleshooting

    TROUBLESHOOTING No Display on Console Heart Rate signal gets interrupted or drops out 1. Press any key to bring the console to ‘Quick Start’ mode. 1. Ensure that there is a minimum distance of 36 inches between 2. Ensure that the batteries are installed properly in the bikes.
  • Page 34 SMART TENSION WITH CONSOLE OTHER FUNCTION DESCRIPTIONS 1. In the mode of power saving (standby mode) and no connection, the user needs to press any button to wake up the console every time you want to use it, the LEVEL symbol on the console screen will start flashing, ready to connect to smart tension, and then touch to wake up the Smart tension (do not turn quickly directly), Smart...
  • Page 35: Maintenance & Care

    MAINTENANCE & CARE Post-Workout Machine Care Sanitizing Your Spirit Fitness Equipment 1. Store your machine according to the instructions when • Unupholstered high-contact surfaces (hard plastics) can be not in use. sanitized using a 75% isopropyl alcohol solution and a clean, dry 2.
  • Page 36: Maintenance Schedule

    MAINTENANCE SCHEDULE Part Recommended Action Frequency Cleaner Pedals Ensure that pedals are tight in crank Before each Use arms, that all screws on pedals are tight, and that the pedal straps are not frayed. Frame Wipe down using a clean, soft damp Daily Water cloth...
  • Page 37: Exploded View Diagram

    EXPLODED VIEW DIAGRAM CIC850 Exploded Drawing CIC850 110-1 19 23 20 110-4 125 28 128 118 119 71 71 71 135L 125 123 110-2 110-3 136R www.spiritfitness.ca...
  • Page 38: Parts List

    PARTS LIST CIC850 PARTS LIST Up sweat guard(back) (wider) Handlebar adjustment taut block DESCRIPTION Pop pin knob(long) Frame Flat hex screw SUS304 M8*P1.25*25L Outer circle tube assembly Handlebar Post assembly Front stabilizer assembly Down sweat guard(front) (wider) Transportation wheel Down sweat guard(back) (wider) Flat washer SUS304 M8(D19*d8.5*1.0t)
  • Page 39 PARTS LIST Sensor board fixing piece Fixed base assembly Permanent magnet L type knob Bearing-LF-1910ZZ Console bracket Brake block (right) Console DT-3268F Brake block (left) Flat washer SUS304 M6(D16*d6.5*1.0t) Brake gasket assembly Bushing (seat post/handlebar) Flat cross head screw SUS304 M4*P0.7*40L Left dumbbell Holder Nylon nut SUS304 M4*P0.7 Right dumbbell Holder...
  • Page 40: Warranty

    Effective August 07, 2023- CIC850 Indoor Cycle LIMITED WARRANTY* Spirit Fitness Inc. warrants all its home use Indoor Cycle parts for a period of time listed below, from the date of retail sale, as deter- mined by a sales receipt or in the absence of a sales receipt, eighteen (18) months from the original factory shipping date. Spirit Fit- ness’s responsibilities include providing new or remanufactured parts, at Spirit Fitness’s option, and technical support to our indepen-...
  • Page 41 9. Warranties outside of the United States may vary. Please contact your local dealer for details. Product features or specifications as described or illustrated are subject to change without notice. All warranties are made by Spirit Fitness, Inc. This warranty...
  • Page 42 4. Spirit Fitness’ obligation under this warranty is limited to repairing or replacing, at Spirit Fitness’ option, the product through one of our authorized service centers. All repairs must be preauthorized by Spirit Fitness. If the product is shipped to a service center freight charges to and from the service center will be the customer’s responsibility.
  • Page 44 3000 Nestle Road Jonesboro, AR 72401 | Phone: 800-258-8511 | Fax: 870-935-7611 www.spiritfitness.com ©2024 All Rights Reserved. CIC850 Owner’s Manual...
