Summary of Contents for Skope HB85
- Page 1 Service Manual MAN80408 Rev 1.0 Oct. 2023...
- Page 2 E-mail: skope@skope.com Website: www.skope.com Trademark Infringement The SKOPE trademark on this product is infringed if the owner, for the time being, does any of the following: • Applies the trade mark to the product after its state, condition, get-up or packaging has been altered in any manner.
-
Page 3: Table Of Contents
HB85 ........ -
Page 4: Specifications
SKOPE HB85 1 Specifications Models This service manual applies to the SKOPE HB85 countertop fridge listed below. Refer to the product specification sheet (available on the SKOPE website: www.skope.com) for specifications. Table 1: Model Model SKOPE ID HB85 HB85JN Specifications... -
Page 5: Installation Installation Guidelines
SKOPE HB85 2 Installation Installation Guidelines When installing this cabinet, make sure you consider and meet the installation guidelines below. Ventilation Surface Door Opening Climate Class Stabiliser Foot Ensure all ventilation Make sure the Allow adequate Only install the fridge in an... -
Page 6: Shelves
SKOPE HB85 Shelves The cabinet is supplied with two shelves. Remove the packaging, then place the shelves at the required height. The shelves have hooks on the back which lock them in position. Shelf hook Installation Service Manual... -
Page 7: Operation
SKOPE HB85 3 Operation Let the cabinet stand for: • at least 30 minutes before connecting to the power supply for the first time. • 10 minutes if it has been disconnected from the power supply for any reason. Loading Product Let the cabinet run for 30 minutes before loading it with product for the first time. -
Page 8: Replacement Procedures
SKOPE HB85 4 Replacement Procedures Electrical Safety Caution Disconnect the cabinet from the mains power supply before attempting any maintenance. Correct wiring routing is as important as using the correct components for compliance with safety and radio interference regulations. In order to maintain safety and compliance with regulations, make sure you replace any wiring that is disturbed during servicing and secure it back in its original position. - Page 9 SKOPE HB85 Procedure 2: To remove the top hinge cover Before you start You will need a tool to slide under the hinge cover to prise it up. 1. Wrap the tool in a soft cloth to protect the cabinet from scratches.
-
Page 10: Interior Light
SKOPE HB85 Interior Light The cabinet interior is fitted with a 3 watt LED strip light. Ensure you replace the light with the same light type. Procedure 4: To replace the interior light 1. Disconnect the cabinet from the mains power supply (see page 8 above). -
Page 11: Electrical
SKOPE HB85 Electrical Remove the refrigeration compartment grille to access the cabinet’s light power supply and refrigeration cartridge electrics in the rear of the cabinet. Remove the relay cover to access the electrical connections and compressor electrics. Refrigeration compartment grille Power cord –... - Page 12 SKOPE HB85 Procedure 5: To access the electrics 1. Disconnect the cabinet from the mains power supply (see page 8). 2. Remove the refrigeration compartment grille. Refrigeration compartment grille 3. Remove the light power supply, located on the left rear wall of the refrigeration compartment.
-
Page 13: Refrigeration System
SKOPE HB85 Refrigeration System Evaporator The evaporator fan and thermostat are located inside the cabinet on the back of the upper rear duct panel. The evaporator coil is attached to the inside back wall of the cabinet behind the lower rear duct panel. You need to remove the upper panel to access the lower panel. - Page 14 SKOPE HB85 Procedure 7: To remove the thermostat 1. Disconnect the cabinet from the mains power supply. 2. Access the thermostat (see Procedure 6 above). Thermostat 3. Use a screwdriver to pop the thermostat knob off the front. 4. Use a socket to loosen the nut.
-
Page 15: Condenser
SKOPE HB85 Condenser The condenser’s pipes are foamed into the sides of the cabinet. Compressor The compressor is located in the rear at the bottom of the cabinet. You can access the compressor by removing the refrigeration compartment grille. Drier... -
Page 16: Wiring
SKOPE HB85 5 Wiring HB85 GNYE GNYE S1-2 P1-2 S1-2 P1-2 P1-1 S1-1 Compressor Compressor Start Start Thermostat Thermostat P2-1 S2-1 P2-1 S2-1 S1-3 P3-1 S1-3 P3-1 S2-3 P2-3 S2-3 P2-3 Overload Overload Relay Relay S1-4 P3-2 S1-4 P3-2 P4-2 S4-2... -
Page 17: Spare Parts
SKOPE HB85 6 Spare Parts Cabinet and Refrigeration System Table 2: Parts – Cabinet and refrigeration system Item Description SKOPE part no. Top hinge cover HB0060875562A LED light HB0074001620 Top hinge HB0060875560 Shelf HB0070116985 Thermostat knob HB0070203732 Upper air duct... - Page 18 SKOPE HB85 Table 2: Parts – Cabinet and refrigeration system (continued) Item Description SKOPE part no. Door HB0070844090A Lock HB0070103412 Lock bracket HB0070117003 Adjustable foot – left HB0070204762 Bottom hinge with adjustable foot – right HB0070114499A Condensate tray HB0060249428 Compressor base plate HB0070116773 Compressor (Donper L96CU1) –...
-
Page 19: Maintenance
SKOPE HB85 7 Maintenance Cleaning WARNING Unplug the cabinet from the mains power supply before undertaking any cleaning. Many commercially available cleaning products contain solvents that may damage the plastic components of this product and cause them to crack. It is important to use only warm water and a small amount of detergent when cleaning the cabinet. -
Page 20: Troubleshooting
SKOPE HB85 8 Troubleshooting Use Table 3 below to troubleshoot cabinet and refrigeration system problems. Table 3: Cabinet and refrigeration system diagnostics Problem Possible cause Repair • Loss of power supply • Check the power supply. Cabinet not operating •... - Page 21 SKOPE Industries Limited ABN: 73 374 418 306 AU: 1800 121 535 NZ: 0800 947 5673 skope@skope.com www.skope.com...
