PLEASE READ PRIOR TO INSTALLATION Before installation of this mount you should fully read these instructions to ensure you are aware of the full installation procedure. In addition to the screen and accessories and in order to carry out the installation you will need: •...
SAFTEY INFORMATION WARNING: Risk of Electrical shock. Only authorised installers should open electrical control boxes contained within or for the control of this product. WARNING: Do not exceed the weight capacity stated for each product or component. Failure to do so can result in serious personal injury or damage to the equipment.
Unpacking Parts: o Left Frame o Right Frame o Top Left Frame o Top Right Frame o Bottom Left Frame o Bottom Right Frame (Contains control box) o Left Frame Cover o Right Frame Cover o Top Left Frame Cover o Top Right Frame Cover o Bottom Left Frame Cover o Bottom Right Frame Cover...
Installation 1. Decide on the height you want the bottom of the visible projected image to be at on your finished screen. Mark this height on the wall where you are installing the screen. Now add 28mm to this further up the wall. This will be the height at which the top of the back plate on the bottom screen sections will sit.
Page 7
12. Take one of the stretcher bars and fit this between the top Left and bottom Left screen profiles. Tighten the grub screws to open the jaws of the clamp on the end of the stretcher profile to clamp onto the screen profile. These should be fitted approximately mid-way on the top and bottom left profiles but can be moved to suite speaker positioning.
Electrical Connections 1. On the bottom section of the frame is the control box. At either end of this are the connections to make to the mask motors and sensors. The mask motor connections are simple push together connectors. 2. The sensor connectors are on pre attached phoenix connectors and pug into the control box; one at each end.
Fabric Installation Your screen is delivered with two fabrics The first one to be installed is the black backing fabric then the white fabric ensuring that the projection side is facing out. Care and time should be taken during handling and installation of the fabric. On larger screens you will need 2 people to complete this task.
Page 10
Retaining track insertion point Fig. 8 • Now unwind enough fabric from the roll to take you to the middle of the screen. Again ensuring that the top of the fabric is in line with the top of the screen push the fabric into the fabric retaining track in the centre of the top rail of the screen.
Page 11
Direction of fabric Tucking Fig.10 • Continue this process until you reach the corners of the screen. You may have to pull out the original tucks in the top left and right corners and re-tuck them to ensure that you have no wrinkles in the fabric.
Inner Screen Cover Installation • Install the bottom covers first. The covers are magnetic and simply align and clip into place allowing the magnets to ‘grab’. The barb on the back of them will slot into the groove on the aluminium profile just below the grey plastic fabric retaining track. There are two sections for the top and two for the bottom with a central join.
