3-Band Rat
Rat with a Marshall-type
3 band EQ
Contents of this document are ©2021 Pedal Parts Ltd.
No reproduction permitted without the express written
permission of Pedal Parts Ltd. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3-BandRat and is the answer not in the manual?

Questions and answers

Summary of Contents for FuzzDog 3-BandRat

  • Page 1 3-Band Rat Rat with a Marshall-type 3 band EQ Contents of this document are ©2021 Pedal Parts Ltd. No reproduction permitted without the express written permission of Pedal Parts Ltd. All rights reserved.
  • Page 2: Important Notes

    Important notes If you’re using any of our footswitch daughterboards, DOWNLOAD THE DAUGHTERBOARD DOCUMENT • Download and read the appropriate build document for the daughterboard as well as this one BEFORE you start. • DO NOT solder the supplied Current Limiting Resistor (CLR) to the main circuit board even if there is a place for it.
  • Page 3 Schematic + BOM 1N4001 D2-3 1N4148 560R 100p D4-5* 3mm Red LED Jumper 4u7 elec 2u2 elec LM308 / OP07 4u7 elec 470p Q1** 2N5457 1u elec 100KA 100u elec DIST 100KA 47u elec BASS 25KA 4u7 elec TREB 250KA 100p RUEZ 1K TRIM...
  • Page 5 The power and signal pads on the PCB conform If you’re not adding the extra clipping in positions to the FuzzDog Direct Connection format, so can D4 and D5, add a jumper wire on S1 as shown in be paired with the appropriate daughterboard for red above.
  • Page 6 Extra notes..No Ruez mod please Replace the 1K Ruez trimmer with a 47R resistor if you want to keep things stock. You’ll need to place it vertically into these pads >>>> Tone stack tweaking No rules here. Google is your friend. The values in the BOM are taken from the Krank Distortus Maximus and work very well.
  • Page 7 Test the board! Check the relevant daughterboard document for more info before you undertake this stage. UNDER NO CIRCUMSTANCES will troubleshooting help be offered if you have skipped this stage. No exceptions. Once you’ve finished the circuit it makes sense to test is before starting on the switch and LED wiring.
  • Page 8 Wire it up (if using a daughterboard please refer to the relevant document) BOARD BOARD INPUT BOARD BOARD BOARD BOARD BOARD BOARD BATTERY Wiring shown above will disconnect the battery when you remove the jack plug from the input, and also when a DC plug is inserted. The Board GND connections don’t all have to directly attach to the board.
  • Page 9: Drilling Template

    Wiggle room = good! 35mm This template is a rough guide only. You should ensure correct marking of your enclosure before drilling. You use this template at your own risk. Pedal Parts Ltd can accept no responsibility for incorrect drilling of enclosures. FuzzDog.co.uk...
