DRYMAX | LGR DEHUMIDIFIER
The Phoenix DryMAX LGR Dehumidifier
•
Built in Bluetooth
•
LGR Capacity - Removes moisture even in dry
conditions for deep drying.
•
Energy Efficiency - Removes 80 pints at AHAM while
drawing only 5.5 amps.
•
Smallest Footprint Large Category Dehumidifier.
•
Slide Out Handle with Recessed Wheels for Easy
Maneuverability and Compact Storage.
•
Integrated Cord and Hose Management for
Transportation and Storage.
•
Easy to read, industry graphical control panel.
•
Status Light Indicator – Tell at a Glance What
Operating Mode the Unit is in.
•
Integrated, Superior Stacking for Transportation and
Storage.
•
170 CFM - Optimized process air speeds drying and
provides static pressures for ducting.
•
Plastic Housing - Rugged roto-molded housing resists
dents and scratches
•
Outlet Ducting - 10" lay flat exhaust.
•
Pleated Media Air Filter – MERV 10
•
Lighted cord - Easy to determine power to the unit.
Specifications subject to change without notice.
OWNER'S MANUAL
Installation, Operation & Service Instructions
– READ AND SAVE THESE INSTRUCTIONS –
We've added Bluetooth functionality to DryMAX. You can
now stream all of your psychrometric data by Bluetooth to
the FREE DryLINK app or an app you may already use for
your drying jobs. Go to https://usephoenix.com/drylink/
ecosystem/ for more information on the DryLINK Ecosystem.
The feedback on the stacking of the AirMAX was so positive
we made sure to build it into the Phoenix DryMAX BLE.
We've also added an advanced graphical control panel
which puts all the information on homescreen in an easily
understandable format.
A new Status Bar is located at the top of the new control
panel to give you instant feedback about the dehumidifier
from across the room.
Remove only four fasteners and you have easy access to
service the unit.
Phoenix DryMAX BLE
Part No. 4045300-01 (RED)
4044300-02 (BLUE)
4045300-05 (Green)
Patent: thermastor.com/patents
USEPHOENIX.COM | 800-533-7533
1
Phoenix now offers
this unit in both
Red and Blue
TS-2104
03/25 Rev. B
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Therma-Stor Phoenix DryMAX BLE
Summary of Contents for Therma-Stor Phoenix DryMAX BLE
-
Page 1: Introduction
LGR Capacity - Removes moisture even in dry conditions for deep drying. The feedback on the stacking of the AirMAX was so positive we made sure to build it into the Phoenix DryMAX BLE. • Energy Efficiency - Removes 80 pints at AHAM while drawing only 5.5 amps. -
Page 2: Table Of Contents
25” INTERRUPTER. Weight 63 lbs 65 lbs • DO NOT use the Phoenix DryMAX BLE as a bench or table. Patent: thermastor.com/patents • It must always be used in the horizontal position. 3 Operation • Never operate a unit with a damaged power cord. If... -
Page 3: Electrical Requirements
3.2 Electrical Requirements Light Bar = Pulsing The Phoenix DryMAX BLE plugs into a common grounded outlet on a 15 amp circuit. It draws 5.7 amps at 80°F, 60% RH. If used in a wet area, a ground fault interrupter (GFI) is required. - Page 4 3.3.8 Condensate Removal Press the button to remove condensate manually from the reservoir. The Phoenix DryMAX BLE is equipped with an internal condensate pump to remove the water that is condensed during dehumidification. This allows the condensate to be 3.3.5 Dashboard pumped up to 23 feet with the attached hose.
- Page 5 3.3.11 Shut Down Sequence/Power Down time 3.3.13 Job Hours Press the Set button to adjust the Power Down Time in one Press and hold the key for three seconds to reset the job minute increments ranging from 3 – 20 minutes. hours from any screen.
- Page 6 3.3.16 Bluetooth 3.3.19 Humidistat Mode The Bluetooth functionality comes from the factory set to The default mode is Humidistat “Off” “On”. In the on position the DryMAX BLE is capable of Press the Set button to toggle the Humidistat Mode On/Off. transmitting data and receiving commands using the Phoenix DryLINK app or other compatible apps.
-
Page 7: Condensate Removal
UUID: The unique identifier for the Bluetooth Radio 3.4 Condensate Removal When the dehumidifier is plugged in it will enter stand-by The Phoenix DryMAX BLE is equipped with an internal mode. condensate pump to remove the water that is condensed during dehumidification. -
Page 8: Purge Button
CAUTION: Do not operate unit without the top cover in place. 4.1 Air Filter The Phoenix DryMAX BLE is equipped with a pleated media air filter that must be checked regularly. The standard filter is a MERV-10 high efficiency filter. Operating the unit with 5.1 Running Diagnostics... -
Page 9: Technical Description
Press the Set button to start the Display test. 5.1.7 Diagnostic Mode - Refrig. Test 5.2 Technical Description The Phoenix DryMAX BLE uses a refrigeration system similar to an air conditioner’s to remove moisture from incoming air and to add heat to the air that is discharged. -
Page 10: Troubleshooting
the incoming air and evaporates. The evaporator operates 3. Defective compressor capacitor in a flooded condition, which means that all the evaporator 4. Defective compressor overload tubes contain liquid refrigerant during normal operation. A 5. Defective compressor flooded evaporator should maintain constant pressure and 6. - Page 11 5.3.1 Air Mover 5.3.3 Condensate Pump The internal condensate pump removes water that collects in the reservoir. To replace the condensate pump: 1. Unplug the unit 2. Remove the top housing (3/8” driver) 3. Cut cable ties and unplug pump connector The air movement is created by an impeller.
- Page 12 6. Remove 2 of the 11/32 nuts holding pump to bracket 4. Remove control panel by removing 4 screws (T20 Torx) Replace the pump, hose, wiring, bolts, and housing in the reverse order 5.3.4 Float Switch The float safety switch activates the pump when the water 5.
-
Page 13: For Service Technicians Only
5.4 FOR SERVICE TECHNICIANS ONLY Warning Only qualified HVAC or electrical contractors are allowed to conduct maintenance, service and/or repair operations on dehumidifiers. Examples include but are not limited to breaking into the refrigerating circuit, opening of sealed components, and/or opening of ventilated enclosures. CAUTION –... - Page 14 5.5 FOR SERVICE TECHNICIANS ONLY Refrigerant Removal and Evacuation When breaking into the refrigerant circuit to make repairs – or for any other purpose – conventional procedures shall be used. However, for flammable refrigerants it is important that best practice be followed, since flammability is a consideration. The following procedure shall be adhered to safely remove refrigerant following local and national regulations: ○...
- Page 15 5.4 FOR SERVICE TECHNICIANS ONLY Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its details. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of recovered refrigerant.
-
Page 16: Options & Accessories
Lay-Flat Duct 10” Round x 250’ Roll 4024935 Lay-Flat Duct 10” Round x 250’ Roll DryMAX Bluetooth Board Upgrade 4041595 DryMAX Bluetooth Board Upgrade ontact Therma-Stor LLC at 1-800-533-7533. To order, contact Therma-Stor LLC at 1-800-533-7533. 7 Wiring Diagram ing Diagram BLK (CORD) WHT (CORD) -
Page 17: Service Parts
8 Service Parts 8 Service Parts 4042065 Condensate Pump 4041588 4037719 Micro Channel Condenser Float Switch 4039814 4043961 Compressor 4034716-04 Evap Thermistor 4041809-01 Humidity/Temp Sensor 4037847 4036885 Handle Bushing RH Condensate Hose 4036945 4036942 Handle Bracket RH Handle Weldment 4037848 Handle Bushing LH 4037038 4036946... -
Page 18: Warranty
Madison, WI 53704 Telephone: 1-800-533-7533 Who Is Covered: This warranty extends only to the original end-user of the Phoenix DryMAX BLE dehumidifier and may not be assigned or transferred. Year One: Therma-Stor LLC warrants that, for one (1) year the Phoenix DryMAX BLE dehumidifier will operate free from any defects in materials and workmanship, or Therma-Stor LLC will, at its option, repair or replace the defective part(s), free of any charge. - Page 19 USEPHOENIX.COM | 800-533-7533...
- Page 20 WARRANTY REGISTRATION CARD IMPORTANT WARRANTY INFORMATION - DO NOT DISCARD REGISTER YOUR PRODUCT. SERIAL NUMBER PART NUMBER www.thermastor.com/registration Register your product using the serial number and part number above at www.thermastor.com/registration This is important Warranty Information. Please DO NOT DISCARD!
