Summary of Contents for Billy Goat AET60
- Page 1 AET60 Owner’s Manual AERATOR 60” Owner's Manual AET60 Replacement Parts TINE REPLACEMENT Replacement tip for aerating tines. P/N 381588 Part No 100384 Form No F080114D...
- Page 2 AET60 Owner’s Manual CONTENTS SPECIFICATIONS_____________________ SAFETY AND WARNINGS_____________ INSTRUCTION LABELS, PACKING CHECKLIST, & ASSEMBLY _____6 OPERATION MAINTENANCE AND TROUBLE SHOOTING ILLUSTRATED PARTS & PARTS LIST 9-10 Part No 100384 Form No F080114D...
- Page 3 AET60 Owner’s Manual Specifications AET60 Total Unit 440# (200 Kg) Weight: 37”-48”-60” Width Max. operating slope Part No 100384 Form No F080114D...
-
Page 4: General Safety Symbols
This symbol indicates that this manual and the engine manufacturer’s manual should be read carefully before assembling, operation, or servicing this equipment. ® This symbol indicates important information that will prevent damage to your BILLY GOAT Machine. Read and make sure you thoroughly understand the following safety precautions before assembling, operating or servicing this equipment: READ this manual and the engine manufacturer’s manual carefully before assembling, operating, or... -
Page 5: Safety Instruction
AET60 Owner’s Manual SAFETY INSTRUCTION DO NOT leave equipment unattended while in operation. DO NOT park equipment on a steep grade or slope. DO NOT operate equipment with bystanders in or near the work area. DO NOT allow children to operate this equipment. -
Page 6: Instruction Labels
P/N 100356 LABEL HITCH MOUNT P/N 100374 PACKING CHECKLIST Your Billy Goat is shipped from the factory in one carton, completely assembled. READ all safety instructions before assembling unit. TAKE CAUTION when removing the unit from the box. PARTS BAG &... -
Page 7: Operation
OPERATING INSTRUCTIONS The AET60 is a combination of a tow-behind aerator and a 3-point aerator with two wings for adjustable aeration widths. When used behind a tractor in the 3-point application, there are pins on each tine assembly that can be removed to allow tines to swivel, enabling the tractor to turn while still aerating with the tines in the ground. -
Page 8: Maintenance
AET60 Owner’s Manual MAINTENANCE ERIODIC AINTENANCE Periodic maintenance should be performed at the following intervals: Maintenance Operation Every Use (daily) Every 10 hrs Every 50 Hrs Inspect for loose, worn or damaged parts. Thoroughly clean all debris from unit and tines ... - Page 9 AET60 Owner’s Manual PARTS DRAWING AET60 Part No 100384 Form No F080114D...
- Page 10 AET60 Owner’s Manual PARTS LIST AET60 AET60 ITEM # PART # DESCRIPTION 381556 BASE FRAME WELDMENT 381157 LEFT WING FRAME WELDMENT 381158 RIGHT WING FRAME WELDMENT 381559 TINE AXLE WELDMENT 381560 WHEEL ASSEMBLY 381561 JACK ASSEMBLY 381562 OUTER TOW LINK...
