Installation
! The cords must not cover up the area
shown in the figure below. This is neces-
sary to allow the amps and navigation me-
chanism to dissipate heat.
Do not cover this area.
! The semiconductor laser will be damaged
if it overheats, so don't install the naviga-
tion unit anywhere hot —for instance, near
a heater outlet.
