- Page 1 16 Port USB 2.0 Rack-Mountable Hub w/Internal Power Supply, ESD Surge Protection, & Port Status LEDs Model Number: HUB-1600i-RM Installation Guide Coolgear, Inc. Version: 1.0 Date: 04/30/2024...
-
Page 2: Revision History
USB devices to the downstream port of the hub, the host PC immediately gains 16 USB ports. HUB-1600i-RM USB hub is designed for use in industrial applications. It is housed in a DIN rail mountable metal case with screw holes for securing USB and power cables. - Page 3 Input power connector has screw holes to lock the power cable ✔ CE, FCC approval ✔ 2. DIAGRAM OF HUB-1600i-RM The HUB-1600i-RM provides a lockable terminal power connector to supply 5V, 1A power to each connected USB device. Need help? Visit: coolgear.com/support...
-
Page 4: Installation
This 16-port USB hub is a plug-and-play device. The software drivers are installed automatically. 1. Connect the AC power adapter to HUB-1600i-RM. The red power LED will light on when the hub is receiving power. Connect the upstream port cable to an unused USB port on your computer. -
Page 5: Specifications
427mm × 144mm × 44mm (W × L × H) 449mm × 144mm × 44mm (W × L × H) with DIN rail ears Input Power Range 90VAC to 264VAC Terminal Block Connector Output +5VDC 1A Power Need help? Visit: coolgear.com/support... - Page 6 Technical Support When you reach out to Coolgear support, you’ll find yourself in the hands of a solution-oriented and knowledgeable expert ready to answer whatever question you throw at them. If you ever need help with your product, visit coolgear.com/support for support tickets, downloads, and other support resources.
- Page 7 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
