  • Page 1 Installation guide M-9414-9899-01-A ATOM DX and RTLF linear encoder system ™ www.renishaw.com/atomdxdownloads #renishaw...
  • Page 2 This page is intentionally left blank. ATOM DX and RTLF linear encoder system ™...

  • Page 3: Table Of Contents

    Bracket dimensions .......................40 www.renishaw.com...
  • Page 4 Output signals........................41 Speed .

  • Page 5: Legal Notices

    (1) This device may not cause harmful interference, and (2) this device must accept Renishaw warrants its equipment and software for a limited period (as set out in the Standard any interference received, including interference that may cause undesired operation.

  • Page 6: Intended Use

    Tool ADTi-100 data sheet (Renishaw part no. L-9517-9699), Advanced Diagnostic Tool ADTi-100 Renishaw Inc. and ADT View software quick-start guide (Renishaw part no. M-6195-9321), and the Advanced 1001 Wesemann Drive Diagnostic Tool ADTi-100 and ADT View software user guide (Renishaw part no. M-6195-9413).

  • Page 7: Reach Regulation

    Disposal of waste electrical and electronic equipment The use of this symbol on Renishaw products and/or accompanying documentation indicates that the product should not be mixed with general household waste upon disposal. It is the responsibility of the end user to dispose of this product at a designated collection point for waste electrical and electronic equipment (WEEE) to enable reuse or recycling.
  • Page 8 ATOM DX software notices Third party licences The ATOM DX product includes embedded software (firmware) to which the following notices apply: Copyright © 2009 - 2013 ARM LIMITED Copyright © NXP Semiconductors, 2012 All rights reserved. All rights reserved. This Redistribution and use in source and binary forms, with or without modification, are Software that is described herein is for illustrative purposes only which provides customers with permitted provided that the following conditions are met: programming information regarding the LPC products.
  • Page 9 Renishaw and the United States Government, civilian federal agency or prime contractor respectively. Please consult the applicable contract or subcontract and the software licence incorporated therein, if applicable, to determine your exact rights regarding use, reproduction and/or disclosure.

  • Page 10: Storage And Handling

    Storage and handling Minimum bend radius NOTE: During storage, ensure that the self-adhesive tape is on the outside of 150 mm the bend. System N-heptane Propan-2-ol CHOHCH ATOM DX and RTLF linear encoder system ™...
  • Page 11 Temperature Humidity 95% relative humidity (non-condensing) to IEC 60068-2-78 Storage System −20 °C to +70 °C Operating System 0 °C to +70 °C www.renishaw.com...

  • Page 12: Atom Dx System Installation Overview

    For information on designing the readhead and scale into the system refer to the detailed installation drawings and 3D models at or contact your local Renishaw representative. For information on the ATOM DX product range refer to the ATOM DX  miniature encoder system data sheet (Renishaw part no. L-9517-9736).

  • Page 13: Rtlf Tape Scale Installation Drawing

    Scale length (with optional end covers) = Measuring length + 13 mm Operating rideheight: 2.5 ±0.11 (40 μm version) Scale length (without end covers) = Measuring length + 6 mm 2.5 ±0.055 (20 μm version) NOTE: ATOM DX cabled readhead variant shown. For readhead dimensions see pages and 39. www.renishaw.com...

  • Page 14: Rtlf Application Methods

    RTLF application methods The RTLF scale application method depends upon the scale length and the bracket type being used. Ledge or dowel mounting the scale Mounting the scale with a scale applicator (RTLF scale lengths < 500 mm only) (any RTLF scale length) Using an adjustable bracket Using a fixed mounting Ledge or dowel mount...

  • Page 15: Equipment Required To Ledge Or Dowel Mount The Rtlf

    Datum clamp (A-9585-0028) • Loctite ® ™ (P-AD03-0012) Optional parts: • Renishaw scale wipes (A-9523-4040) • Loctite 435 dispensing tip (P-TL50-0209) • End cover kit (A-9585-0035) • Reference mark deselection stickers (A-9402-0049 for a sheet of 20) • Lint-free cloth...

  • Page 16: Rtlf Scale Application (Ledge Or Dowel Mounting)

    RTLF scale application (ledge or dowel mounting) 1. Thoroughly clean and degrease the substrate using recommended solvents (see ‘Storage 3. Locate the scale against dowels or a ledge and rotate down onto the substrate. and handling’ on page 10). Allow the substrate to dry before applying the scale. Support dowels 2.
  • Page 17 4. Clean the scale using Renishaw scale wipes or a clean, dry, lint-free cloth. 5. Fit the datum clamp and the end covers (see ‘Fitting the scale datum clamp’ ‘Fitting the scale end covers’ on page 21) and, if needed, deselect the reference marks that are not required (see ‘RTLF reference mark deselection’...

  • Page 18: Equipment Required For Mounting The Rtlf With A Scale Applicator

    Equipment required for mounting the RTLF with a scale applicator Suitable for: Any length of RTLF tape scale. Required parts: Optional parts: • Renishaw scale wipes (A-9523-4040) • An appropriate length of RTLF tape scale (see ‘RTLF tape scale installation drawing’ on page 13) •...

  • Page 19: Rtlf Scale Application (Any Scale Length)

    Ensure the backing paper feeds out of the back of the applicator around the splitter screw • Insert the scale into the applicator up to the start position. as shown on the following page. • Ensure the backing paper feeds out of the back of the applicator www.renishaw.com...
  • Page 20 NOTE: Slim and side mount applicators only: Fit the readhead mounting bracket after removal of scale applicator. 13. Clean the scale using Renishaw scale wipes or a clean, dry, lint-free cloth. 14. Fit the datum clamp and the end covers (see ‘Fitting the scale datum clamp’...

  • Page 21: Fitting The Scale Datum Clamp

    2. Align the markers on the edges of the end cover with the end of the scale and place the end cover over the scale. Ensure the adhesive wicks along the entire length of the cut-out. NOTE: There will be a gap between the end of the scale and the adhesive tape on the end cover. www.renishaw.com...

  • Page 22: Rtlf Reference Mark Deselection

    1. Ensure the scale is free from dirt and grease by cleaning with a Renishaw scale wipe or one of the recommended solvents (see ‘Storage and handling’...

  • Page 23: System Connection: Top Exit Readhead

    A-9414-1238 • Provide appropriate strain relief at the readhead. The Renishaw top exit cables are fitted with a P-clip to ensure appropriate cable strain relief. • When using Renishaw’s top exit cables ensure that the P-clip is mounted within a 50 mm radius of the readhead cable exit.
  • Page 24 Top exit readhead (with readhead cable inserted) Dimensions and tolerances in mm Detail A: Connector (readhead end) and P-clip P-clip Detail B: P-clip dimensions Use M2 tapping drill (∅1.6) as clearance for pin 11.07 5.7 ±0.05 2.09 Hole for M2 screw ∅1.5 ±0.05 ATOM DX and RTLF linear encoder system...

  • Page 25: Readhead Mounting And Alignment: Methods

    There is a range of tools available to assist with readhead installation depending upon the system design and these are detailed below. For more details on designing the mounting bracket and selecting the appropriate mounting tools contact your local Renishaw representative.
  • Page 26 Shim kit (A-9401-0050) Required parts This method is intended for applications where the rideheight of the readhead cannot be adjusted. • Dial test indicator (DTI) or similar The system should be designed to achieve a nominal 2.3 mm (±0.2 mm) from the readhead • 2 M2 × 6 screws mounting surface to the top of the scale.
  • Page 27 100 µm a single shim should be used; for distances greater than 100 µm select one thick (≥ 100 µm) and one thin (< 100 µm) shim. Care must be taken to ensure the scale surface is not scratched. Renishaw offer a DTI In the above example of a required shim thickness of 130 µm this could either be: adapter that can be used to assist with this process.
  • Page 28 ‘nose’ that is machined to the optimum rideheight (2.5 mm ±0.02 mm). It is mounted in place of the readhead directly onto the bracket. The bracket should have location pins or a shoulder to control readhead yaw. Contact your local Renishaw representative for more Shoulder information on bracket design.
  • Page 29 5. Remove the dummy head. 6. Install the ATOM DX readhead in place of the dummy head using 2 M2 × 6 screws in diagonally opposite fixing holes. Ensure the readhead is pushed back against the shoulder of the bracket or the mounting face. www.renishaw.com...

  • Page 30: Accurate Bracket And Feeler Gauge

    6. Check the readhead set-up LED is flashing green along the full axis of travel. 7. Proceed with ‘System calibration’ on page 32. For more information on bracket design contact your local Renishaw representative. ATOM DX and RTLF linear encoder system ™...

  • Page 31: Atom Dx Calibration Overview

    For more details refer to the Advanced Diagnostic Tool ADTi-100 and ADT View software User guide (Renishaw part no. M-6195-9413) and Advanced Diagnostic Tool ADTi-100 and ADT View software Quick-start guide (Renishaw part no. M-6195-9321).

  • Page 32: System Calibration

    Reference mark phasing NOTE: The functions described below can also be carried out by using the optional ADTi-100 and ADT View software. See www.renishaw.com/adt for more information. 1. Move the readhead back and forth over the reference mark until the LED stops flashing and remains solid blue.

  • Page 33: Restoring Factory Defaults

    When reinstalling the system, or in the case of continued calibration failure, factory defaults should be restored. NOTE: Restoring factory defaults can also be carried out using the optional ADTi-100 and ADT View software. See www.renishaw.com/adt for more information. To restore factory defaults: 1. Switch system off.

  • Page 34: Readhead Led Diagnostics

    Readhead LED diagnostics Mode Status Installation mode Green flashing Good set-up, maximise flash rate for optimum set-up Orange flashing Poor set-up, adjust readhead to obtain green flashing LED Red flashing Poor set-up, adjust readhead to obtain green flashing LED Calibration mode Blue single flashing Calibrating incremental signals Blue double flashing...

  • Page 35: Troubleshooting

    Check that the readhead variant is the correct type for the chosen scale (see the ATOM DX  ™ miniature encoder system data sheet (Renishaw part no. L-9517- 9736) for details of readhead configuration) Unable to get a flashing Green LED over System run-out is not within specification •...
  • Page 36 Check the readhead optical window and scale are clean and free from contamination • Check that the readhead variant is the correct type for the chosen scale (see the ATOM DX ™  miniature encoder system data sheet (Renishaw part no. L-9517-9736) for details of readhead configuration) No reference mark output •...
  • Page 37 (see page 32) Multiple reference marks output Unused reference marks have not been • All unused reference marks should be deselected (see page 22) as only the calibrated deselected reference mark will be repeatable • Check alignment of deselection stickers www.renishaw.com...

  • Page 38: Atom Dx Cabled Readhead Dimensions

    ATOM DX cabled readhead dimensions Dimensions and tolerances in mm 1.4 (40 μm version) 1.9 (20 μm version) Set-up LED Readhead datum faces 6.45 10.25 12.7 11.7 4.85 Mounting/ datum face 4.15 Ø9 maximum Readhead/ scale orientation 16.5 3 mounting holes Ø2.5 minimum through 20.5 R >...

  • Page 39: Atom Dx Top Exit Readhead Dimensions

    1.4 (40 μm version) 1.9 (20 μm version) Set-up LED 6.45 10.45 Readhead datum faces 10.25 8.37 12.7 4.85 Mounting/ datum face 4.15 Ø9 maximum Readhead /scale orientation 16.5 3 mounting holes Ø2.5 minimum through 20.5 Identification marks for readhead manufacture only.  Notches will vary depending on readhead type. Not the optical centreline www.renishaw.com...

  • Page 40: Bracket Dimensions

    Bracket dimensions Dimensions and tolerances in mm ‘L’ mounting bracket (A-9402-0037) Side mount bracket (A-9401-0103) 10.5 16.25 3 holes M2 × 0.4 Ø9.15 8.85 12.7 Ø9.4 4.85 3 holes M2 × 0.4 8.25 16.5 16.5 3.25 2 holes M3 × 0.5 ATOM DX and RTLF linear encoder system ™...

  • Page 41: Output Signals

    NOTE: Top exit cables are terminated with the ‘K’ pin-out or the ‘D’ pin-out dependent upon which top exit readhead cable is used. PCB mount mating connectors: Top entry (BM10B-SRSS-TB); Side entry (SM10B-SRSS-TB). Connector on top exit readhead only: Mating connector (10SUR - 32S). Remote CAL line must be connected for use with the ADTi-100. www.renishaw.com...

  • Page 42: Speed

    Speed 20 μm ATOM DX readhead Maximum speed (m/s) Clocked Minimum edge Readhead type output option separation (MHz) (ns) (5 µm) (1 µm) (0.5 µm) (0.2 µm) (0.1 µm) (50 nm) (40 nm) (20 nm) (10 nm) (5 nm) (2.5 nm) 7.25 3.63 1.813...
  • Page 43 1.07 0.54 0.269 0.215 0.107 0.054 0.027 18.13 7.25 3.63 1.81 0.73 0.36 0.181 0.145 0.073 0.036 0.018 9.06 4.53 1.81 0.91 0.45 0.18 0.09 0.045 0.036 0.018 0.009 0.005 1038 For a readhead with a 1 m cable. www.renishaw.com...

  • Page 44: Electrical Connections

    NOTE: For Renishaw top exit readhead cables the shield connection is provided by the P-clip. Maximum readhead cable length: 3 m Maximum extension cable length: Dependent on cable type, readhead cable length and clock speed. Contact your local Renishaw representative for more information. ATOM DX and RTLF linear encoder system ™...
  • Page 45 120R Cable Z = 120R A B Z− 220 pF Standard RS422A line receiver circuitry. The capacitors are recommended for improved noise immunity. Single-ended alarm signal termination (Not available with ‘A’ cable termination) Customer Readhead electronics 100R E− 100nF www.renishaw.com...

  • Page 46: Output Specifications

    Output specifications Digital output signals Form – Square wave differential line driver to EIA RS422A Alarm Incremental Line driven (Asynchronous pulse) 2 channels A and B in quadrature (90° phase shifted) (Not available with ‘A’ cable termination) Resolution P (μm) S (μm) option code Signal period (P)

  • Page 47: General Specifications

    Typical sub-divisional error (SDE) 20 μm version < ±75 nm 40 μm version < ±120 nm CAUTION: Renishaw encoder systems have been designed to the relevant EMC standards, but must be correctly integrated to achieve EMC compliance. In particular, attention to shielding arrangements is essential. www.renishaw.com...

  • Page 48: Rtlf Scale Specifications

    1 m to 10 m in 1 m increments Mass 12.2 g/m For information on how the substrate affects the axis, contact your local Renishaw representative. The recommended maximum axis length for 20 μm systems is 1 m. ATOM DX and RTLF linear encoder system ™...
