ZERO EDGE PRO
TM
Owner's Manual
INSTALLERS: PLEASE BE SURE TO LEAVE THIS
MANUAL WITH THE OWNER. THANK YOU!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZERO EDGE PRO and is the answer not in the manual?

Questions and answers

Related Manuals for SI ZERO EDGE PRO

Summary of Contents for SI ZERO EDGE PRO

  • Page 1 ZERO EDGE PRO Owner’s Manual INSTALLERS: PLEASE BE SURE TO LEAVE THIS MANUAL WITH THE OWNER. THANK YOU!
  • Page 2 APPLY S/N STICKER HERE LIMITED ONE YEAR WARRANTY ON SCREEN INNOVATIONS PRODUCTS Screen Innovations warrants its products, to the original purchaser only, to be free from defects in materials and workmanship for a period of one (1) year from the date of purchase by the original purchaser provided they are properly operated according to Screen Innovations’...
  • Page 3 ZERO EDGE PRO 512-832-6939 9715-B Burnet Road Suite 400, Austin,TX 78758 SCREENINNOVATIONS.COM...

  • Page 4: Table Of Contents

    ZERO EDGE PRO Table of Contents SUGGESTED PROJECTOR PLACEMENT ............. 5 STANDARD FRAME PARTS LIST .

  • Page 5: Suggested Projector Placement

    SUGGESTED PROJECTOR PLACEMENT ZERO EDGE PRO Better 11° Best 11° Good 36”-42” (91cm - 106cm)
  • Page 6 ZERO EDGE PRO PRE ASSEMBLED STANDARD SPLIT...

  • Page 7: Standard Frame Parts List

    Wall Brackets Mounting 4X Thick Corner 4X Thin Corner 1/4-20 x 1/4’’ Screws Brackets Brackets Screws (Small trim only) Bungees SI Attachment Bands Acrylic Logo 1/8’’ & 5/32’’ 4X Gloves (Maestro only) (Black Diamond and Short Hex Keys Throw Only)
  • Page 8 STANDARD If IP controlled LED lights are ordered, Phillips Hue hub must be purchased and set up separately. See page 46 for IP lighting Instructions. Flying Mount Only LED IR Controlled Only LED Remote 2X Flown Screen 2X Flown 2X Flown Ceiling Mount Cable Mount...

  • Page 9: Standard Frame Assembly

    STANDARD FRAME ASSEMBLY STANDARD Thick Bracket Thin Bracket Insert the thin corner brackets into the outside channels and the thick corner brackets into the inside channels of the vertical frames. Then slide into the channels in the horizontal frames.
  • Page 10 STANDARD Make sure the points on the frame pieces line up. Then finger tighten 2 of the set screws to lock in the corners.
  • Page 11 STANDARD A = B Measure the diagonals to check if frame is square. If one diagonal is longer then push on the corners at that diagonal. Tighten all set screws once the diagonals are equal to within 1/8’’.

  • Page 12: Split Frame Parts List

    Support Screws Screws nuts Screws Brackets (Small Trim Only) 4X Thick Corner 4X Thin Corner 1/8’’ & 5/32’’ or 4X Gloves Bungees SI Attachment Acrylic Logo 3/32’’ Hex Keys (Maestro only) Bands Brackets Brackets (Black Diamond and Short Throw Only)
  • Page 13 SPLIT If IP controlled LED lights are ordered, Phillips Hue hub must be purchased and set up separately, see page 46 for IP lighting Instructions. Flying Mount Only LED IR Controlled Only LED Remote 2X Flown Screen 2X Flown 2X Flown Ceiling Mount Mount Cable...

  • Page 14: Split Frame Assembly

    SPLIT FRAME ASSEMBLY SPLIT Thick Bracket Thin Bracket Insert the thin corner brackets into the outside channels and the thick corner brackets into the inside channels of the vertical frames. Then slide into the channels in the horizontal frames.
  • Page 15 SPLIT Slide the horizontal frame pieces together and secure with the splice bars. Then attach the vertical support to the frame as shown.
  • Page 16 SPLIT Make sure the points on the frame pieces line up. Then finger tighten 2 of the set screws to lock in the corners.
  • Page 17 SPLIT A = B Measure the diagonals to check if frame is square. If one diagonal is longer then push on the corners at that diagonal. Tighten all set screws once the diagonals are equal to within 1/8’’.

  • Page 18: Led Lights Attachment

    LED LIGHTS ATTACHMENT ZERO EDGE PRO If IP controlled LED lights are ordered, Phillips Hue hub must be purchased and set up separately, see page 50 for IP lighting Instructions. NOTE: Steps 1 and 2 will have already been completed if possible to be shipped that way.
  • Page 19 ZERO EDGE PRO Press in the lights to the channel on the frame. Do not crease the lights at the corners.
  • Page 20 ZERO EDGE PRO Material? BLACK DIAMOND or SHORT THROW SLATE or PURE MAESTRO...

  • Page 21: Black Diamond Or Short Throw Attachment

    BLACK DIAMOND OR SHORT THROW ATTACHMENT BD or ST Black diamond and short throw material are highly sensitive. Take care to not bend or crease the material as you unroll it. Wear gloves when handling material. Carefully unroll the screen material out onto a clean floor.
  • Page 22 BD or ST DO NOT drop the frame onto the screen material. Frame must be gently set down onto the screen material to avoid denting the material. For Short Throw LED harness at bottom Carefully lie the frame onto the screen material making sure to not dent the screen material with the frame or frame corners.
  • Page 23 Remove and discard the black retaining bumpers then spread out the posts so that they align with the attaching bands. Pull up and then over on the bands to attach to the posts so that the SI diamonds are showing. Do this at all 4 corners before proceeding. Make sure the screen material is centered about the frame by making sure the edges of the screen material line up with the edges of the frame.
  • Page 24 BD or ST As you continue to attach the bands make sure the material is centered about the frame. This is easy to tell by making sure the edge of the material is flush with the edge of the frame. Attach the bands at the middle and then work your way towards the ends on all 4 sides of the screen material.

  • Page 25: Slate Or Pure Attachment

    SLATE OR PURE ATTACHMENT SLATE or PURE Wear gloves when handling material. Carefully unroll the screen material out onto a clean floor. Take care to not bend or crease the screen material. Carefully lie the frame onto the screen material. Center the frame about the screen material.
  • Page 26 SLATE or PURE Remove and discard the black retaining bumpers then spread out the posts so that they aligning with the snaps on the screen material. At all 4 corners attach the snaps at the end of screen material but NOT the snap on the corner tab.
  • Page 27 SLATE or PURE Attach the snaps at the middle and then work your way towards the ends on all 4 sides of the screen material. Finally attach the snaps at the corner tabs. Then check to make sure the screen material is flat and adjust the snap positions if necessary to flatten the screen material.

  • Page 28: Black Backer Attachment

    BLACK BACKER ATTACHMENT SLATE or PURE For AT Material Only Acoustically Transparent (AT) materials come with a black backer that must be installed to eliminate shine through. Spread out the nuts in the top frame piece and attach the black backer to the nuts with the thumb screws.

  • Page 29: Maestro Attachment

    MAESTRO ATTACHMENT MAESTRO Wear gloves when handling material. Carefully unroll the screen material out onto a clean floor. Take care to not bend or crease the screen material. Insert the rods into the pocket in the screen material. Make sure the screen material is lying flat.
  • Page 30 MAESTRO Carefully lay the frame onto the screen material. Center the frame about the screen material.
  • Page 31 MAESTRO Remove and discard the black retaining bumpers then spread out the posts so that they aligning with the holes in the screen material. Put one end of the bungee through the hole in the material and place over the post while holding the other end.

  • Page 32: Black Backer Attachment

    MAESTRO Attach the bungees at the middle and then work your way towards the ends on all 4 sides of the screen material. Check to make sure the screen material is flat and adjust the bungee positions if necessary to flatten the screen material. BLACK BACKER ATTACHMENT Spread out the nuts in the top frame piece and attach the black backer to the nuts with the thumb screws.
  • Page 33 ZERO EDGE PRO 1/2’’ SMALL TRIM 1 1/2’’ OR 2’’ MEDIUM OR LARGE TRIM...

  • Page 34: Small Trim Attachment

    SMALL TRIM ATTACHMENT SMALL TRIM Velvet on trim is delicate, handle with care. Black Diamond only Attach the vertical trim first onto the screen as shown above. NOTE: For Black Diamond and Short Throw make sure that the front lip of the trim is over the attaching bands before rotating the trim into place.
  • Page 35 SMALL TRIM Split Frame Only Attach the horizontal trim pieces. Align and secure the corners with the 1/4-20 x 1/4’’ screws as shown. Hold the trim corners together while tightening the screw to ensure a well aligned corner. Split Frame Only: Connect the horizontals at the middle by installing 1/4-20 x 1/4’’ screws trough the trim into the splice bar.

  • Page 36: Medium Or Large Trim Attachment

    MEDIUM OR LARGE TRIM ATTACHMENT MEDIUM or LARGE TRIM Velvet on trim is delicate, handle with care. Black Diamond only Attach the trim onto the screen as seen above. NOTE: For Black Diamond make sure that the front lip of the trim is over the attaching bands before rotating the trim into place.
  • Page 37 MEDIUM or LARGE TRIM Split Frame Only Loosen the screw on the corner plate, slide over to the corner, and hold the corners together while tightening the screw to secure the well aligned corners. Split Frame Only: Loosen the screw on the center cover plate, slide over to the middle, and hold together trim pieces while tightening the screw to secure the well aligned center trim seam.

  • Page 38: Logo Attachment

    ZERO EDGE PRO LOGO ATTACHMENT Attach the logo to the trim by holding it at the middle of the horizontal trim and letting the magnet pull it to and attach to the back of the trim. NOTE: You can also attach the logo to the screen after it is installed on the wall or flown.

  • Page 39: Trim Removal

    ZERO EDGE PRO TRIM REMOVAL Disconnect the trim at the corners by either removing the screw or loosening the corner plate and sliding over. Then push in on trim pieces while rotating trim off of frame. The magnet will hold the trim in place at first.
  • Page 40 ZERO EDGE PRO WALL MOUNT FLYING MOUNT...

  • Page 41: Wall Installation

    WALL INSTALLATION WALL MOUNT TOP OF VIEWING LEVEL " (9.5 cm) TOP OF VIEWING " (12.1 cm)
  • Page 42 WALL MOUNT...

  • Page 43: Flown Installation

    FLOWN INSTALLATION FLYING MOUNT 100 lbs 100 lbs (45.3 kg) (45.3 kg)
  • Page 44 FLYING MOUNT NOTE: If you pull too far the screen can be lowered by pushing down the button on the top of the flying mount. We recommend you don’t cut the extra cables for future adjustability. Simply tape the extra cable to the back of the screen frame.

  • Page 45: Ir Lighting Hex Codes

    IR LIGHTING HEX CODES ZERO EDGE PRO IR Controlled Option Only 20 13 20 13 20 13 20 13 5C A3 5D A2 41 BE 40 BF 20 13 20 13 20 13 20 13 58 A7 59 A6 45 BA...

  • Page 46: Ip Controlled Lighting Setup

    IP CONTROLLED LIGHTING SETUP ZERO EDGE PRO Screen Innovations LED IP Setup Instructions Backlight IP Option Only Before attempting to connect your LED IP to Phillips Hue, ensure that the Hue Bridge is powered on and connected to the local WIFI network.
  • Page 47 NOTES: 9715-B Burnet Road Suite 400, Austin,TX 78758 Tel: 512-832-6939 Fax: 512-832-6136 www.screeninnovations.com...
  • Page 48 NOTES: 9715-B Burnet Road Suite 400, Austin,TX 78758 Tel: 512-832-6939 Fax: 512-832-6136 www.screeninnovations.com...
