Owner's Manual — Phoenix 300
The Phoenix 300 Dehumidifier is designed to maximize the water removal capacity from a single 0V, 5 amp circuit.
The multiple ducting options on the Phoenix 300 allows for ducting both the intake air and the filtered and
dehumidified supply air. This makes it possible to easily combine the Phoenix 300 with a HEPA air scrubber, air
conditioner or desiccant dehumidifier.
Phoenix dehumidifiers feature significant air filtration. Even the standard 57% MERV-8 filters remove over 90% of
seven-micron particles (the size of a human red blood cell). This filtration dramatically improves the air quality in the
areas being dried and assures continued optimal performance of the refrigeration system.
The Phoenix 300
High Capacity Dehumidifier
High capacity – Up to 38 gallons per day
High energy efficiency – Plugs into a grounded 5V
outlet
Pleated media filter – Built-in air filter reduces dust
and mold
Twist-on duct collar – Direct the drying power where
you need it
Optional high-efficiency filter – Removes 95% of
one-micron particles
Reservoir pump system – Strong and dependable,
20 ft of lift
Pump purge switch – Drains reservoir, no spills or
drips
Pump fail warning light and cut-off – Prevents reservoir
overflow
Lighted power switch – Check machine status at a
glance
Digital hour meter – Easy-to-read for more accurate
billing
30-ft power cord – No need for extension cords
30-ft drain hose – Pump condensate to sinks or drains
Specifications subject to change without notice.
Toll-Free -800-533-7533
PO Box 8680 • Madison, WI 53708
Installation, Operation and Service Instructions
Read and Save These Instructions
Phoenix 300 High Capacity Dehumidifier
Phoenix 300
PN 4022599
www.thermastor.com • sales@thermastor.com
Part number TS-218
Revised 1/07
Advertisement
Table of Contents
Related Manuals for Therma-Stor Phoenix 300
Summary of Contents for Therma-Stor Phoenix 300
- Page 1 Read and Save These Instructions The Phoenix 300 Dehumidifier is designed to maximize the water removal capacity from a single 0V, 5 amp circuit. The multiple ducting options on the Phoenix 300 allows for ducting both the intake air and the filtered and dehumidified supply air.
-
Page 2: Table Of Contents
• If used in a wet area, plug it into a GROUND FAULT INTERRUPTER. • DO NOT use the Phoenix 300 as a bench or table. • It must always be used in the upright position. • The air inlet on top and the side outlet must be at least foot from walls and other obstructions to air flow. -
Page 3: Electrical Requirements
It resets to zero after 99,999.9 hours of operation. 2.10 Defrost Control Adjustment When the Phoenix 300 is used in a cool area, frost will form on the cooling coil as it dehumidifies. When enough frost forms, the defrost thermostat will initiate the timed defrost cycle. -
Page 4: Low Pressure Control
Toll-Free 1-800-533-7533 3.3 Storage There are two issues to consider when the Phoenix 300 is stored between uses and both pertain to the water trapped in the unit: damage caused by freezing and biological growth. -
Page 5: Troubleshooting
coil where it absorbs heat from the incoming air and evaporates. Figure 2: Refrigeration system of Phoenix The evaporator operates in a flooded condition, which means that all the evaporator tubes contain liquid refrigerant during normal operation. A flooded evaporator should maintain constant pressure and temperature across the entire coil, from inlet to outlet. -
Page 6: Refrigerant Charging
Evaporator coil frosted continuously, low dehumidifying capacity. . Defrost thermostat loose or defective (Sec. 2.0 and 4.7). 2. Defrost timer incorrectly set or defective (Sec. 2.0 and 4.7). 2. Low refrigerant charge (Sec. 4.4). 3. Dirty air filter or air flow restricted. (Sec. 3.). Compressor runs with power switch OFF. -
Page 7: C Replacing A Compressor- Non-Burn Out
and water. These contaminants must be carefully removed otherwise even small residues will attack replacement compressor motors and cause failures. The following procedure is effective only if the system is monitored after replacing the compressor to insure that the clean up was complete. . -
Page 8: Relay
It also reduces compressor short cycling after the compressor has stopped. Figure 3: Electrical schematic of Phoenix 300 www.thermastor.com • sales@thermastor.com... -
Page 9: Service Parts List
6 Service Parts Item Part No. Qty. Description 40288 Accumulator 4022636 Air Filter, Pleated, 2” x 20” x 20” 402264 Air Filter, Pleated, 4” x 20” x 20” MERV-8 4022624 Air Filter, Pleated, 4” x 20” x 20” (90-95% EFFICIENT) 402083 Blower w/ Capacitor 4022622... - Page 10 This page intentionally left blank. Toll-Free 1-800-533-7533 www.thermastor.com • sales@thermastor.com...
- Page 11 (but all warranty periods will be extended by the period of time, if any, that the Phoenix 300 Dehumidifier is out of service while awaiting covered warranty service).
