Titan Fitness CBLTWR320 Operator's Manual

Cable machine 10 - 320 lb selector
Hide thumbs

Advertisement

Quick Links

Download this manual
Cable Machine | 10 - 320 LB Selector
Accessory Handles Included
CBLTWR320
401990
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!

Advertisement

loading
Need help?

Need help?

Do you have a question about the CBLTWR320 and is the answer not in the manual?

Questions and answers

Related Manuals for Titan Fitness CBLTWR320

Summary of Contents for Titan Fitness CBLTWR320

  • Page 1 Cable Machine | 10 - 320 LB Selector Accessory Handles Included CBLTWR320 401990 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives...
  • Page 2 ASSEMBLY EXPLODED VIEW/ PARTS LIST DESCRIPTION DESCRIPTION MAIN FRAME LINK REAR BASE FRAME MULTI-GRIP CURL BAR PEDAL FRAME STRAIGHT BAR SEAT PAD FIXING FRAME SEAT PAD STORAGE FRAME LEG ROLLER ADJUSTABLE FRAME PARTS BOX LAT BAR WEIGHT STACK ANKLE STRAPS HARDWARE PACKING TRICEP ROPE...
  • Page 3 HARDWARE PACKING...
  • Page 4 HARDWARE PACKING...
  • Page 5 ASSEMBLY INSTRUCTIONS Step 1 Connect the Rear Base Frame (2) with the Main Frame (1), using Flat Washer Φ13.2*Φ24*2 (107), Spring Washer Φ12.9 (109), M12 Nut (114), Hex Bolt M12*50 (86) and Hex Bolt M12*100 (87).
  • Page 6 ASSEMBLY INSTRUCTIONS Step 2 Connect the Storage Frame (3) with the Main Frame (1), using Flat Washer Φ13.2*Φ24*2 (107), Spring Washer Φ12.9 (109), M12 Nut (114), Hex Bolt M12*50 (86) and Hex Bolt M12*100 (87).
  • Page 7 ASSEMBLY INSTRUCTIONS Step 3 Remove the Front Right cover (12), Rear Right Cover (15) and Right Logo Plate (22) from the Main Frame (1).
  • Page 8 ASSEMBLY INSTRUCTIONS Step 4 1. Loose the Screw M8*8 (100) on the Fixing Bushing (38). 2. Pull the stainless still pull pin (69) up and rotate 90 degrees. Make Stainless steel pull pin (69) and L-shaped connector (20) separation. 3. Remove the Flat Washer Φ11*Φ20*2(105), M10 Nut (112), Hex Bolt M10*55 (80) and Pulley Φ150 (31), split it with the pulley frame (16).
  • Page 9 ASSEMBLY INSTRUCTIONS Step 5 Assemble the Weight Stack (42), Top Weight Stack (41), 5 LB Weight Stack (40) and Fixing Bushing (38) back into the Guide Rod (37), then Fixing the Guide Rod (37) on the Main Frame (1), using Screw M8*8 (100).
  • Page 10 ASSEMBLY INSTRUCTIONS Step 6 1. Attach middle cable (54) to Aluminum pulley φ150 (31) as shown. 2. Adjust the tightness of the Middle cable (54) and fix the Aluminum pulley φ150 (31) on Pulley Frame (16), using Flat Washer Φ11*Φ20*2 (105), M10 Nut (112), Flat Nut m12 and Hex Bolt M12*50 (80).
  • Page 11 ASSEMBLY INSTRUCTIONS Step 7 Assemble the Front Right Cover (12), Rear Right Cover (15) and Right Logo Plate (15) on the Main Frame (1), using Flat Washer Φ6.6*Φ12*1.6 (102) and Pan Head, Hex Bolt M6*15 (90).
  • Page 12 ASSEMBLY INSTRUCTIONS Step 8 Connect the Pedal Frame (6) with the Main Frame (1), using Flat Washer Φ13.2*Φ24*2 (107), Spring Washer Φ12.9 (109), M12 Nut (114) and Hex Bolt M12*120 (88).
  • Page 13 ASSEMBLY INSTRUCTIONS Step 9 1. Connect the Lat bar (62) with the Top Cable (55), using Safety Hook (70) and Link (39). 2. Fix the D-Handle (33) on the Middle Cable (54),using Safety Hook(70). 3. Fix the Straight Bar (63) on the Lower Cable (56), using Safety Hook(70).
  • Page 14 ASSEMBLY INSTRUCTIONS Step 10 Assemble the Foam Roller (67) Inner End Cap (76) and Outer End Cap (51) on the Adjustable Frame (10), using Flat Washer Φ11*Φ20*2 (105) and Pan Head, Hex Bolt M10*30 (92).
  • Page 15 ASSEMBLY INSTRUCTIONS Step 11 Fix the Seat Pad (68) on the Seat Pad Support Frame (8), using Flat Washer Φ9*Φ16*1.6 (104) and Hex Bolt M8*30 (78).
  • Page 16 ASSEMBLY INSTRUCTIONS Step 12 1. Pull up the Pin from the Seat Pad Support Frame (8), then insert the Adjustable Frame (10) into the Seat Pad Support Frame (8). 2. Assemble the Seat Pad Support Frame on the Main Frame (1), Fixing by the Pull Pin.
  • Page 17 FULL ASSEMBLY/EXPLODED VIEW/ FULL PARTS LIST DESCRIPTION DESCRIPTION Main Frame Pull Pin Rear Base Frame Multi-Grip Curl Bar Storage Frame Lat Bar Slide Frame Straight Bar Pulley Carriages Pegboard Hook Pedal Fixing Frame Tricep Rope Pedal Ankle Strap Seat Pad Fixing Frame Leg Roller Φ125*216 Seat Pad Frame Seat Pad 450*200*55...
  • Page 18 Front Adjustable Tube Hex Bolt M6*15 Angle Board Hex Bolt M8*30 Cable stop plate Hex Bolt M8*20 L-shaped connector Hex Bolt M10*50 Left Logo Plate Hex Bolt M10*55 Right Logo Plate Hex Bolt M10*85 Aluminium-plastic Panel Hex Bolt M10*95 Handle Hex Bolt M10*100 Outer Spacer Hex Bolt M10*105...
  • Page 19 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
  • Page 20 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2025 Titan Brands...

This manual is also suitable for:

401990
